5 Operation

5.1 Requirements for Successful Operation

The device has been designed for use in a system complying with the PROFINET standard. For successful operation, the controller
must also support all functions and interfaces described in this manual.

5.2 Device Classification

The PROFINET Card is a PROFINET I/O-device and must be managed by an I/O-controller over Ethernet.

5.3 Ensuring Safe and Successful Control

Data written to the device remains in its registers until the data is overwritten or the device is reinitialized. If the soft starter is con-
trolled via parameter 7-1 Command Override or is disabled via the reset input (terminals RESET, COM+), fieldbus commands should
be cleared from the registers. If a command is not cleared, it is re-sent to the soft starter once fieldbus control resumes.

5.4 Feedback LEDs

Port 1 Port 2
Table 2: LED Descriptions
LED name LED state
Power Off
On
Error Off
Flashing
On
Status Off
Flashing
Link x Off
On
TX/RX x Flashing
14 | Danfoss A/S © 2020.12
TX/RX2 TX/RX1 STATUS
LINK 2 LINK 1 ERROR
Description
The device is not powered up.
The device is receiving power.
No error.
Connection not established.
No physical link or slow physical link.
No configuration.
No error.
DCP signal service initiated via the bus.
No network connection.
Connected to a network.
Transmitting or receiving data.
