Error
Name
ID
W-2203 Ink Cartridge error
Ink Cartridge error
W-2204
Insufficient ink remaining amount error Insufficient ink left to perform initial charge.
W-2205
AID all nozzle clogging
W-2301
AID current leak error
W-2302
Auto Ink Detection Board
communication error
W-2303
pulse)
(abnormal test
DX100 Service Manual
Message
Ink Cartridge error
(X)*
Delete all print jobs remaining in the operating system's print
queue.
Please install correct cartridge.
Delete all print jobs remaining in the operating system's print
queue.
Replace the Ink Cartridge.
Cannot perform [Detect Clogging] correctly.
Delete all print jobs remaining in the operating system's print queue.
Perform [Diagnostic Cleaning].
Contact service support if the error continues to occur.
Table 3-3. Warning
Cause (Status)
The corresponding color's Ink Cartridge is not
recognized.
The Ink Cartridge does not have enough ink for
initial ink charge in it.
• AID Unit is broken.
• Main Board is broken.
No communication between the AID Board and the
Main Board.
3.3Troubleshooting by Error Message
Remedy
1. Reset the corresponding color's Ink Cartridge.
2. Replace the corresponding color's Ink Cartridge
with a new one.
3. Connect the FFC that connects the Ink Cartridge
Holder and the Main Board again.
4. Replace the Ink Cartridge Holder with a new
one. (P. 175, P. 179)
Replace the Ink Cartridge with a new one.
1. Check the connection between the AID Unit
and the AID cap and also check its conduction.
(P. 275)
2. Replace the AID Unit if the problem is not
solved. (P. 113)
1. Perform the head cleaning. (P. 222)
2. Check if there is any foreign object in the AID
cap. (P. 275)
3. Check if there is any foreign object attached on
the Print Head. (P. 275)
4. Check the status of the mechanism conducting
and insulating state AID Unit.
5. Replace the AID Unit if the problem is not
solved. (P. 113)
1. Check the FFC connection between the AID
Unit and the Main Board. (P. 275)
2. Replace the AID Unit if the problem is not
solved. (P. 113)
54
(P. 275)
