6.3.6 Bytes 10–63: Extended Information
Table 4: Information from Internal Registers of the Soft Starter
Byte Description
10–11 Version
12–13 Model number
14–15 Reserved
16–17 Reserved
18–19 Starter state
20–21 Current
22–23 Current
24–25 Motor temperature
26–27 Reserved
Danfoss A/S © 2020.12
Bits Details
0–8 Reserved.
9–15
Product type code:
15 = MCD 600.
0–7 Reserved.
8–15 Soft starter model ID.
0–4
0 = Reserved.
1 = Ready.
2 = Starting.
3 = Running.
4 = Stopping.
5 = Not ready (restart delay, restart temperature check, run simulation, reset
input is open).
6 = Tripped.
7 = Programming mode.
8 = Jog forward.
9 = Jog reverse.
5 1 = Warning.
6
0 = Uninitialized.
1 = Initialized.
7
Command source:
0 = Network, timer.
1 = Remote LCP, digital input, clock.
8 Reserved.
9
0 = Negative phase sequence.
1 = Positive phase sequence.
10–15 Reserved.
0–13 Average rms current across all 3 phases.
14–15 Reserved.
0–9 Current (% motor FLC).
10–15 Reserved.
0–7 Motor thermal model (%).
8–15 Reserved.
Packet Structures
