MAX200 Series Motorized Microscopy Stages
4.7.2 MAX202 and MAX203 Dimensions
Seven mounting holes
5.9" [150.0mm]
0.6" [15.0mm]
8.7"
[220.0mm]
1.3" [33.0mm]
Six 6-32UNC (M3) mounting
10.1"
8.4"
9.1"
holes to clamp well plates
3.5" [88.0mm]
[257.5mm]
[214.0mm]
[230.0mm]
1.3" [33.0mm]
5.4"
[136.4mm]
1.3" [33.0mm]
2.7"
2.4"
[69.0mm]
[62.0mm]
2.0"
3.9" [100.0mm]
[50.0mm]
7.4" [187.0mm]
2.2"
[55.5mm]
11.6" [294.5mm]
Fig. 4.7 Dimensions - MAX202 and MAX203 Stages
