Harrier 48 Pro
CODE
486A
OWNER'S HANDBOOK
(English Version)
FROM SERIAL NO: 486A001001
HANDBOOK: 486046 (Rev.1.)
Issue :10.05.04

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Harrier 48 PRO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hayter Harrier 48 PRO

Summary of Contents for Hayter Harrier 48 PRO

  • Page 1 Harrier 48 Pro CODE 486A OWNER'S HANDBOOK (English Version) FROM SERIAL NO: 486A001001 HANDBOOK: 486046 (Rev.1.) Issue :10.05.04...

  • Page 2: Specifications

    MAIN FEATURES /SPECIFICATIONS Main Features 1. Spark Plug Lead 2. Primer Bulb 3. Engine Cover 4. Air Cleaner 5. Fuel Cap 6. Serial Number Label 7. Oil Filler Cap & Dipstick 8. Handlebar Securing Knob 9. Rear Deflector 10. Engine Start Grip 11.
  • Page 3 1ST Year (12 months) We certify that this service has been carried out by an Authorised Hayter Service Dealer Date: 2nd Year (24 months) We certify that this service has been carried out by an Authorised Hayter Service Dealer Date: 1ST Year (12 months) Owner’s Name: Serial Number:...

  • Page 5: Table Of Contents

    1.2 Main Features/Specifications 1.5 Contents 1.6 Introduction 1.7 Warranty 1.8 - 1.11 Safety Precautions 1.11 Safety Symbols 1.11 Decal Symbols 1.12 Assembling the Mower 1.12 - Delivery Checklist 1.12 - Handlebar 1.12 - Adjust Handlebar Height 1.12 - Grassbag Attachment 1.13 Before Starting the Mower 1.13 - Prevent Engine Damage...

  • Page 6: Introduction

    Any arbitrary modifications carried out to this machine may relieve Hayter Limited of liability for any resulting damage or injury. Hayter mowers are robustly constructed and designed for efficient economical performance under normal mowing conditions. Correct operation and maintenance will ensure a long and satisfactory service life.

  • Page 7: Warranty

    LIMITED WARRANTY Hayter Limited warrants to the original user/purchaser that this unit shall be free from defects in material and workmanship under normal use and service for a period of one year from the date of purchase. The manufacturers of the engine furnish their own warranty and services are provided through their authorised network (Refer to "Engine Warranty Statement").

  • Page 8: 1.11 Safety Precautions

    SAFETY PRECAUTIONS Safety Alert Symbol This safety alert symbol indicates important safety messages. When you see this symbol be alert to the possibility of injury. Carefully read the following and inform others. Your mower is perfectly safe if used correctly. Failure to observe the following precautions may result in serious injury.

  • Page 9: Operation

    SAFETY PRECAUTIONS Preparation - Always use fresh fuel. Stale fuel can block the carburettor and cause leakage. - Replace fuel tank and oil tank caps securely. A damaged cutterblade or loose fixing bolt are major hazards. Before use, always visually inspect the cutting mechanism to ensure that it is in good condition.

  • Page 10: Maintenance And Storage

    SAFETY PRECAUTIONS Operation Do not tilt the mower when starting the engine. Do not put hands or feet near or under rotating parts. Never pick up or carry the mower while the engine is running. Never lift the rear deflector while the engine is running. Never touch the exhaust/exhaust guard or cooling fins when the engine is hot.

  • Page 11: Safety Symbols

    Maintenance & Storage Allow the engine to cool before storing in any enclosure. To reduce the fire hazard, keep the engine and the surrounding deck area free of grass, leaves, or excessive grease. Check the rear deflector and grassbag frequently for wear or deterioration. Replace worn or damaged parts for safety.

  • Page 12: Assembling The Mower

    ASSEMBLING THE MOWER Delivery Checklist Remove the mower from the packaging and check that the following items have been supplied correctly. If any items are missing contact, your local Hayter dealer. 1. Engine Handbook. 2. Grassbag. To prevent accidents cut off the long ribbon attached to the grass- bag and discard.

  • Page 13: Before Starting The Mower

    BEFORE STARTING THE MOWER Prevent Engine Damage To prevent engine damage the engine is shipped without oil or petrol. The engine must be filled with the correct grade of oil and petrol before starting the engine. Always use high quality detergent oil classified “For service SE, SF, SG”...

  • Page 14: 1.17 Operating The Mower

    OPERATING THE MOWER Controls Operate all control levers several times and ensure that the cables move freely. Check that the engine stop and ground drive clutch levers return freely to their rest position when released. Whilst operating the engine throttle mechanism slight resistance should be felt when moving the lever to the ‘choke’...

  • Page 15: Forward Travel

    OPERATING THE MOWER Hold the handlebar and operate the ground drive clutch lever to power the mower in a forward direction. When the ground drive clutch lever is disengaged the mower may be pushed. This feature is useful when mowing in confined areas. If the engine stop lever is released the engine will stop.

  • Page 16: Height Of Cut

    OPERATING THE MOWER Height of Cut Move the height of cut lever sideways to disengage it from the locking notch, then push forwards to lower or pull backwards to raise the height of cut. Release the lever in the required position and ensure that it locks firmly into one of the seven notch settings.

  • Page 17: Heavy Growth

    OPERATING THE MOWER Heavy Growth Areas of heavy growth should be mown without collecting the clip- pings. If collection is required, first mow the area without the grass- bag at the maximum height of cut setting. Allow the grass clippings to dry out and then mow the area at the maximum height of cut setting with the grassbag fitted.

  • Page 18: Maintenance Schedule

    MAINTENANCE SCHEDULE To prevent accidents stop the engine disconnect the spark plug lead before attempting to carry out maintenance procedures on the mower. Follow the hourly or calendar intervals, whichever occurs first. More frequent service will be required if working for prolonged periods under dusty, dry conditions, or when airborne debris is present or after extensive operation cutting tall, dry grass.

  • Page 19: 1.25 Mower Maintenance - Engine

    MOWER 100Hrs or Every Season Clean the engine cooling system. Clean more often under dusty conditions or when airborne debris is present or after prolonged operation whilst cutting tall, dry grass. Replace the spark plug. Check valve clearances. Engine Cowl Spark Plug / Lead Carburetor Exhaust Guard...

  • Page 20: Maintenance

    MAINTENANCE MOWER Oil Service Check the oil level daily before starting the engine and ensure that the correct oil level is maintained. Refer to-‘Before Starting the Mower’ for oil checking and filling instructions. Change the engine oil after the first 5 hours of operation and thereafter according to the ‘Maintenance Schedule’:- Air Cleaner Service To service the air cleaner, loosen the two screws (1) and remove cover...

  • Page 21: Spark Plug Service

    MOWER MAINTENANCE Spark Plug Service Use only Briggs & Stratton spark tester (1) to check for a spark as shown in the diagram. Replace the spark plug every 100 hours or every season, whichever occurs first. A spark plug wrench is available from any authorised Briggs &...

  • Page 22: Deck Housing

    MOWER MAINTENANCE Deck Housing Remove grass debris from the top and underside of the deck housing immediately after use. To prevent damage fertilisers and top dressings are particularly corrosive. Thoroughly clean the mower deck immediately after use on treated grass and store well away from corrosive materials. Securing Nuts &...

  • Page 23: Lubrication

    MOWER MAINTENANCE Lubrication Lubricate the wheels, pivot points and linkages with engine oil every 25 operating hours. Apply a good quality medium grease to the inner control cables at the point of entry and exit from their outer casing. Cutterblade Removal Drain the fuel by running the engine until the fuel tank is empty and the engine stops.

  • Page 24: Cutterblade Assembly

    MOWER MAINTENANCE Cutterblade Assembly Assemble the cutterblade with the turned up edges facing towards the engine. Secure the cutterblade using the bolt (1), spring washer (2), and distance piece (3) and tighten to a torque of 54Nm Cutterblade Sharpening 30°-45° A slightly worn cutterblade may be re-sharpened.

  • Page 25: Storage

    MOWER MAINTENANCE Storage To store the handlebar unscrew the 2 small securing knobs sufficient- ly to allow it to be pivoted forwards to rest against the mower. Take care to ensure that the control cables do not become snagged at the pivot point and depress the engine stop lever to prevent it being dam- aged through contact with the engine spark plug.

  • Page 26: 1.27 Trouble Shooting

    TROUBLE SHOOTING PROBLEM Engine will not turn over Engine smokes Engine runs then stops Engine will not start Engine runs rough 1.26 POSSIBLE FAULT Engine stop lever released. Incorrect oil level. Obstruction under deck. Excess oil level. Air cleaner cartridge oil soaked or blocked.
  • Page 27 PROBLEM Engine vibrates excessively Uneven cut Discharge chute blocks Mower is hard to push Mower will not self propel Poor grass collection TROUBLE SHOOTING POSSIBLE FAULT Mounting bolts loose. Cutterblade bolt loose. Cutterblade out of balance. Bent crankshaft. Undulating ground conditions Cutterblade worn Cutterblade out of balance Wheels / roller damaged...

  • Page 28: Declaration Of Conformity

    VIBRATION INFORMATION Lawnmower vibration information. RMS acceleration measured in 3 - axes at operators contact position on CODE 486A = 5 ms the handlebars. 1.28 Harrier 48 Pro CODE 486A Auto-Drive Electric Start Pedestrian Rotary Briggs & Stratton 2800 rpm...

  • Page 29: Parts List

    NO. DESCRIPTION Mainframe - Casting Plate - Location RH Clamp - Boss Inner Clamp - Boss Outer Nut - Nyloc Insert ‘T’ Type Key - Woodruff Throttle Control Engine - B/S Intek edge 55 OHV Decal - Engine Knob - Handlebar Handlebar - Lower Bolt - Handlebar Nut - Nylon Insert...
  • Page 30 PARTS LIST NO. DESCRIPTION Ratchet HOC Moulding Throwplate - Main Body Screw - Taptite Bearing - Roller Housing Roller - Rear W/A Spring Tension - Rear Axle Washer Screw - Taptite Bolt - Coach Washer Rope - Stop Handle Washer - Spring Sprocket - 17 Teeth Frame - Rear Roller W/A Key - woodruff...
  • Page 31 NO. DESCRIPTION Axle - Front W/A Moulding - Front axle Bearing Fin - Front Insert Decal - Hayter & Royal Warrant 410087 Nut - M8 Shouldered Plug - Tube 100 Tie - Cable 101 Handle - Grip 102 Brace - Support 103 Bracket HOC 104 Torsion Spring HOC 105 Rivet...
  • Page 32 PARTS LIST 1.32 31 32 48 49 54 26 -Grassbag Assy. Includes Items 28,36 & 101 2C486A01C...
  • Page 33 NOTES Notes:- 1.33...
  • Page 34 NOTES Notes:- 1.34...
  • Page 35 NOTES Notes:- 1.35...

  • Page 36: Customer Information

    CUSTOMER INFORMATION Serial No: Engine Type:-12K682-0166-E1 Date of Sale:- Your Local Dealer:- 1.36 Engine:-Briggs & Stratton Intek Edge 55...
