3.2.2 Local Port Configuration

1. On the main page of the Mediatrix GUI (Figure 7 The main page of the Mediatrix GUI) right click
the Port tab and select Edit (Figure 10).
2. From the Country list box select the country in which the Mediatrix is used to allow the latter to
set the country-specific parameters (tones, rings, etc.) according to your choice (Figure 11
Selecting the country).
Copyright © 2004 Epygi Technologies, Ltd. All rights reserved.
Increasing Quadro FXO Capability with Mediatrix
Figure 11 Selecting the country
Figure 10
