- Page 1 User manual IVP 7001 MW EX...
- Page 2 IVP 7001 MW EX Passive infrared sensor Congratulations, you have just purchased a product with Intelbras quality and safety. The IVP 7001 MW PET passive infrared sensor has triple technology, which combines microwave de- tection with detection by passive infrared rays and immunity to animals up to 20kg. Advanced signal...
- Page 3 » Follow all instructions in the manual for assembling and installing the product. » LGPD - General Law for the Protection of Personal Data: Intelbras does not access, transfer, capture, or perform any other type of treatment of personal data from this product.
- Page 4 Scan (top view) 8 (m) 10 12 (m) Detection range (side view) 2.2m zona zero...
-
Page 5: Table Of Contents
Summary 1. Technical specifications 2. Product 3. Characteristics 4. Installation 5. Troubleshooting 6. Approval Warranty term... -
Page 6: Technical Specifications
1. Technical specifications Operating voltage 9-16 Vdc Operating Current ≤ 50 mA (12 Vdc) Detection Angle 110° Detection Range 12 × 12 m ± 20% Detection method MW and PIR (AND) Sensor element Low noise PIR MW antenna GaAs FET MW Frequency 10.525 GHz Immunity to animals... -
Page 7: Characteristics
3. Characteristics » Microcontrolled signal processing. » Microwave (Doppler effect) + infrared. » Automatic temperature compensation to reduce false alarms. » Adjustable microwave power; » Immunity to white light up to 10,000 lux; » Articulating bracket for attachment; » High immunity to RFI / EMI - shield; »... - Page 8 To attach the sensor follow the steps described below: 1. Unlock the rear cover by turning the lock on the bottom of the cabinet 180 ° and remove it by sliding the sensor upwards, as shown below: 2. For installation directly or in a wall corner, break the seals indicated for the holes in the rear attaching cover: For installation in the corner of the wall, it is necessary to use the support, as described in item 3.
- Page 9 » For installation directly on the wall, drill the holes in the positions indicated on the base of the articulator. For installa- tion in the corner of the wall, drill the holes in the positions indicated on the side of the back cover; Before screwing the articulator in position, pass the wire as shown in the images: Montado Mounted on...
- Page 10 » Fit the back cover to the wall-mounted bracket: » Define the position of the sensor and fix the articulator by tightening the screw as shown: 4. Connect the cables following the terminal indications. When energized, the sensor LED will flash for 60 s. This time is neces- sary to stabilize the amplification circuit of the PIR sensor and the microwave.
- Page 11 » P.COUNT: controls the pulse count of the PIR sensor to trigger the alarm. This adjustment has three selectable levels, according to the table below. Choose the configuration accordingly according to the environment in which the sensor will be installed. Factory Default: 1P P.
-
Page 12: Troubleshooting
5. Troubleshooting » Perform the walk test by verifying that the entire area you want to protect is being detected by the sensor. If this does not happen, readjust the PIR and microwave detection sensitivity. To do this, perform the following steps: 1. -
Page 13: Warranty Term
8. After its useful life, the product must be delivered to an authorized Intelbras service center or directly disposed of in an environmentally appropriate manner to avoid environmental and health impacts. If you prefer, the battery, as well as other unused Intelbras brand electronics, can be disposed of at any Green Eletron collection point (waste management facility to which we are associated). - Page 14 Support via e-mail: suporte@intelbras.com.br Customer Service: 0800 7042767 Where to buy? Who installs it? 0800 7245115 Imported to Brazil by: Intelbras S/A – Indústria de Telecomunicação Eletrônica Brasileira Rodovia SC 281, km 4,5 – Sertão do Maruim – São José/SC – 88122-001 01.21 CNPJ 82.901.000/0014-41 –...
