Product Overview; Grass Bag Assembly; Specifi Cations; Appropriate Temperature Ranges - Hayter CODE613A Operator's Manual

Product Overview

4
3
2
1. Height of Cut Lever
2. Rear Defl ector
3.

Grass Bag Assembly

4. Self-Propel Lever
5. Handle
6. Blade Control Bar
7. Electric-Start Button
8. Electric Starter
9. Handle Knob
10. Easy Wash Port (Not Shown)
11. Green Series Motor
12. Battery Compartment
Grass Bag Assembly
A
B
B
©2020 - Hayter Limited
Spellbrook, Bishop's Stortford,
Herts, CM23 4BU
5
6
7
8
9
10
11
1
Figure 8
Figure 9
Specifi cations
Model
CODE613A
* Without battery

Appropriate Temperature Ranges

Charge/store the battery
pack at
12
Use the battery pack at
Use the machine at
*Charging time will increase if you do not charge the
battery pack within this range.
Store the machine, battery pack, and battery charger
in an enclosed clean, dry area. Figure 10.
12
Weight* Length Width
kg mm mm
28.3 kg 1400 530
5°C (41°F) to 40°C (104°F)*
-30°C (-22°F) to 49°C (120°F)*
0°C (32°F) to 49°C (120°F)*
1
Figure 10
1. Battery charger
2. Battery pack CODE106A
Cutting Height
Width mm
mm
460 1050
2
