Adesys B.V. | Wateringen Index Introduction 1.1. Safety rules and advice for regular testin alarms 1.2. Maintenance 1.3. Storage and transport 1.4. Faults and repair 1.5. Disposal 1.6. Guarantee and liaility Installation 2.1. Mounting Octalarm-Touch 2.2. Connecting Octalarm-Touch System properties further explained 3.1.
• the recycling and/or disposal will have to be done by following the guidelines stated in this quickstart. Battery handling guide • Only use the Adésys Octalarm-Touch type battery. There is a risk of explosion if the battery is replaced by an incorrect type.
Octalarm-Touch. Installation 2.1. Mounting Octalarm-Touch Before connecting the Octalarm-Touch, the unit needs to be mounted on a wall or solid object. The Octalarm-Touch can be mounted by first placing screws in the wall before sliding the mounting holes on the device over them. The screws must be capable of supporting at least 1360 grams. 2.2.
Adesys B.V. | Wateringen 3.4. PSTN configuration There are 2 ways to connect the Octalarm-Touch to the PSTN: • standalone; • Additional telephone devices on the same PSTN line (Fax / Central Office etc.). The PSTN line can be connected to the Octalarm- Touch’s RJ11 “Line In” connector. By doing so no other device can interfere with the alarm device. In...
If this fails (for example if the message ‘Portal not reachable’, ‘payment failed’ etc. is shown), use http:// portal.octalarm.com Chapter 7.1.2 contains more information on activating Octalarm Connect. The initial setup is now completed. Pressing ‘Ready’ activates the Octalarm-Touch. 4.2. Dashboard (start sreenm) Interface status...
Log in By placing a check mark, this contact is given the right to log in on the Octalarm-Touch. Next, you assign an authorisation, a user name and password. You can also link a tag. The tag allows logging in without a password.
For Email, SMS and pager an acceptance time is used. This is the time period within which the contact can call back or send a text message to the Octalarm-Touch. The contact must call the mobile phone number of the Octalarm-Touch. Day schedule: Day/night/weekend times Here you can select according to which schedule the contact should receive an alert.
The alarm text is the text used in the alarm messages and in voice calls. When you press the ‘Play’ button the Octalarm-Touch device speaks the alarm text. If the spoken text is not clear, it is best to enter the alarm text phonetically.
Adesys B.V. | Wateringen Waiting time between repetitions Between the number of repetitions the Octalarm-Touch waits the number of minutes you enter here. Buzzer By default, the buzzer is enabled. If you uncheck the ‘On upon alarm’ field, the buzzer (and any external buzzer) will no longer be used for this alarm. 6.1.2. Link or create call list (right side) •...
Changing the time zone • Go to ‘Settings’. • In the navigation, scroll to ‘Time zone’. • Press ‘Change’. • Select the correct zone. • Press ‘Save’. Manual Octalarm-Touch | Back to index Page 12...
• Press ‘Save’. It is not possible to change the weekend. 7.2.5. Voice The voice used by the Octalarm-Touch can be set. If the used voice is not clear enough, another voice can be set. Changing the voice • Go to ‘Settings’.
The installer and the administrator can clear all settings of the Octalarm-Touch. This feature is useful when, for example, the Octalarm-Touch is taken to another location. The log will not be deleted when the system is reset to the factory settings.
Interfaces 7.4.1. GSM The Octalarm-Touch is supplied with a GSM module with a SIM card. For more information about the GSM module, see chapter “3.5. GSM module”. The SIM card is disabled by default and can be activated during onboarding. With this process the end user enables the Octalarm Connect service.
If the international format is not used or if a PSTN connection is used that does not support this format, it is important that the correct country code is set. The Octalarm-Touch contains a list of default codes per country. The country code can also be set manually.
Adesys B.V. | Wateringen 7.4.4. VoIP Voice-over IP is a way to make a call via the Internet. The Octalarm-Touch uses the SIP protocol for this. To use the 24/7 monitored Adésys servers, you must activate Octalarm Connect via the included SIM card.
SMTP server Own SMTP server SMTP settings SMTP server address Enabled | Disabled* * delete as appropriate SMTP port Authentication Enabled | Disabled* * delete as appropriate User name Password Manual Octalarm-Touch | Back to index Page 18...
To use a static IP address, you can set DHCP to manual in the ‘Ethernet’ screen. If you then enter an IP address, the Octalarm-Touch will only use that IP address. If this does not allow the Octalarm-Touch to connect correctly, it is important to check this IP address, or you may have to use DHCP.
Octalarm- Touch will repeat the alarm after the set waiting time, as outlined in chapter “6.1.1. Alarm settings (left side)”. Manual Octalarm-Touch | Back to index Page 20...
0°C ... +50°C Storage Temperature 0°C ... +85°C Relative humidity 20% - 85% (noncondensing) IP code IP42 Operating altitude Up to 2000 metre Regulations EN 301 489-1 V2.1.1 / EN301 489-3 V1.6.1 EN 62368 Manual Octalarm-Touch | Back to index Page 21...
Page 22
Molenweer 4 +31 174 794022 2291 NR Wateringen www.adesys.nl The Netherlands info@adesys.nl More information on the website Version 09-2019...
