3.4. PSTN configuration
There are 2 ways to connect the Octalarm-Touch to the PSTN:
• standalone;
• Additional telephone devices on the same PSTN line (Fax / Central Office etc.).
The PSTN line can be connected to the Octalarm-
Touch's RJ11 "Line In" connector. In case additional
devices need to be connected to the same PSTN line,
it is very important that no other device can occupy
this line, when the Octalarm-Touch has to call out
an alarm message. By doing so no other device can
interfere with the alarm device.
When an alarm message has to be sent out, all other
PSTN devices are automatically disconnected from
the PSTN line by means of a "Line-Seize" relay.
Caution:
Users must check that the "Line Size" feature is working properly immediately after installation and repeat
this check frequently. This is necessary in order to ensure that the device can initiate a call even if the line
is being used by other devices, such as a phone, answering system, computer modem, etc.
3.5.

GSM module

4.

Setting up the device

4.1.

Initial settings (onboarding)

When you turn on the device for the first time, or after restoring the factory settings, follow the on-screen
instructions to set up your device:
1. Select the preferred device language for:
• Text that is displayed on the device.
• Spoken alarm text.
See chapter "7.2.1. System language" for more information.
2. Select a region and country:
• The location you select determines the time
zone.;
See chapter "7.2.2. Time zone" for more information.
3. Select your preferred keyboard layout;
See chapter "7.2.3. Keyboard" for more information.
4. Set the country code and any dial-out number
and/or lead digits.
See chapter "7.4.3. Country codes" for more information.
To prevent dial-out problems, we recommend
using the default country codes.
5. Change the default Octalarm name to a name that
can be used to distinguish the location.
See chapter "7.3.1. Location name" for more information.
6. Set the installer or administrator of the
device:Complete all fields and follow the on-
screen instructions.
See chapter "5.1. Adding and editing contacts" under Contacts for
more information on the different contact roles.
Manual Octalarm-Touch | Back to
Antenna connector (SMA female).
Maximum antenna gain: +8dBi
index
To use the GSM module, place a SIM-card in the GSM
module and slide the module into place. The SIM card is
placed on the bottom of the GSM module.
The SIM card is placed on the bottom of the GSM
module. The module can then be pushed into the GSM
compartment until it clicks.
