Examples for correct positioning of EnergyCam 2.0
Examples for uncorrect positioning of EnergyCam 2.0
Oblique positioned
Position too far down
Step 5:
Press the button until the LCD display shows '3' to install
EnergyCam 2.0 on the meter. Compare the reading on
the LCD display with the actual meter readout.
Done! EnergyCam 2.0 is now installed on the meter.
LED
Meaning
No digits found or EnergyCam 2.0 is
positioned incorrectly.
Position
completed.
FAST_EnergyCam_Manual.docx | v1.30 | 8. December 2016
is
OK
and
installation
Positioned too high up
Positioned too far right
Installation process
Action
Repeat installation process (step 3 to 5).
Compare reading with actual meter
reading
