Craftsman Model C459-60133
PARTS LIST
Ref.
Part No.
No.
1
710-0227
2
710-04484
3
712-04063
4
720-04061
5
925-1303
6
725-1439
7
726-0278
8
726-0279
9
732-1184
10
936-0108
11
736-0242
12
938-0296
13
783-0209D
14
783-04081D-0637
15
783-1489D-0637
16
757-04124
17
710-05280
18
710-0599
19
731-04591A
20
783-04587D-4043
21
783-04843-0637
22
723-04025
723-04026
23
710-0134
24
732-04035
Description
Screw, 8-18 x .500
Screw, 5/16-18 x .750
Flange Lock Nut, 5/16-18
Knob, 3/8-16 x .875
Outer Seat Spring
Inner Seat Spring
Insulator Boss Plate
Insulator Plate
Extension Spring
Flat Washer, .510 x .750 x .033
Flat Washer, .340 x .872 x .060
Shoulder Screw, 5/16-18 x .437 x .268
Lift Seat Bracket
Seat Pivot Bracket
Seat Mounting Bracket
Low Back Seat
Screw, 1/4-20 x .500
Screw Pan Torx Head, 1/4-20 x .500
Cup Holder
Fender
Lift Adjuster Bracket
Abrasive Foot Pad, LH
Abrasive Foot Pad, RH
Carriage Screw, .62: 1/4-20
Spring, Compress., 1.28 x 3.125
37
