3.

More system information

3.1.

Screen

The screen is made of glass with a touchscreen in the middle as seen in the picture above. Do not use
hard objects on the touchscreen as these will leave scratch marks and potentially couse it to become
inoperable.
To use RFID, place an RFID tag within 10 mm of the RFID reader location.
3.2.

Power

3.3.

Battery

Battery compartiment
1 Velcro fastener
2 Battery connector location
3 Battery label
Manual Octalarm-Touch | Back to
Battery label (Europe)
index
Screen pictograms
1 RFID reader
2 Brand logo
By wrapping the power cable around the S-shaped
pull protector, you can keep the input safe and
protect the and cable against unintentional removal.
When replacing or using a power supply cord not
included by Adésys the power supply cord must
comply with IEC 60227-1.
Place the battery on the battery flat and secure it
tightly with Velcro. Then close the connector.
Caution:
Replacing the battery with an incorrect type may
cause damage to the device and the battery.
Page 7
