- Page 1 UNPACKING Unpacking Manual DL600 Installation Manual Rev. C...
- Page 2 C H A P T E R UNPACKING...
- Page 3 1.1 Unpacking 1.1 Unpacking „ The weight of the printer is approximately 120 kg. When C A U T I O N moving or lifting the product, be sure to work with more than three people using the handles shown in the figure 1.1.1 Unpacking the Main Body below.
- Page 4 1.1 Unpacking Table 1-1. List of Cushioning Materials/Inner Packaging Box When removing the upper outer box, be careful of the Front C A U T I O N Cushioning Materials/Inner Packaging Box Quantity Bundled Items Roll of the printer because it rises automatically. Printer Front Padding L Roll Paper Holder Padding R Roll Paper Holder Padding L...
- Page 5 1.1 Unpacking Open the Printer Rear Padding R (3), Printer Rear Padding L (4) Open the Printer Rear Padding R (3), Printer Rear Padding L (4) Unfold the four sides of the “bottom outer box”. and inner packaging box with the manual (7), and confirm that all and inner packaging box with the manual (7), and confirm that all Push the main body and the cushioning materials from the paper feed of the following bundled items are included with the product.
- Page 6 1.1 Unpacking Lift the printer’s right side, and pull out the cushioning material on Lift the paper ejection side of the main body, and pull out the the right side. (Figure. 1-4) cushioning material on the paper ejection side. (Figure. 1-5) Lift the printer's left side, and pull out the cushioning material on Lift the paper feed side of the main body, and pull out the the left side in the same manner as step7.
- Page 7 1.1 Unpacking Remove the protective sheet from the main body. 1.1.2 Unpacking the Optional Items The printer weighs 57.5 kg when packed. So, be extremely C A U T I O N Protective sheet Protective sheet careful when unpacking it. 932 mm 1,380 mm Figure 1-6.
- Page 8 1.1 Unpacking Unbind the two polypropylene straps and remove the “upper outer Remove the eight cushioning materials. container” by lifting it upwards. Remove the two cushioning materials Remove the packaging box (Long Paper Ejection Unit) and packaging box (Conveyer). Upper outer container Cushioning material Packaging box (Long Paper Ejection Unit)
- Page 9 1.1 Unpacking Lift the Sorter and remove it. Hold the packaging box by the handles, and remove the Long Paper Ejection Unit together with the packaging box. Remove the plastic sheets from the Sorter. Remove the two pieces of tape that secure the two cables and remove the Long Paper Ejection Unit from the packaging box.
