1 Introduction

The Mediatrix 1204 is an analogue gateway that allows connectivity between the PSTN and a VoIP
network. The device can be used with the Quadro4x/16x to emulate additional FXO ports.
This document describes how to configure the Quadro with the Mediatrix 1204 to increase Quadro FXO
capability.
For the detailed information on how to install and use the Mediatrix refer to the Mediatrix 1204
Administration Manual.
For the detailed information on how to install and use the Quadro refer to Manual II: Administrator's
Guide for Quadro4x, Quadro4xi, Quadro16x and Quadro16xi.

2 Prerequisites

•
The Quadro is connected to the network and all network settings are done without any issues.
•
The Mediatrix 1204 is connected to the LAN socket of the Quadro via a straight-through Cat 5
cable with a RJ 45 connector.
•
FXO lines of the Quadro and Mediatrix are connected to telephone lines.
•
SOHO-SW 3.0.5 or later image running on the Quadro.
•
4.4.13.88 or later software image or later image running on the Mediatrix 1204.

3 Configuration

This section presents step-by-step instructions on both the Quadro and Mediatrix setups.

3.1 Quadro Setup

3.1.1 DHCP Server Configuration

The Mediatrix 1204 has to have an IP address to identify itself in the Quadro LAN. This IP address can
be assigned to it manually or dynamically via the Quadro's DHCP server. A simpler way from the
configuration perspective is to dynamically get an IP address from the Quadro. This requires
configuration of the Quadro as a DHCP server and the Mediatri
co nfigure the Quadro as a DHCP server for its LAN interface:
1. Login to the Quadro as an administrator and select DHCP Settings for the LAN Interfac
from the LAN services menu.
2. Make sure the Enable DHCP Server checkbox is selected and the IP
configured (see Figure 1: Enabling the DHCP server on the Quadro).
Copyright © 2004 Epygi Technologies, Ltd. All rights reserved.
Increasing Quadro FXO Capability with Mediatrix
x as a DHCP client. So the first step is to
Address Range is
e
