11.2. EM-8001 (external IO)

System properties
Contact inputs
Relay contacts
I/O bus
Power supply (external)
Life expectancy
(Calculated MTBF)
Enclosure and operating conditions
Enclosure
Dimensions (L x W x H)
Weight
Operating temperature
Storage Temperature
Relative humidity
IP code
Operating altitude
Regulations
EMC
Manual Octalarm-Touch | Back to
Voltage
Impedance
V
il
V
ih
Note
Max load
Cable type
Length:
Conclusion
Power consumption
Imax
Input voltage range
over 10 years
DIN rail (TS35) mounting and wall mounting
71 x 90 x 33 (mm)
135 g
-30°C ... +70°C
-40°C ... +85°C
20% - 85% (non-condensed)
IP30
Up to 2000 metres
Emission: EN 55032 (2012) + AC (2013), class B
Immunity: EN 55024 (2010), 10Vrms
index
30VAC or 30VDC max
10k pull-up to 12Vdc
<2V
>2.5V
Input can be a contact to GND or a voltage
30VDC / 1A, 30VAC / 1A (resistive load)
RS485 Modbus cable (22 AWG), see chapter 10.1.2 for
more information
<1km
120Ω
DC: 1 Watt
AC: 1.5 Watt (rms), single-sided rectified
5 Watt (charging capacitor)
0.2A
8 - 30VDC
20 - 30VAC
