BreezeACCESS™
LB System Manual
November 2003
P/N 213559

Advertisement

Table of Contents
loading

Related Manuals for Alvarion BreezeACCESS LB

Summary of Contents for Alvarion BreezeACCESS LB

  • Page 1 BreezeACCESS™ LB System Manual November 2003 P/N 213559...
  • Page 2 Error! No text of specified style in document. BreezeACCESS LB System Manual...
  • Page 3 (14) months from the date of shipment of a given Product to Purchaser (the “Warranty Period”). Alvarion will, at its sole option and as Purchaser’s sole remedy, repair or replace any defective Product in accordance with Alvarion’ standard RMA procedure.
  • Page 4 (b) PURCHASER’S SOLE REMEDY FOR BREACH OF THE EXPRESS WARRANTIES ABOVE SHALL BE REPLACEMENT OR REFUND OF THE PURCHASE PRICE AS SPECIFIED ABOVE, AT ALVARION’S OPTION. TO THE FULLEST EXTENT ALLOWED BY LAW, THE WARRANTIES AND REMEDIES SET FORTH IN THIS AGREEMENT ARE EXCLUSIVE AND...

  • Page 5: Limitation Of Liability

    (c) ALVARION SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT IN THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY PURCHASER’S OR ANY THIRD PERSON'S MISUSE, NEGLIGENCE, IMPROPER INSTALLATION OR IMPROPER TESTING, UNAUTHORIZED...
  • Page 6 Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. BreezeACCESS LB System Manual...

  • Page 7: Important Notice

    It could also void the user’s authority to operate the equipment. Some of the equipment provided by Alvarion and specified in this manual, is manufactured and warranted by third parties. All such...

  • Page 8: About This Manual

    Chapter 5 – Wireless Broadband, describes the benefits and advantages of a BreezeACCESS LB system. It also describes the Link Budget Tools and various scenarios. Appendix A – Glossary of Terms, includes a tabular list of...

  • Page 9: Table Of Contents

    23 dBi, 9 Degree Antenna Specifications ... 1-8 28 dBi, 4.5 Degree Antenna Specifications ... 1-9 Chapter 2 - Installation ...2-1 Installation Requirements... 2-2 Packing List: BreezeACCESS LB System... 2-2 The Indoor Unit at a Glance ... 2-3 System Status Indicators... 2-3 Wireless Status Indicators ... 2-4 Ethernet Status Indicators ...
  • Page 10 System Logs ... 3-25 Chapter 4 - Diagnostics and Troubleshooting ... 4-1 Diagnostics Using the Front Panel... 4-2 System Power ...4-3 System Fault ...4-3 Wireless Link ...4-4 Wireless Signal ...4-5 Ethernet Link ...4-6 Ethernet Collision ...4-7 BreezeACCESS LB System Manual...
  • Page 11 Appendix A - Glossary of Terms ... A-1 Appendix B - Peak Power Spectral Density ... B-1 Power spectral density as measured for the BreezeACCESS LB system ... B-2 Appendix C - CLI Commands ... C-1 General CLI Commands... C-2 General Commands...
  • Page 12 Contents Appendix E - Antenna Assembly... E-1 Antenna Assembly Drawings... E-2 28 dBi, 4.5º Antenna - Vertical Mount Assembly... E-2 23 dBi, 9º, Antenna - Vertical Mount Assembly... E-3 BreezeACCESS LB System Manual...
  • Page 13 Figure 2-5: Outdoor Unit and Antenna with Vertical Mount ... 2-6 Figure 2-6: Radio Deployment Options... 2-8 Figure 2-7: BreezeACCESS LB System Installation... 2-9 Figure 2-8: Indoor Unit Connected To Switch/Router/Hub ... 2-10 Figure 2-9: Indoor Unit Connected To Host Computer... 2-10 Figure 2-10: Indoor unit LAN Ethernet Port RJ-45 Jack...
  • Page 14 Figures Figure 3-9: SNMP BreezeACCESS LB General Information ...3-15 Figure 3-10: System Status ...3-17 Figure 3-11: Software Upgrade ...3-21 Figure 3-12: Status of the Upgrade File Transfer ...3-22 Figure 3-13: System Password...3-23 Figure 3-14: Options Key...3-24 Figure 3-15: System Log Screen ...3-25 Figure 4-1: Front Panel Status LEDs ...4-2...
  • Page 15 Tables Table 1-1 Radio Specifications ... 1-3 Table 1-2: Data Communications Specifications ... 1-4 Table 1-3: Outdoor Unit to Indoor Unit Communications ... 1-5 Table 1-4: Communication and Management ... 1-5 Table 1-5: Interfaces ... 1-6 Table 1-6: Electrical Mechanical and Environmental... 1-7 Table 1-7: Standards Compliance and General...
  • Page 16 Tables This page left intentionally blank. BreezeACCESS LB System Manual...

  • Page 17: Chapter 1 - System Description

    Chapter 1 - System Description In this Chapter This chapter introduces BreezeACCESS LB, and includes the following sections: General, on page 1-2, provides a general introduction of the entire BreezeACCESS LB system System Components, on page 1-2 describes the highlights of the...

  • Page 18: Introducing Breezeaccess Lb

    BPSK, QPSK, 16 and 64 QAM to maximize data rate up to 72 Mbps, and improve spectral efficiency. The BreezeACCESS LB system is a Class A digital device for use in a commercial, industrial or business environment. System Components The BreezeACCESS LB system is comprised of an Indoor Unit (LB NI-01) and an Outdoor Unit (LB RE-01).

  • Page 19: Networking Equipment

    Networking Equipment The BreezeACCESS LB system point-to-point is connected to the backbone through standard data communication and telecommunication equipment. The 10/100BaseT ports of the system can be connected directly to a multi-port router or to an Ethernet switch connected to a router.

  • Page 20: Data Communication

    Table 1-2: Data Communications Specifications Parameter Standard Compliance VLAN support Layer-2 Traffic Prioritization Layer-3 Traffic Prioritization BPSK QPSK QPSK Value IEEE 802.3 CSMA/CD Transparent to IEEE 802.1q IEEE 802.1p prioritization Transparent to IP ToS according to RFC791 BreezeACCESS LB System Manual...

  • Page 21: Outdoor Unit To Indoor Unit Communication

    IF Frequency IF cable Impedance Maximum IF cable Attenuation Cable Length * RG6U and RG11U cables must be rated up to 2.5 GHz operation. Contact Alvarion for specific cable manufacturer and connector) Communication and Management Table 1-4: Communication and Management Parameter Local &...

  • Page 22: Interfaces

    Chapter 1 - System Description Interfaces Interface Outdoor Unit F-Type connector Antenna N-Type connector Ethernet Power 24 VDC from indoor unit via the IF cable Table 1-5: Interfaces Indoor Unit F-type connector Auto-sensing 10/100Base-T (RJ-45) with 4 LEDs AC jack BreezeACCESS LB System Manual...

  • Page 23: Electrical Mechanical And Environmental

    ……………………………………… Antenna, 23 dBi, 9° …………………………...…………… IF Cable, F Male/F Male, RG6, 100 ft…..………………………………… Introducing BreezeACCESS LB LB NI-01 Indoor Unit 110/220 VAC, 50/60 Hz, 39 W max. 17” x 12” x 1.75” 431.8 mm x 304.8 mm x 44.45 32°F to 131°F...

  • Page 24: Standards Compliance And General

    ETSI EN 302 085 V1.1.2 (2001-02) Range 1TS1- TS3 -32 dB (max) DC Grounded (L x W x D) 12 x 12 x 1 in / 305 x 305 x 25 mm 3.3 lb / 1.5 kg BreezeACCESS LB System Manual...

  • Page 25: 28 Dbi, 4.5 Degree Antenna Specifications

    Cross Polarization Side lobe Level F/B Ratio Lightning Protection Mechanical Dimensions Weight Connector Introducing BreezeACCESS LB Value N-Type Female -45°C to +70°C / -49°F to + 158°F 137 mph / 220 km/hr 1 in / 25 mm Value Planar Array ETSI EN 302 085 V1.1.2 (2001-02)
  • Page 26 Table 1-9: 28 dBi, 4.5 Degree Antenna Specifications Parameter Temperature (operating) Wind Load (Survival) Radial Ice Load 1-10 Value -45°C to +70°C / -49°F to + 158°F 137 mph / 220 km/hr 1 in / 25 mm BreezeACCESS LB System Manual...

  • Page 27: Chapter 2 - Installation

    LED’s, on Equipment Location Guidelines, on page 2-7, provides information on the best locations to deploy the BreezeACCESS LB components in order to achieve the optimal reception and transmission quality. Installing the Indoor...

  • Page 28: Installation Requirements

    Chapter 2 - Installation Installation Requirements This section describes all the supplies required to install the BreezeACCESS LB system components and the items included in each installation package. Packing List: BreezeACCESS LB System The BreezeACCESS LB system comes packaged with the following major...

  • Page 29: The Indoor Unit At A Glance

    Reset – depressing the “Reset” button recessed in the front panel can hard reset the system. The reset button is used to reactivate the BreezeACCESS LB unit in the event that it is functioning improperly or is in a state of suspension.

  • Page 30: Wireless Status Indicators

    Figure 2-2: Front Panel – Wireless Link – The “Link” LED lights solid and green when the radio link to the remote BreezeACCESS LB unit is established. The LED will turn off if the link is lost. Signal – The “Signal” LED lights solid green if the system is operating at the configured Modulated Burst Rate.

  • Page 31: The Lan Interface

    Installation Requirements 100 – The “100” LED lights solid and green when the Ethernet port is operating at 100 Mb/s. The LED will not illuminate if the port is operating in 10 Mb/s mode. The Ethernet port automatically selects the speed through auto-negotiation with either the host computer/server or router/switch.

  • Page 32: The Outdoor Unit & Antenna At A Glance

    The vertical mount bracket can accommodate 1 ¾” to 4 ½” (4.45 cm – 11.45 cm) masts found on many commercial tower installations Before connecting the BreezeACCESS LB system, it is important to review the safety tips provided at the beginning of this manual.

  • Page 33: Equipment Location Guidelines

    Equipment Location Guidelines Equipment Location Guidelines The first step in installing the BreezeACCESS LB system is to conduct a general site survey. Although the installation steps are relatively straightforward, they do involve some construction and electrical work, which is best performed by a professional installer. The following site survey steps should be followed: Determine the optimum location.

  • Page 34: Figure 2-6: Radio Deployment Options

    Chapter 2 - Installation The BreezeACCESS LB system is also designed to operate in near-line- of-sight (NLOS) conditions, as a result of the OFDM technology incorporated in the system. Under NLOS conditions, the best method of obtaining a proper RF link is to evaluate different antenna orientations and choosing the one with the best Signal to Noise (SINADR) ratio and highest Received Signal Strength (RSSI) value.

  • Page 35: Figure 2-7: Breezeaccess Lb System Installation

    Note that the IF cable provided is meant for exterior use, and should be used for only minimal interior runs to connect to the LB NI- 01 Indoor unit. Also, note that the BNC and serial connectors are for future use. Figure 2-7: BreezeACCESS LB System Installation...

  • Page 36: Installing The Indoor Unit

    The LB NI-01 Indoor unit may also be connected directly to the host computer, as shown in Figure 2-9. In this configuration, a straight- through CAT 5/UTP cable is required to complete the connection. Figure 2-9: Indoor Unit Connected To Host Computer 2-10 BreezeACCESS LB System Manual...

  • Page 37: Figure 2-10: Indoor Unit Lan Ethernet Port Rj-45 Jack

    To help you establish other implementations that are not addressed in this manual, Figure 10 provides an illustration of the pin-out for the LB NI-01 Indoor unit LAN interface. Warning: do not connect a telephone cable to the LB NI-01 LAN interface, as this will damage the LB NI-01 Indoor unit.

  • Page 38: Installing The Antenna And Outdoor Unit

    Figure 2-11: Antenna Polarization Arrow For building mounts, ensure the surface to which the mounting bracket will be attached is structurally sound, flat and vertical (use a level). Ensure that the installation can withstand wind loading. 2-12 BreezeACCESS LB System Manual...

  • Page 39: Installing The Outdoor Unit

    The Vertical mount bracket for the antenna can accommodate 1 ¾” to 4 ½ OD masts. Installing the Outdoor Unit The following sections describe how to install the Outdoor Unit, including pole mounting the unit, grounding and IF cables. The Outdoor Unit can be mounted on a pole using one of the following options: Special brackets and open-ended screws are supplied with each unit.

  • Page 40: Connecting The Antenna Cable

    Connecting the Ground and IF Cables The ground terminal, which is marked with the symbol and the IF cable connector (marked IF) are located on the bottom panel of the unit, as shown in Figure 2-14. 2-14 BreezeACCESS LB System Manual...

  • Page 41: Running The If Cable

    Figure 2-14: Outdoor Unit Top Panel To connect the ground cable: 1. Connect one end of a grounding cable to the ground terminal and tighten the ground screw firmly. 2. Connect the other end of the ground cable to a ground connection. NOTE It is recommended that you switch OFF the power of the Indoor Unit prior to connecting or disconnecting the IF cable to or from the Outdoor Unit.
  • Page 42 4. Connect the IF cable to the F-type female connector located on the back of the LB NI-01 Indoor unit. The connector should be tightened finger-tight and then tightened an additional 1/8 of a turn 2-16 BreezeACCESS LB System Manual...

  • Page 43: Aligning The Antenna

    Aligning the Antenna Once the antenna is mounted and the LB NI-01 Indoor unit is installed, the antenna must be aligned in both the azimuth and elevation planes. Elevation alignment is accomplished by loosening the two bolts attached to the mounting bracket, as shown in Figure 15 below, and angling the antenna so it is aligned towards the remote BreezeACCESS LB unit.
  • Page 44 Chapter 2 - Installation IMPORTANT The BreezeACCESS LB System is used as a fixed wireless Ethernet bridge that is to be professionally installed by a trained professional installer or sub- contractor. For compliance with FCC RF exposure requirements, the transmitting antenna is required to be mounted outdoors on the building roof or antenna tower and located at a distance of more than 2.1 meters (6.5 feet) from the transmitting...

  • Page 45: Chapter 3 - Commissioning

    Chapter 3 - Commissioning About this Chapter This is normal Preliminary Configuration, on page 3-2, describes how to connect using hypertext transfer protocol (HTTP) management. System Configuration, on page 3-8, describes how to use the Web Interface to set Ethernet and Wireless parameters. General Information, on page 3-15, provides a summary view of the general information screen.

  • Page 46: Preliminary Configuration

    Local Unit Management This section describes the procedures for configuring and operating the BreezeACCESS LB NI-01 Indoor unit. System Configuration and Operation via the Web Interface 1. Connect a PC to the Ethernet port, using a straight cable to connect to the LB NI-01 indoor unit and a crossed cable to connect to network device (switch, router, hub).

  • Page 47: Figure 3-1: Web Interface

    (set from the factory) for both the user name and password for the User is user. This login denies access to the Configuration, Upload, and BreezeACCESS LB Options screens. Refer to the System Password screen to change the password for future sessions.

  • Page 48: System Configuration And Operation Via Telnet

    LB NI-01 indoor unit via Telnet using the command line interface (CLI). To connect to the indoor unit, Telnet to the IP address of the indoor unit (default address shown below). BreezeACCESS LB System Manual...

  • Page 49: System Configuration And Operation Via Snmp

    SNMP. The latest LB NI-01 MIB file may be obtained by contacting your Alvarion certified partner or system integrator, or by downloading it from the ‘Support’ area of our website.

  • Page 50: System Configuration And Operation Via Console Port

    Set the PC/Terminal to emulate a VT-52 or VT-100 terminal. Use the following port settings: Bits Per Second: 9600 Data Bits: 8 Parity: None Stop Bits: 1 Flow Control: Hardware Hit the ‘Enter’ key – the LB NI-01 prompt will appear. BreezeACCESS LB System Manual...

  • Page 51: Figure 3-5: 9-Pin D Sub Connector (Male)

    The following diagram shows the 9 PIN D-SUB male connector pin-out at the LB NI-01 Indoor unit: Figure 3-5: 9-PIN D SUB Connector (Male) Table 3-1: 9-PIN D SUB Connector Pin-Outs (Male) Name RS232 NOTE RS232 column is RS232 circuit name. V.24 column is ITU-TSS V.24 circuit name.

  • Page 52: System Configuration

    It is important to ensure that all fields on the System Configuration page are filled out properly for local and remote BreezeACCESS LB units. Errors in these fields will result in the inability to establish a communication link. Please read this section carefully to ensure a quick, trouble-free deployment.

  • Page 53: Ethernet Configuration

    LB NI-01 Indoor unit, which can consist of any combination of letters and numbers up to 20 characters in length. The default name for the BreezeACCESS LB system from the factory is set to WEB01. The device name remains with the system, even during power off state.

  • Page 54: Figure 3-7: Snmp Configuration

    To delete an existing community, select the community from the pull down menu and click ‘Delete’. It is not possible to delete the "public" SNMP community. However, its access level can be changed. Figure 3-8: SNMP Community Configuration BreezeACCESS LB System Manual 3-10...

  • Page 55: Community Configuration

    SNMP requests. Trap Configuration Trap Enable: When the SNMP Agent in the BreezeACCESS LB detects an error condition, a message known as a trap is sent. A Trap Host is an IP workstation/server that is set up to receive SNMP trap messages.

  • Page 56: Wireless Configuration

    3-12 Frequency 5735 MHz 5745 MHz 5755 MHz 5765 MHz 5775 MHz 5785 MHz 5895 MHz 5805 MHz 5815 MHz Chapter 5 – Wireless BreezeACCESS LB System Manual...

  • Page 57: Table 3-3: Max. Operational Power Per Channel (Dbm) Vs. Modulation

    Adaptive Modulation: checking this box sets the system to operate in adaptive modulation mode. It is recommended to keep the BreezeACCESS LB in this mode so that the system can automatically change the modulation scheme to the highest possible order, based on measured RF performance.
  • Page 58 Chapter 3 - Commissioning Master Mode: Sets one of the BreezeACCESS LB units to serve as the master system, while the other BreezeACCESS LB unit assumes a slave role. There are no consequences related to setting either unit to serve as the master or slave for this version release.

  • Page 59: General Information

    Figure 3-9: SNMP BreezeACCESS LB General Information Located at the top of this page is a graphic interface providing a real- time view of the BreezeACCESS LB unit front panel (refreshed every 30 sec.), plus a summary of general information related to the configuration and status of the local unit.
  • Page 60 Uncoded Burst Rate [Mb/s]: The actual current Uncoded Burst rate for the link. Obtaining a 64 QAM license key (see page 3-24) raises the available Modulated Burst Rate from the default 36 Mbps to 54 Mbps BreezeACCESS LB System Manual 3-16...

  • Page 61: System Status

    System Status System Status Clicking on System Status in the main menu will load this page, which provides General Information, Ethernet LAN Statistics and Wireless Statistics, as shown in Figure 3-10 below. Figure 3-10: System Status General Information: Identical to the information found on the General Information page, with the addition of: RF Channel Frequency: Specifies the center frequency of the channel in use.

  • Page 62: Table 3-4: Rf Status Error Codes

    Table 3-4: RF Status Error Codes Error Code LB NI-01 Indoor unit Communication Error Over IF PLL Error Cable 0 - NO ERRORS 3-18 LB RE-01 LB RE-01 Power Low DC Voltage Supply Fault At LB RE-01 High Temp. Input Warning BreezeACCESS LB System Manual...

  • Page 63: Error Details

    Error Details LB NI-01 PLL Error: The PLL (Phase Locked Loop) section within the LB NI-01 Indoor unit experienced an error. The System Fault LED may light. Action: Try resetting the unit. Communication Error Over IF Cable: Communication between the LB NI-01 Indoor unit and the LB RE-01 Outdoor unit failed.
  • Page 64 LB NI-01, due to degradation in the RF link. Reset Statistics: Click this button to clear the data for the Wireless and Ethernet LAN Statistics on this page. You will be prompted for your password. BreezeACCESS LB System Manual 3-20...

  • Page 65: Software Upload

    Software Upload Software Upload The upload screen as shown on next page is used to upgrade the existing software load of the LB NI-01 indoor unit with new software stored in a binary file on the server or host computer. Note the LB NI-01 indoor unit contains two memory pages for storing two versions of the software/firmware.

  • Page 66: Figure 3-12: Status Of The Upgrade File Transfer

    LB NI-01 Indoor unit will reject the new software load and provide a warning that the upgrade was unsuccessful. In this case, the operator will need to repeat the upgrade process. Figure 3-12: Status of the Upgrade File Transfer BreezeACCESS LB System Manual 3-22...

  • Page 67: System Password

    System Password System Password The factory default password for the system is "admin" for the administrator’s ID and “user” for the User’s ID. To change the password, click on System Password from the main menu and apply a new value in the New Password field (see Figure 3-13) using any alphanumeric combination.

  • Page 68: Product Options

    The product options License Key is personalized to each unit’s MAC address. Please ensure that the correct MAC address is provided when requesting a key from your local Alvarion distributor. Enter the key (Case Sensitive), ensure it is correct, and click "Send Key".

  • Page 69: System Logs

    System Logs The System Logs page, shown below, provides a list of the last forty messages recorded by the LB NI-01 Indoor unit, describing either system activity or errors that have occurred. Figure 3-15: System Log Screen The logs will also indicate if the following transactions were successfully completed: Save Configuration –...

  • Page 70: Table 3-5: Log Messages And Descriptions

    The memory area containing the system configuration has been corrupted. Default parameters loaded. The latest configuration parameters have not been successfully saved. In this case, repeat the save configuration process to try to resolve the problem. BreezeACCESS LB System Manual...
  • Page 71 Table 3-5: Log Messages and Descriptions Log Message 203-Another upgrade in progress! 204-Invalid upgrade parameters! 205-Upgrade failed! 206-Password changed unsuccessfully! 207-Timeout on reading data packet! 209-TFTP error received! 210-Error: TFTP unknown message! 211-Error: while writing flash! 212-Error firmware configuration! 213-Firmware programming failed! 214-Error while loading version control!
  • Page 72 Choose another name. MIB construction process generated an error. Try to reset the indoor unit. If problem persists, contact customer support. EEPROM memory was corrupted and the SNMP configuration couldn't be loaded. Default SNMP configuration was loaded. BreezeACCESS LB System Manual...
  • Page 73 Table 3-5: Log Messages and Descriptions Log Message 226-Error while saving SNMP configuration! Description SNMP configuration saving process was not successful. Try again. If problem persists, contact customer support. System Logs 3-29...
  • Page 74 Chapter 3 - Commissioning This page left intentionally blank. BreezeACCESS LB System Manual 3-30...

  • Page 75: Chapter 4 - Diagnostics And Troubleshooting

    In this Chapter This chapter provides basic diagnostic and troubleshooting procedures to help solve problems that may occur with the BreezeACCESS LB system. If, after reading this chapter, you are unable to get the system operating properly, please contact your local Alvarion representative.

  • Page 76: Diagnostics Using The Front Panel

    Chapter 4 - Diagnostics and Troubleshooting Diagnostics Using the Front Panel The front panel of the BreezeACCESS LB NI-01 Indoor unit comprises three sets of status LEDs, grouped under the headings System, Wireless and Ethernet, to help with first level diagnoses of problems encountered with the unit.

  • Page 77: System Power

    System Fault Check the IF cable. A short or long reset may fix the problem. If not, contact your local Alvarion representative. Also, refer to the RF Status codes in Table 3-4 on page 3-18, as well as the Log file.

  • Page 78: Wireless Link

    LB NI-01 Indoor unit. Clear path or re- locate antennas. Repair or replace LB RE-01 Re-align the antenna. Properly secure cables. Repair or replace LB NI-01 Indoor unit. Make sure both units are operating on the same RF channel. BreezeACCESS LB System Manual...

  • Page 79: Wireless Signal

    Wireless Signal It will flash when the system is operating at a lower order modulation scheme (i.e., the Actual Modulated Burst Rate is lower than the configured Modulated Burst Rate). If the system cannot maintain the lowest modulation scheme due to link errors, the Signal LED will turn off.

  • Page 80: Ethernet Link

    Otherwise, to connect the LB NI-01 Indoor unit to a switch or router, ensure a crossover cable is used. Repair or replace faulty units. Try short reset or long reset. BreezeACCESS LB System Manual...

  • Page 81: Ethernet Collision

    Ethernet Collision However, if the LED flashes constantly, or flashes when the LB NI-01 indoor unit is connected to a switch or router, there is a serious problem with the LAN connection. Some possible causes include: Table 4-5: Ethernet Collision Diagnostics Symptom Possible Problem Link Collision...

  • Page 82: Troubleshooting Using The Web Interface

    LB NI-01 Indoor unit to the default value. Warning: performing a long reset will restore the BreezeACCESS LB NI- 01 Indoor unit’s IP address (192.168.25.2) and Subnet Mask (255.255.255.0) to the factory default value...

  • Page 83: Table 4-6: Web Interface Diagnostics

    Table 4-6: Web Interface Diagnostics Symptom Possible Problem Home page (General Incorrect IP address Information) cannot be and/or Subnet Mask. accessed. Problems with host computer, or LB NI-01 Indoor unit. Host PC ARP table is incorrectly configured Troubleshooting using The Web Interface Solution Perform a ping test from the host computer...
  • Page 84 Chapter 4 - Diagnostics and Troubleshooting This page left intentionally blank. BreezeACCESS LB System Manual 4-10...

  • Page 85: Chapter 5 - Wireless Broadband

    Greater distances Quicker time to market Greater portability The BreezeACCESS LB system functions logically as a transparent bridge, providing all the benefits of a converged IP network, i.e., "IP everywhere". A converged network allows operators to reduce network build-out costs significantly by employing standard IP appliances...

  • Page 86: Who Can Benefit From The Breezeaccess Lb System

    Enterprises Educational Institutions and Campuses Carriers The BreezeACCESS LB system will provide benefits to both Incumbent and Competitive Local Exchange Carriers (ILECs and CLECs, respectively). Although ILECs own and provide services over wireline infrastructures within a specific geographical area, they are faced with the challenges of reaching outlying regions suffering from poor to no service.

  • Page 87: Internet Service Providers

    Who Can Benefit From The BreezeACCESS LB System? Internet Service Providers The BreezeACCESS LB system is perfect for ISPs looking to provide cost-effective broadband solutions to demanding business customers including Small Office Home Office (SOHO) and Small to Medium sized Enterprises (SME) located just outside of the downtown core, where there is a lack of infrastructure.

  • Page 88: Enterprises

    BFW systems serving as an important enabler in bringing Internet content to the student body. Fixed wireless systems such as the BreezeACCESS LB provide a cost effective means of creating a backbone for connecting existing and new campus buildings to the educational infrastructure to support distance learning and two-way interactive training.

  • Page 89: The Breezeaccess Lb Advantage

    The BreezeACCESS LB Advantage The Alvarion BreezeACCESS LB system includes several key features to mitigate the effects of interference arising from other systems operating co-channel in the vicinity, as well as coping with propagation anomalies such as multipath. These features include:...
  • Page 90 Chapter 5 - Wireless Broadband In addition to the anti-interference features described above, the BreezeACCESS LB NI-01 Indoor unit also holds several other competitive advantages: High Data Rates High Bandwidth Efficiency Long Reach and Wide Coverage Higher Power Efficiency "Over-the-Air" Security.

  • Page 91: Wireless Facts

    The Link Budget Tool Alvarion has available a Link Budget Tool to help characterize the range performance of the BreezeACCESS LB NI-01 Indoor unit for LOS (line of sight), OLOS (optical line of sight) and NLOS conditions, including various system parameters. The Link Budget Tool can be obtained by contacting your Alvarion certified partner or system integrator.

  • Page 92: Table 5-1: Modulation Scheme Vs. Data Rate

    Gtx is the transmit antenna gain in dB FSL is the free space loss attenuation in dB, and Grx is the receive antenna gain in dB table below describes the net Over The Air Rate Modulated Burst Rate (Mbps) (Mbps) BreezeACCESS LB System Manual...

  • Page 93: Figure 5-4: Fresnel Zone Obstruction

    The FSL value is dependent on the range between the LB NI-01 Indoor units, the type of terrain over which the link is deployed, and whether or not the link is operating line of sight (LOS), optical line of sight (OLOS) or near-LOS (NLOS).

  • Page 94: Figure 5-5: Fresnel Zone Radius Calculation

    Engineers (IEEE) and International Telecommunications Union (ITU), who are chartered with developing standardized calculations. The Alvarion Link Budget Tool is built upon these formulas; however, it is important to bear in mind that the calculations are an estimate only, with relatively large standard deviations (5-15 dB) depending on the exact deployment scenario and obstacle characteristics.

  • Page 95: Table 5-2: Availability Versus Outage Time

    99.99%. The tool automatically calculates the estimated required fade margin over distance to achieve this availability. A key advantage of the Alvarion product is that it features a transmission correction scheme called Automatic Repeat Request (ARQ). The ARQ algorithm essentially detects when a packet(s) has been lost, due to fading, and makes a request to the remote system to re-transmit the lost packet(s).

  • Page 96: Figure 5-6: Link Budget For 64 Qam ¾ Code Rate

    Chapter 5 - Wireless Broadband A sample link budget is shown in Figure 5-6 for the BreezeACCESS LB system operating at 72 Mbps, providing a net burst throughput of 54 Megabits per second (Mbps). This provides an average throughput of 43 Mbps to the Ethernet port.

  • Page 97: Figure 5-7: Fade Margin Graph Los, Olos And Nlos

    Wireless Facts Figure 5-7: Fade Margin Graph LOS, OLOS and NLOS The graph assumes a fade margin of 3 dB. The effects of rain at bands are negligible, hence are not included in the link budget. It is important to note the link calculation assumes that the Earth’s curvature is not blocking the propagation path.

  • Page 98: Table 5-3: Radar Horizon Ranges, Different Terminal Heights H1 & H2

    5-14 35.4 38.9 42.0 44.7 40.8 44.3 47.3 50.1 44.9 48.4 51.4 54.2 48.4 51.9 54.9 57.7 51.4 54.9 58.0 60.7 54.2 57.7 60.7 63.5 56.8 60.2 63.3 66.1 BreezeACCESS LB System Manual 47.3 52.6 56.8 60.2 63.3 66.1 68.6...

  • Page 99: Deployment Scenarios

    (same rooftop), and adjacent area. Co-located Deployments It is possible to deploy more than one BreezeACCESS LB system from the same rooftop to support multiple links, however, it is important to consider issues that may arise from co-channel and adjacent channel interference.

  • Page 100: Adjacent Area Deployments

    Users 3 and 4, on the other hand, can operate co-channel since they are outside the narrow beam width of both LB NI-01 Indoor units. Narrow beam widths are one feature of the BreezeACCESS LB to help address potential interference. Figure 5-9: Deployment Scenarios 5-16...

  • Page 101: Appendix A - Glossary Of Terms

    Appendix A - Glossary of Terms...
  • Page 102 Decibels in milliwatts Dynamic Host Configuration Protocol. A DHCP server will automatically issues IP addresses within a specified range to devices on a network. An antenna that concentrates transmission power into one direction. BreezeACCESS LB System Manual...
  • Page 103 Table -A-1: Glossary of Terms Term Encryption Ethernet Gain Gateway Hertz (Hz) IP (Internet Protocol) Isotropic IXC (Inter-exchange Carrier) LAN (Local Area Network) LEC (Local Exchange Company) Description For the purposes of privacy, the transformation of data into an unreadable format until reformatted with a decryption key.
  • Page 104 (error detection and correction bits). Provides for the transmission of data through a communications channel by defining the electrical, mechanical, and procedural specifications. Point to Point Quadrature Amplitude Modulation Quadrature Phase Shift Keying BreezeACCESS LB System Manual...
  • Page 105 Table -A-1: Glossary of Terms Term Receiver Sensitivity SINADR TCP/IP (Transmission Control Protocol/Internet Protocol) TFTP UNII Description A measurement of the weakest signal a receiver can receive and still correctly translate it into data. Radio Frequency Receiver Signal to Noise Ratio Signal to noise and distortion ratio.
  • Page 106 Appendix A - Glossary of Terms This page left intentionally blank. BreezeACCESS LB System Manual...

  • Page 107: Appendix B - Peak Power Spectral Density

    Appendix B - Peak Power Spectral Density...

  • Page 108: Power Spectral Density As Measured For The Breezeaccess Lb System

    Appendix B - Peak Power Spectral Density Power spectral density as measured for the BreezeACCESS LB system PPSD (dBm) Channel Number (1-9) BreezeACCESS LB System Manual...

  • Page 109: Appendix C - Cli Commands

    Appendix C - CLI Commands In this Appendix: The CLI commands described in this Appendix are available via Telnet and Console connections to the LB NI-01 indoor unit, as outlined in previous Sections. For online help, type ‘help <command>’ at the command prompt.

  • Page 110: General Cli Commands

    Set one configuration parameter: <parameter name> [<value>] Without <value>, ‘set’ returns the actual value for configuration parameters. For status parameters, use the Get command. Returns a list of all System Configuration parameters. Returns a list of current system log entries. BreezeACCESS LB System Manual...
  • Page 111 Table C-1: General Commands Command show snmp show stats snmpaccess snmpcomm snmptrap test config upgrade General CLI Commands Description Returns a list of all SNMP communities and related parameters. Returns a list of all System Status parameters. Modify access rights for a community (see snmpcomm) snmpaccess <community name>...

  • Page 112: General Information

    Yes: RF link up / No: RF link down Specifies the time elapsed since the system started Specifies the operating software version Specifies the location, telephone #, contact information, etc. Identifies the local terminal Indicates the system's current uncoded burst rate BreezeACCESS LB System Manual...

  • Page 113: System Status And Configuration

    System Status and Configuration System Status Table C-3: System Status Command cableattn erxpkt erxpktd etxpkt gateway ipaddr ipmask macaddr master resetstats rffreq rflink rfstatus rssimax rssimean rssimin sinadr System Status and Configuration Description The attenuation of the signal over the IF cable Counts the number of packets successfully received locally Counts the number of packet errors received...

  • Page 114: System Configuration

    The no. of wireless pkt. retransmitted over the air Description Enables Adaptive Modulation mode. Specifies whether the antenna buzzer is enabled Change the operating software version Specifies whether over-the-air data encryption is enabled Enter the remote terminal's MAC address if encryption is enabled BreezeACCESS LB System Manual...
  • Page 115 Table C-4: System Configuration Command flowctrl gateway http ipaddr ipmask macaddr master modreduct radio reboot rfchannel save config snmp sysdetails sysname telnet telnetport test config System Status and Configuration Description Specifies whether flow control on the Ethernet port is enabled Specifies the IP address of the default router Specifies whether configuration over HTTP is enabled...
  • Page 116 Appendix C - CLI Commands Table C-4: System Configuration Command txpower Ubrate Description Specifies the max. power level of the system Sets the desired burst rate for the link. BreezeACCESS LB System Manual...

  • Page 117: Appendix D - Support For Tdm Using Third Party Units

    Appendix D - Support for TDM using Third Party Units...

  • Page 118: Support For Tdm Using Third Party Units

    Support For TDM Using Third Party Units 802.1p The BreezeACCESS LB uses IEEE 802.1p to ensure QoS to TDM based applications such as mobility backhaul and enterprise PBX traffic. IEEE 802.1p allows the wireless transmit queue to be split into two (high and low priority) queues.

  • Page 119: Using A Third Party T1/E1 Unit With Breezeaccess Lb

    802.3x pause frame in order to ensure uninterrupted transmission of the TDM traffic. NOTE For more information, contact your Alvarion certified partner or system integrator or check our support site for additional TDM documents. Support For TDM Using Third Party Units...
  • Page 120 Appendix D - Support for TDM using Third Party Units This page left intentionally blank. BreezeACCESS LB System Manual...

  • Page 121: Appendix E - Antenna Assembly

    Appendix E - Antenna Assembly...

  • Page 122: Antenna Assembly Drawings

    Appendix E - Antenna Assembly Antenna Assembly Drawings 28 dBi, 4.5º Antenna - Vertical Mount Assembly BreezeACCESS LB System Manual...

  • Page 123: Dbi, 9º, Antenna - Vertical Mount Assembly

    Antenna Assembly Drawings 23 dBi, 9º, Antenna - Vertical Mount Assembly...

Table of Contents
