Fujitsu AUXG07KVLA Service Manual page 89

3-unit multi-split type
Hide thumbs

Advertisement

Table of Contents
61
62
Item no.
61
62
63
64
65
66
67
3-4. Wall mounted type
66
65
Step motor
holder assy
Step
motor
holder
63
Part no.
9387593211
Evaporator total assy (For 07, 09, 12 model)
9387593204
Evaporator total assy (For 14 model)
9387590104
Drain pan total assy
9387714036
Step motor holder assy
9603688011
Brushless motor (For 07, 09, 12 model)
9603492014
Brushless motor (For 14 model)
9333606033
Crossflow fan assy
9333628004
Bearing D assy
9387587074
Base assy
67
Motor cover assy
Cable guide
Part name
- (02-45) -
64
Motor case
Service part
3. Indoor unit parts list
