Install the Source 4WRD II Retrofit
WARNING:
only onto luminaires that have the construction features and
dimensions shown in the images in this document and where
the input rating of the retrofit kit does not exceed the input
rating of the luminaire.
WARNING:
enclosure of wiring or electrical components during kit
installation.
CAUTION:
other than oil-free canned air.
Tools required:
Adjustable wrench
•
#2 Phillips screwdriver
•
1. Use oil-free canned air to clean the LED emitters before you install
the retrofit. Do not touch the LED emitters.
2. With the fixture resting securely on a flat surface, attach the
supplied threaded post to the back end of the fixture body. Use an
adjustable wrench to tighten the threaded post one-quarter turn
past finger tight.
3. Secure the earth bond wire to the fixture body using the provided
screw and washer.
4. Gently slide the Source 4WRD II LED onto the fixture body and
threaded post while guiding the LED tower into the lamp housing
hole, as shown in the following image. Take care to prevent contact
between the LEDs and the reflector.
8
