Craftsman Model C459-60133
Ref.
Part No.
No.
1
918-04566
2
647-04034C-0637
3
647-04035
4
710-0227
5
710-04484
6
710-0599
7
710-0604A
8
710-0809
9
710-0176
10
710-3008
11
911-04075A
12
712-04063
13
712-0700
14
914-0209
15
714-04040
16
718-04407
17
720-04028
18
725-0157
19
725-1644
20
726-0214
21
926-0320
22
731-04602
23
731-04604
24
731-06894
25
732-04306
26
732-04488
27
732-04746
28
732-0716D
29
735-0239
30
736-0242
31
747-04969
32
747-05186
Description
Transmission Drive Assembly
Pedal Assembly
Shaft Lever Assembly
Screw, 8-18:0.500
Screw, 5/16-18 x .750
Screw, 1/4-20 x 0.500
Screw, 5/16-18 x 0.625
Screw, 1/4-20 x 1.250
Hex Screw, 5/16-18 x 2.75
Hex Screw, 5/16-18 x .75
Ferrule, 3/8-24 X .375 DIA.
Flangelock Nut, 5/16-18
Flange Nut, 9/16-18
Cotter Pin INT- .125 DIA
Bow-Tie Cotter Pin
Pulley Hub, 5/8 SPLINE
Shift Knob
Cable Tie
Short Spring Switch
Push Cap, 5/8
Plate Insulator Nut
Sleeve, .758 x .821 x 3.3125
Sleeve, .758 x .821 x 2.4375
Shift Bearing Plate
Spring Extension, .80 OD x 3.28 LG
Spring Extension, .38 OD x 3.25 LG
Spring Extension, .94 OD x 6.75 LG
Spring Extension, .59 OD x 4.00 LG
Foot Pad, 4.0 LONG
Bell Washer, .340 x .872 x .060
Belt Keeper Rod
Variable Speed Control Rod
PARTS LIST
Ref.
Part No.
No.
33
747-05188
34
747-05244
35
738-04237A
36
750-0566A
37
750-0802
38
954-04249
39
954-0241A
40
956-04002
41
783-04536B-0637
42
783-04595A
43
956-04015A
44
683-04206
45
710-0627
46
710-0778
47
718-04261
48
736-0362
49
941-0600
50
683-04176A
51
683-04207
52
710-0347
53
710-1260A
54
712-04065
55
938-0347
56
756-04325
57
725-04363
58
17962
59
634-0104-0961
60
634-04369-4042
61
934-0255
62
734-1730-0901
925-04082
41
Description
Brake Rod
Shift Rod
Shoulder Screw, #10-32 x .500
Spacer, .260 x .375 x 1.030 LG
Spacer, .640 ID x .76 OD x 2.63
V Belt, 5L: 70.90 POLY
V Belt, 5L: 35.25 POLY
Trans. Pulley
Pedal Support Bracket
Shaft Adjust Bracket
Variable Speed Pulley Assembly
Bracket Assembly
Hex Screw, 5/16-24 x .750
Screw, 1/4-20 x 1.500
Bearing Cup
Flat Washer, .330 x 1.25 x .06:HT
Ball Bearing, 17 x 40 x 12
Transmission Bracket Assembly
Idler Bracket Assembly
Hex Screw, 3/8-16 x 1.75
Screw, 5/16-18 x 0.750
Flange Lock Nut, 3/8-16
Shoulder Spacer, .625 ID x .169
Idler Pulley
Switch Interlock
Plate Switch
Wheel Assembly, 20 x 8 x 8 Sq. Sh.
Rim Assembly
Valve Stem
Tire, 20 x 8 x 8 Sq. Sh.
Wiring Harness (Not Shown)
