4.6 Electrical Connections (MAX201 and MAX203 only)
Using the splitter lead supplied, make electrical connections as shown in Fig. 4.5.
15 pin D-Type - long lead
To stepper motor connector
15 pin D-Type - short lead
To SmartSignal Electronics module
15 pin D-Type
To DRIVE CHANNEL on
rear of stepper motor control unit
MOTOR DRIVE
Fig. 4.5 Electrical connections
MAX200 Series Motorized Microscopy Stages
22
