- Page 1 Cybex Plate Loaded 16120 Smith Press ® Owner’s Manual Strength Systems Part Number 16120-999-4 F www.cybexintl.com...
-
Page 2: Table Of Contents
Cybex® and the Cybex logo are registered trademarks of Cybex International, Inc. DISCLAIMER: Cybex International, Inc., makes no representations or warranties regarding the contents of this manual. We reserve the right to revise this document at any time or to make changes to the product described within it without notice or obligation to notify any person of such revisions or changes. -
Page 3: Safety
It is imperative the floor be level. Cybex recommends that all fitness equipment be used in a supervised area. It is recommended that the equipment be located in an access controlled area. Control is the responsibility of the owner. The extent of control is at the discretion of the owner. - Page 4 Cybex Plate Loaded 16120 Smith Press Owner’s Manual Use the selectorized and plate loaded machines as shown on placards. DO NOT modify the • machine. Never pin the weights in an elevated position. DO NOT use the machine if found in this condition.
- Page 5 Death or serious injury will occur if the following requirements are not met: Cybex is not able to anchor the equipment due to local building codes. The owner is responsible for the actual anchoring of equipment. Consult with a professional contractor.
-
Page 6: Securing Equipment
Cybex Plate Loaded 16120 Smith Press Owner’s Manual Securing Equipment Do not use machine until it is properly anchored. The machine has holes in the feet, which allow for ease in anchoring to the floor. All anchoring holes must be used to maximize stability. Equipment must be secured to a solid, level surface to eliminate rocking, tipping, or falling over due to incorrect usage and misuse. - Page 7 Cybex Plate Loaded 16120 Smith Press Owner’s Manual Inspect all cables and belts for damage or wear. If a cable or belt is worn or damaged, immediately • discontinue use until cable or belt has been replaced. Check for worn handles, worn snap links, and worn warning labeling. Replace all worn parts •...
-
Page 8: Warnings And Cautions
Cybex Plate Loaded 16120 Smith Press Owner’s Manual Warnings and Cautions Warning decals indicate a potentially hazardous situation that could result in death or serious injury if the precautions are not observed. Caution decals indicate a potentially hazardous situation that could result in death or serious injury if the precautions are not observed. -
Page 9: Label Placement
Cybex Plate Loaded 16120 Smith Press Owner’s Manual Label Placement 5220-364-X 16120-340-X 16120-340-X 16120-341-X 16120-341-X 16120-340-X 4000Y316-X 16120-341-X 16120-340-X 16120-341-X... -
Page 10: Assembly
Cybex Plate Loaded 16120 Smith Press Owner’s Manual Assembly Tools Required 9/16” Socket wrench • 7/16” Wrench • 7/32” Allen wrench • 9/16” Wrench • 5/16” Allen wrench • 16120 Smith Press Total Weight and Size 380 lbs. inches - 84 W x 54 L x 84 H 173 kg cm - 213 W x 137 L x 213 H Three people will be required for this procedure. - Page 11 Cybex Plate Loaded 16120 Smith Press Owner’s Manual WARNING: Use extreme caution when removing Smith Press Assembly from pallet. Failure to do so could result in injury. 3. Move to desired location and unpack. Keep all shipping packages near area of installation.
- Page 12 Cybex Plate Loaded 16120 Smith Press Owner’s Manual 4. Assemble Frame With assistants hold frames in an upright position. • Carefully place foot pad (supplied with machine) on each foot of the frame. • Align front frame mount in place.
- Page 13 Cybex Plate Loaded 16120 Smith Press Owner’s Manual 5. Install weight bar assembly. Carefully place weight bar on frame and secure in place by latching bar catch on hooks. • Verify each bar catch is hooked properly on the hook.
- Page 14 HHCS 7. Securely anchor machine to the floor using the anchor holes provided in each machine. CAUTION: Cybex is not responsible for the actual anchoring of equipment. Consult with a professional contractor. WARNING: Use fasteners having a minimum of 500 lbs. tensile capacity (3/8’’ grade 2 bolts or better).
- Page 15 Cybex Plate Loaded 16120 Smith Press Owner’s Manual...
-
Page 16: Exercise
Cybex Plate Loaded 16120 Smith Press Owner’s Manual Exercise Intended Use The intended commercial use of this machine is to aid exercise and improve general physical fitness. Instructions Read and understand all instructions and warnings prior to using this machine in the Safety section of the Owner’s Manual. - Page 17 Cybex Plate Loaded 16120 Smith Press Owner’s Manual SET UP 1. Adjust bar to appropriate height for exercise. See Diagram A. 2. Adjust bar stops to appropriate height for exercise. See Diagram B. 3. Load bar evenly with appropriate resistance. Unloaded bar weight = 15 lbs (7kg).
-
Page 18: Maintenance
Maintenance All preventive maintenance activities must be performed on a regular basis. Performing routine preventive maintenance actions can aid in providing safe, trouble-free operation of all Cybex Strength Systems equipment. Cybex is not responsible for performing regular inspection and maintenance actions for your machines. - Page 19 Cybex Plate Loaded 16120 Smith Press Owner’s Manual Clean Upholstery Then 1. Prepare a solution of 10% household liquid soap and warm water. 2. Apply with a soft damp cloth. Light Soiling 3. If necessary, apply a solution of liquid cleanser with a soft bristle brush.
- Page 20 Cybex Plate Loaded 16120 Smith Press Owner’s Manual Clean Chrome Clean chrome tubes, first using chrome polish and then using a car wax seal. Neutral cleaners with a pH between 5.5 and 8.5 are recommended. Be sure to dry thoroughly. AVOID acid or chlorine based cleaners and also cleaners containing abrasives as these could scratch or damage the equipment.
-
Page 21: Weekly Procedures
Cybex Plate Loaded 16120 Smith Press Owner’s Manual Weekly Procedures Inspect All Nuts and Bolts Tighten all loose nuts and bolts as required. WARNING: Serious injury or death may result if the following precautions are not followed. Replace all worn cables and belts. Worn cables and belts can fail if not replaced. - Page 22 Cybex Plate Loaded 16120 Smith Press Owner’s Manual Belts Condition of Belt 3D View 3D or Side View Peeling of the belt’s skin. Wave in belt Replace belt if any Examine edge of belt (both sides). section is over 1/32”...
-
Page 23: Yearly Procedures
Cybex Plate Loaded 16120 Smith Press Owner’s Manual CAUTION: Personal injury or property damage may occur if the following precautions are not followed. Do not use if less than 1/8” of material remains to the edge. Replace all worn handles immediately. Failure to replace worn handles can result in injury or property damage. -
Page 24: Cable Adjustment
Cybex Plate Loaded 16120 Smith Press Owner’s Manual Cable Adjustment Tools Required 9/16” Wrench (2) Four types of cable tension adjustment are used on Cybex Strength Systems: Cable Description Diagram Adjustment This type of adjustment uses a jam nut and a tension adjustment nut at... -
Page 25: Belt Adjustment
Cybex Plate Loaded 16120 Smith Press Owner’s Manual Belt Adjustment Tools Required 7/32” Wrench • Torque wrench (lbs-in) • Belt Adjustment Action 1. Using a 7/32” Allen wrench loose set screws. 2. Pull belt tight. 3. Secure belt in place with set screws. -
Page 26: Customer Service
Hours of phone service are Monday through Friday from 8:30 a.m. to 6:00 p.m. Eastern Standard Time. For Cybex customers living in the USA, contact Cybex Customer Service at 888-462-9239. For Cybex customers living outside the USA, contact Cybex Customer Service at 508-533-4300 or fax 508-533-5183. email address internationaltechhelp@cybexintl.com Find information on the web at www.cybexintl.com. -
Page 27: Return Material Authorization (Rma)
Provide the model and serial number of your Cybex equipment. At Cybex’s discretion, the technician may request that you return the problem part(s) to Cybex for evaluation and repair or replacement. The technician will assign you a RMA number and will send you an ARS label. -
Page 28: Damaged Parts
Cybex Plate Loaded 16120 Smith Press Owner’s Manual Damaged Parts Materials damaged in shipment should not be returned for credit. Shipping damages are the responsibility of the carrier (UPS, Federal Express, trucking companies, etc.) Apparent Damage Upon receipt of your shipment, check all items carefully. Any damage seen with a visual check must be noted on the freight bill and signed by the carrier’s agent. - Page 30 10 Trotter Drive Medway, MA 02053 508-533-4300 FAX 508-533-5183 • • www.cybexintl.com • techhelp@cybexintl.com...
