en Commissioning / Functional test
8 Commissioning / Functional test
NOTICE
It is recommended to test together with the connected system.
The pump's installation and operating instructions are needed for some settings.
8.1

Settings

Stratos Smart IF module
Smart IF module
Table 6: Settings
8.2

Wilo Net ID

Stratos Smart IF module
Smart IF module
Table 7: Wilo Net ID
8.3

Parameter A - Bluetooth block

Stratos Smart IF module
Smart IF module
Table 8: Parameter A - Bluetooth block
8.4

Parameter C - delete Bluetooth connection key

Enter 1 as the parameter to delete all Bluetooth connection keys (pairings). After the
command has been run, the value automatically returns to 0.
Delete the connection key to delete the pairing of all previously paired devices. This
prevents previously paired devices from gaining unauthorised access at a later point.
The group of authorised remote controls can be checked along with block A.
36
2. Position the wires of the digital temperature sensor according to their colours
(WH - white, RD - red, BK - black).
Read the installation and operating instructions for the Stratos series to
configure settings in Stratos pumps.
In order to configure settings in the < 5.x.x.x > menus, DIP switch 1 (no
key symbol) under the terminal box cover must be set to "ON".
Adjust Wilo Net ID in pump menu
OFF deactivates the interface.
Adjust Wilo Net ID in pump menu < 5.2.3.0 >.
OFF deactivates the interface.
0 enables pairing with the device, 1 blocks pairing.
Set to 1 to not permit any new devices.
0 enables pairing with the device, 1 blocks pairing.
Set to 1 to not permit any new devices.
Parameter A is adjusted in menu < 5.2.4.0 >.
.
