22
21
Item no.
21
22
23
24
25
3-2. Mini duct type
Main Panel (2 Fan)
Part no.
9381930111
Drain pan sub assy
9381933440
Evaporator total assy
9900472061
Pump assy
9900465063
Float switch
9378450097
Hose sub assy
24
25
Part name
- (02-11) -
23
Service part
3. Indoor unit parts list
