FujiFilm DX 400 Quick Reference Manual

Download this manual

Check that the power light is lit.

If the power light is flashing, the printer is

operating. Wait until all operations have

stopped.

Remove the spindle unit.

Do not lift the spindle unit by the knobs

when removing it. The spindle may come

apart, fall and become damaged.

DX 400

Quick Reference Guide

Loading Paper

Remove the scrap paper box and

dispose of the paper scraps. Inspect

the inside of the printer for any stray

paper scraps.

REMOVING THE PAPER CORE:

Raise the knob and remove the left

side media edge guide.

FUJIFILM DIGITAL

PHOTO CENTER

Pull out the roller paper unit.

Raise the knob and remove the

right-side media edge guide and

spindle. Remove the core and

dispose.

VER: 061625

Need help?

Do you have a question about the DX 400 and is the answer not in the manual?

Page 1 FUJIFILM DIGITAL DX 400 PHOTO CENTER Quick Reference Guide Loading Paper Check that the power light is lit. Remove the scrap paper box and Pull out the roller paper unit. dispose of the paper scraps. Inspect the inside of the printer for any stray If the power light is flashing, the printer is paper scraps.
Page 2 ATTACHING NEW ROLL PAPER. Raise the knob on the media edge Insert the spindle into the media guide and place it on the roll paper. guide until the position of the width of the paper being loaded (6’). Remove the new roll paper from its packaging, and stand it on end on a flat Press it until there is no gap between clean, dry surface.
Page 3 Confirm that there are no gaps between INSTALLING THE SPINDLE UNIT Insert the leading edge of the roll the media edge guide and the roll paper, paper into the paper slot until you lower the knob, and then secure the media hear a beep.
Page 4 Push the roll paper unit all the way in. Attach the scrap paper box. The paper feed starts after it is attached. When paper feed stops, the control panel screen displays the paper type settings. Press OK as paper type will not to be changed at any time.
