Fast Forward EnergyCam Getting Started Tutorial page 4

The following actions are currently available:
Button is Action
pressed
for
1 sec OCR Reading
2 sec Install wM-Bus
3 sec Install Device
4 + 1 sec Reboot
5 sec Info
5 + 1 sec Reset
6 + 1 sec Reset
(1 sec) Trigger OCR reading
To trigger an OCR reading outside the default period - the button has to be pressed for 1 second.
(until the "- 1 -" is visible)
Press Button
If the device is installed on a meter the display shows:
1) --PIC---
2) P 15 / P 10 / P 5 / P 2
2) P ---
3) 1078.4
FAST_EnergyCam_Manual.docx | v1.30 | 8. December 2016
Display after
--Pic--- P 15 / P ---
--MBus-- e.g. 22048063
(M-Bus ID)
-INST-BW --V2.00--
-INST-WB
--Reset- -- EC --
(see below) (see below)
--Reset- MODBUS
--Reset- M-BUS
Release Button
: Trigger OCR reading is started
: the configured reading period (60min, 30min,15 min, 10 min, 5 min, 2 min, 1
min)
: device isn't installed
: the new reading
Button After that
Device goes into normal
operation
S2 / T2 / Cable Install wM-Bus and send
default data.
B (Build#) If successful – device goes
into normal operation
Restart the device / disable
the Data Logger
(see below) Device goes into normal
operation
115200 Device is Reset to default
Modbus
2400 Device is Reset to default M-
Bus
page 4 / 38
