AIR CONDITIONER
3-unit multi-split type
DESIGN & TECHNICAL MANUAL
INDOOR
ASYG07–14KGTE
ASYG07–14KGTF
ABYG18KRTA
AGYG09–14KVCA
AUXG07–18KVLA
ARXG07–14KSLAP
ASYG18KMTB
ASYG07–14KMTB
ASYG18KMTE
ASYG07–14KMCC
ASYG07–14KMCE
ASYG07–14KMCF
ARXG07–14KLLAP
ARXG18KSLAP
ARXG18KLLAP
ASYG07–14KETA
ASYG07–14KETE
ASYG07–14KETF
OUTDOOR
ASYG07–14KGTB
ASYG07–14KETA-B
ASYG07–14KETE-B
ASYG07–14KETF-B
AOYG18KBTA3
AOYG24KBTA3
DR_MU024EF_06
2023.03.10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ARXG14KSLAP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fujitsu ARXG14KSLAP

Summary of Contents for Fujitsu ARXG14KSLAP

  • Page 1 AIR CONDITIONER 3-unit multi-split type DESIGN & TECHNICAL MANUAL INDOOR AUXG07–18KVLA ARXG07–14KSLAP ARXG07–14KLLAP ASYG07–14KGTB ARXG18KSLAP ARXG18KLLAP ASYG07–14KGTE ASYG18KMTB ASYG07–14KMTB ASYG07–14KETA ASYG07–14KETA-B ASYG07–14KGTF ASYG18KMTE ASYG07–14KMCC ASYG07–14KETE ASYG07–14KETE-B ASYG07–14KMCE ASYG07–14KETF ASYG07–14KETF-B ASYG07–14KMCF OUTDOOR ABYG18KRTA AGYG09–14KVCA AOYG18KBTA3 AOYG24KBTA3 DR_MU024EF_06 2023.03.10...
  • Page 2 • For further details, please check with our authorized dealer. Trademarks ™ FGLair is trademark of FUJITSU GENERAL LIMITED in the United States, other countries or both. “AIRSTAGE Mobile” is a trademark of FUJITSU GENERAL LIMITED. Android and Google Play are trademarks of Google LLC.

  • Page 3: Table Of Contents

    CONTENTS Part 1. INDOOR UNIT................1 1. Model lineup ....................2 1-1. Connectable indoor units to each outdoor unit..............4 1-2. Indoor unit connection patterns..................5 2. Specifications....................7 2-1. Compact cassette type ....................7 2-2. Mini duct type........................9 2-3. Slim duct type ........................11 2-4. Wall mounted type ......................13 2-5.
  • Page 4 CONTENTS (continued) 8-4. Wall mounted type .......................126 8-5. Ceiling type ........................133 8-6. Floor type........................134 9. Noise level curve..................135 9-1. Compact cassette type ....................135 9-2. Mini duct type.......................138 9-3. Slim duct type ......................141 9-4. Wall mounted type .......................144 9-5. Ceiling type ........................149 9-6.
  • Page 5 CONTENTS (continued) 15-6.Wired remote controller (UTY-RNNYM) ..............310 15-7.Wired remote controller (UTY-RVNYM) ..............312 15-8.Wired remote controller (UTY-RLRY) .................313 15-9.Wired remote controller (UTY-RNRYZ*) ..............313 15-10.Simple remote controller (UTY-RSNYM)..............314 16. Accessories ....................315 16-1.Compact cassette type ....................315 16-2.Mini duct type......................316 16-3.Slim duct type ......................318 16-4.Wall mounted type ......................319 16-5.Ceiling type .........................325 16-6.Floor type ........................326...
  • Page 6 CONTENTS (continued) Part 2. OUTDOOR UNIT (3 UNITS TYPE) ........341 1. Specifications....................342 2. Dimensions....................344 2-1. Models: AOYG18KBTA3 and AOYG24KBTA3 ............344 3. Installation space ..................345 3-1. Models: AOYG18KBTA3 and AOYG24KBTA3 ............345 4. Refrigerant circuit ..................348 4-1. Models: AOYG18KBTA3 and AOYG24KBTA3 ............348 5.
  • Page 7 CONTENTS (continued) 16. Outdoor unit installation precautions .............456 16-1.Places where prohibited for use..................456 16-2.Points to remember when installing ................456...

  • Page 9: Part 1. Indoor Unit

    Part 1. INDOOR UNIT COMPACT CASSETTE TYPE: AUXG07–18KVLA MINI DUCT TYPE: SLIM DUCT TYPE: ARXG07–14KSLAP ARXG18KSLAP ARXG07–14KLLAP ARXG18KLLAP WALL MOUNTED TYPE: ASYG07–14KGTB ASYG07–14KGTE ASYG18KMTB ASYG07–14KGTF ASYG18KMTE ASYG07–14KMTB ASYG07–14KETA ASYG07–14KETA-B ASYG07–14KMCC ASYG07–14KETE ASYG07–14KETE-B ASYG07–14KMCE ASYG07–14KETF ASYG07–14KETF-B ASYG07–14KMCF CEILING TYPE: FLOOR TYPE: ABYG18KRTA AGYG09–14KVCA...

  • Page 10: Model Lineup

    1. Model lineup Indoor unit AUXG07KVLA ARXG07KSLAP ARXG07KLLAP ASYG07KGTB AUXG09KVLA ARXG09KSLAP ARXG09KLLAP ASYG09KGTB AUXG12KVLA ARXG12KSLAP ARXG12KLLAP ASYG12KGTB AUXG14KVLA ARXG14KSLAP ARXG14KLLAP ASYG14KGTB AUXG18KVLA ARXG18KSLAP ARXG18KLLAP ASYG07KGTE ASYG18KMTB ASYG07KMTB ASYG07KETA ASYG09KGTE ASYG18KMTE ASYG09KMTB ASYG09KETA ASYG12KGTE ASYG12KMTB ASYG12KETA ASYG14KGTE ASYG14KMTB ASYG14KETA ASYG07KGTF ASYG07KMCC...
  • Page 11 Outdoor unit AOYG18KBTA3 AOYG24KBTA3 - 3 - 1. Model lineup...

  • Page 12: Connectable Indoor Units To Each Outdoor Unit

    1-1. Connectable indoor units to each outdoor unit ●: Connectable / -: Not connectable Compact cassette Mini duct Outdoor unit ARXG07–14KSLAP AUXG07–18KVLA ARXG18KSLAP Btu class kW class AOYG18KBTA3 ● ● ● ● — ● ● ● ● — AOYG24KBTA3 ● ●...

  • Page 13: Indoor Unit Connection Patterns

    1-2. Indoor unit connection patterns ¢ 3-unit multi-split type AOYG18KBTA3 Combination no. Unit 1 Unit 2 Unit 3 Total — — — — — — — — — — Numbers in column Unit 1, 2, 3, and Total indicate the indoor unit capacities as follows: 7: 7,000 Btu/h, 9: 9,000 Btu/h, 12: 12,000 Btu/h, 14: 14,000 Btu/h ..
  • Page 14 AOYG24KBTA3 Combination no. Unit 1 Unit 2 Unit 3 Total — — — — — — — — — — — — — — Numbers in column Unit 1, 2, 3, and Total indicate the indoor unit capacities as follows: 7: 7,000 Btu/h, 9: 9,000 Btu/h, 12: 12,000 Btu/h, 14: 14,000 Btu/h ..

  • Page 15: Specifications

    2. Specifications 2-1. Compact cassette type Model name AUXG07KVLA AUXG09KVLA AUXG12KVLA AUXG14KVLA Power supply 1Ø 230 V~ 50 Hz Available voltage range 198—264 V Capacity kW class Input power Running current 0.15 0.19 0.22 HIGH Cooling QUIET Airflow rate HIGH Heating QUIET Type ×...
  • Page 16 Model name AUXG18KVLA Power supply 1Ø 230 V~ 50 Hz Available voltage range 198—264 V Capacity kW class Input power Running current 0.30 HIGH Cooling QUIET Airflow rate HIGH Heating QUIET Type × Qty Turbo fan × 1 Motor output HIGH Cooling QUIET...

  • Page 17: Mini Duct Type

    2-2. Mini duct type Model name ARXG07KSLAP ARXG09KSLAP ARXG12KSLAP ARXG14KSLAP Power supply 1Ø 230 V~ 50 Hz Available voltage range 198—264 V Capacity kW class HIGH Input power QUIET Running current 0.29 0.33 0.38 0.58 HIGH Cooling QUIET Airflow rate...
  • Page 18 Model name ARXG18KSLAP Power supply 1Ø 230 V~ 50 Hz Available voltage range 198—264 V Capacity kW class HIGH Input power QUIET Running current 0.49 HIGH Cooling QUIET Airflow rate HIGH Heating QUIET Type × Qty Sirocco fan × 3 Motor output Recommended static pressure 0 to 50...

  • Page 19: Slim Duct Type

    2-3. Slim duct type Model name ARXG07KLLAP ARXG09KLLAP ARXG12KLLAP ARXG14KLLAP Power supply 1Ø 230 V~ 50 Hz Available voltage range 198—264 V Capacity kW class Input power Running current 0.33 0.30 0.35 0.51 HIGH Cooling QUIET Airflow rate HIGH Heating QUIET Type ×...
  • Page 20 Model name ARXG18KLLAP Power supply 1Ø 230 V~ 50 Hz Available voltage range 198—264 V Capacity kW class Input power Running current 0.44 HIGH Cooling QUIET Airflow rate HIGH Heating QUIET Type × Qty Sirocco fan × 3 Motor output Recommended static pressure 0 to 90 HIGH...

  • Page 21: Wall Mounted Type

    2-4. Wall mounted type Model name ASYG07KGTB ASYG09KGTB ASYG12KGTB ASYG14KGTB Power supply 1Ø 230 V~ 50 Hz Available voltage range 198—264 V Capacity kW class Input power Running current 0.20 0.24 0.24 0.29 HIGH Cooling QUIET Airflow rate HIGH Heating QUIET Type ×...
  • Page 22 Model name ASYG07KGTE ASYG09KGTE ASYG12KGTE ASYG14KGTE Power supply 1Ø 230 V~ 50 Hz Available voltage range 198—264 V Capacity kW class Input power Running current 0.20 0.24 0.24 0.29 HIGH Cooling QUIET Airflow rate HIGH Heating QUIET Type × Qty Crossflow fan ×...
  • Page 23 Model name ASYG07KGTF ASYG09KGTF ASYG12KGTF ASYG14KGTF Power supply 1Ø 230 V~ 50 Hz Available voltage range 198—264 V Capacity kW class Input power Running current 0.20 0.24 0.24 0.29 HIGH Cooling QUIET Airflow rate HIGH Heating QUIET Type × Qty Crossflow fan ×...
  • Page 24 Model name ASYG18KMTB Power supply 1Ø 230 V~ 50 Hz Available voltage range 198—264 V Capacity kW class Input power 37.5 Running current 0.35 HIGH Cooling QUIET Airflow rate HIGH 1,020 Heating QUIET Type × Qty Crossflow fan × 1 Motor output HIGH Cooling...
  • Page 25 Model name ASYG18KMTE Power supply 1Ø 230 V~ 50 Hz Available voltage range 198—264 V Capacity kW class Input power 37.5 Running current 0.35 HIGH Cooling QUIET Airflow rate HIGH 1,020 Heating QUIET Type × Qty Crossflow fan × 1 Motor output HIGH Cooling...
  • Page 26 Model name ASYG07KMTB ASYG09KMTB ASYG12KMTB ASYG14KMTB Power supply 1Ø 230 V~ 50 Hz Available voltage range 198—264 V Capacity kW class Input power Running current 0.20 0.24 0.24 0.30 HIGH Cooling QUIET Airflow rate HIGH Heating QUIET Type × Qty Crossflow fan ×...
  • Page 27 Model name ASYG07KMCC ASYG09KMCC ASYG12KMCC ASYG14KMCC Power supply 1Ø 230 V~ 50 Hz Available voltage range 198—264 V Capacity kW class Input power Running current 0.20 0.24 0.24 0.30 HIGH Cooling QUIET Airflow rate HIGH Heating QUIET Type × Qty Crossflow fan ×...
  • Page 28 Model name ASYG07KMCE ASYG09KMCE ASYG12KMCE ASYG14KMCE Power supply 1Ø 230 V~ 50 Hz Available voltage range 198—264 V Capacity kW class Input power Running current 0.20 0.24 0.24 0.30 HIGH Cooling QUIET Airflow rate HIGH Heating QUIET Type × Qty Crossflow fan ×...
  • Page 29 Model name ASYG07KMCF ASYG09KMCF ASYG12KMCF ASYG14KMCF Power supply 1Ø 230 V~ 50 Hz Available voltage range 198—264 V Capacity kW class Input power Running current 0.20 0.24 0.24 0.30 HIGH Cooling QUIET Airflow rate HIGH Heating QUIET Type × Qty Crossflow fan ×...
  • Page 30 ASYG07KETA ASYG09KETA ASYG12KETA ASYG14KETA Model name ASYG07KETA-B ASYG09KETA-B ASYG12KETA-B ASYG14KETA-B Power supply 1Ø 230 V~ 50 Hz Available voltage range 198—264 V Capacity kW class Input power Running current 0.20 0.24 0.24 0.30 HIGH Cooling QUIET Airflow rate HIGH Heating QUIET Type ×...
  • Page 31 ASYG07KETE ASYG09KETE ASYG12KETE ASYG14KETE Model name ASYG07KETE-B ASYG09KETE-B ASYG12KETE-B ASYG14KETE-B Power supply 1Ø 230 V~ 50 Hz Available voltage range 198—264 V Capacity kW class Input power Running current 0.20 0.24 0.24 0.30 HIGH Cooling QUIET Airflow rate HIGH Heating QUIET Type ×...
  • Page 32 ASYG07KETF ASYG09KETF ASYG12KETF ASYG14KETF Model name ASYG07KETF-B ASYG09KETF-B ASYG12KETF-B ASYG14KETF-B Power supply 1Ø 230 V~ 50 Hz Available voltage range 198—264 V Capacity kW class Input power Running current 0.20 0.24 0.24 0.30 HIGH Cooling QUIET Airflow rate HIGH Heating QUIET Type ×...

  • Page 33: Ceiling Type

    2-5. Ceiling type Model name ABYG18KRTA Power supply 1Ø 230 V~ 50 Hz Available voltage range 198—264 V Capacity kW class Input power Running current 0.21 HIGH Cooling QUIET Airflow rate HIGH Heating QUIET Type × Qty Sirocco fan × 2 Motor output HIGH Cooling...

  • Page 34: Floor Type

    2-6. Floor type Model name AGYG09KVCA AGYG12KVCA AGYG14KVCA Power supply 230 V~ 50 Hz Available voltage range 198—264 V Capacity kW class Input power Running current 0.15 0.18 0.20 HIGH Cooling QUIET Airflow rate HIGH Heating QUIET Type × Qty Crossflow fan ×...

  • Page 35: Wireless Lan Control (For Kgtf, Kmcf, Ketf, And Ketf-B)

    After installation of mobile app, user registration is required. For user registration and setup infor- mation, refer to Setting Manual attached with the product. For the latest version of the wireless LAN control manuals, refer to the following web site. https://www.fujitsu-general.com/global/support/ - 27 - 3-1. System requirement...

  • Page 36: Wireless Lan Function List

    3-2. Wireless LAN function list NOTE: To use the wireless LAN control, user registration in advance and access to the wireless home network are required. Attached Wireless Item Mobile app Remote Controller Air conditioning Operation on/off ○ ○ control function Operation mode setting ○...

  • Page 37: Dimensions

    4. Dimensions 4-1. Compact cassette type ¢ Models: AUXG07–18KVLA Unit: mm Grid type grille Hanging bolt position IR receiver Drain hose View A Ceiling Control Box View B View C - 29 - 4-1. Compact cassette type 4. Dimensions...
  • Page 38  Installation space requirement Unit: mm Strong and durable ceiling or more 1,000 1,000 or more or more 1,800 or more Obstruction Floor Maximum height from floor to ceiling (Unit: mm) 07 and 09 models 12 or larger models Standard 2,700 High ceiling —...

  • Page 39: Mini Duct Type

    4-2. Mini duct type ¢ Models: ARXG07–14KSLAP Unit: mm Rear view View A Drain port P 100 × 6 = 600 Top view Side view Front view Bottom view - 31 - 4-2. Mini duct type 4. Dimensions...
  • Page 40 ¢ Model: ARXG18KSLAP Unit: mm Rear view View A Drain port P 100 × 8 = 800 Top view Side view Front view Bottom view - 32 - 4-2. Mini duct type 4. Dimensions...
  • Page 41  Installation space requirement Provide sufficient installation space for product safety. Unit: mm Strong and durable ceiling Indoor unit Left Right side side or more* or more *: 400 or more when drain from drain pipe • When intaking air from back: •...

  • Page 42: Slim Duct Type

    4-3. Slim duct type ¢ Models: ARXG07–14KLLAP Unit: mm View A Rear view Drain port 100 x 6 = 600 Side view Top view Front view Bottom view - 34 - 4-3. Slim duct type 4. Dimensions...
  • Page 43 ¢ Model: ARXG18KLLAP Unit: mm Rear view View A Drain port 100 × 8 = 800 Top view Side view Front view Bottom view - 35 - 4-3. Slim duct type 4. Dimensions...
  • Page 44  Installation space requirement Provide sufficient installation space for product safety. In ceiling-concealed installations: Unit: mm 300 or more Strong and durable ceiling 20 or more Indoor unit Left Right side side 20 or more Service access Ceiling or more or more Floor ...

  • Page 45: Wall Mounted Type

    4-4. Wall mounted type ¢ Models: ASYG07–14KGTB Unit: mm 373.5 417.5 Outline of indoor unit for pipe inlet Ø65 for pipe inlet Ø65 - 37 - 4-4. Wall mounted type 4. Dimensions...
  • Page 46  Installation space requirement Provide sufficient installation space for product safety. Unit: mm 70 or more 40 or more Wall hook bracket Outline of the indoor unit 107 or more 183 or more 1,500 or more A: Install so that the flare connection part is outdoors. - 38 - 4-4.
  • Page 47 ¢ Models: ASYG07–14KGTE and ASYG07–14KGTF Unit: mm 373.5 417.5 (834) Outline of indoor unit for pipe inlet Ø65 for pipe inlet Ø65 - 39 - 4-4. Wall mounted type 4. Dimensions...
  • Page 48  Installation space requirement Provide sufficient installation space for product safety. Unit: mm 40 or more 70 or more Wall hook bracket 107 or more 183 or more Outline of the indoor unit 1,500 or more A: Install so that the flare connection part is outdoors. - 40 - 4-4.
  • Page 49 ¢ Model: ASYG18KMTB Unit: mm Outline of indoor unit for pipe inlet Ø65 for pipe inlet Ø65 - 41 - 4-4. Wall mounted type 4. Dimensions...
  • Page 50  Installation space requirement Provide sufficient installation space for product safety. Unit: mm 40 or more Wall hook bracket 70 or more Outline of the indoor unit 160 or more 117 or more 1,500 or more A: Install so that the flare connection part is outdoors. - 42 - 4-4.
  • Page 51 ¢ Model: ASYG18KMTE Unit: mm Outline of indoor unit for pipe inlet Ø65 for pipe inlet Ø65 - 43 - 4-4. Wall mounted type 4. Dimensions...
  • Page 52  Installation space requirement Provide sufficient installation space for product safety. Unit: mm 40 or more Wall hook bracket 70 or more 117 or more Outline of the indoor unit 160 or more 1,500 or more A: Install so that the flare connection part is outdoors. - 44 - 4-4.
  • Page 53 ¢ Models: ASYG07–14KMTB and ASYG07–14KMCC Unit: mm Outline of indoor unit for pipe inlet Ø65 for pipe inlet Ø65 - 45 - 4-4. Wall mounted type 4. Dimensions...
  • Page 54  Installation space requirement Provide sufficient installation space for product safety. Unit: mm 70 or more 40 or more Wall hook bracket Outline of the indoor unit 107 or more 183 or more 1,500 or more A: Install so that the flare connection part is outdoors. - 46 - 4-4.
  • Page 55 ¢ Models: ASYG07–14KMCE and ASYG07–14KMCF Unit: mm Outline of indoor unit for pipe inlet Ø65 for pipe inlet Ø65 - 47 - 4-4. Wall mounted type 4. Dimensions...
  • Page 56  Installation space requirement Provide sufficient installation space for product safety. Unit: mm 40 or more 70 or more Wall hook bracket 107 or more 183 or more Outline of the indoor unit 1,500 or more A: Install so that the flare connection part is outdoors. - 48 - 4-4.
  • Page 57 ¢ Models: ASYG07–14KETA, ASYG07–14KETA-B, ASYG07– 14KETE, ASYG07–14KETE-B, ASYG07–14KETF, and ASYG07– 14KETF-B Unit: mm 373.5 417.5 (950) Outline of indoor unit for pipe inlet Ø65 for pipe inlet Ø65 - 49 - 4-4. Wall mounted type 4. Dimensions...
  • Page 58  Installation space requirement Provide sufficient installation space for product safety. Unit: mm 40 or more 40 or more Wall hook bracket Outline of the indoor unit 166 or more 211 or more 1,500 or more The flare connection part should be installed outdoors.

  • Page 59: Ceiling Type

    4-5. Ceiling type ¢ Model: ABYG18KRTA Unit: mm 1,080 49 84 125 103 Side view Top view ø100-mm hole Rear view Suspension bolt pitch Dimensions Indoor unit (Top view) (Space required for installation) The length of the bolt here is 30 mm. Indoor unit - 51 - 4-5.
  • Page 60 ¢ Installation space requirement Unit: mm Ceiling Indoor unit 30 or more Ceiling 200 or more 0 or more Obstruction Floor Required ceiling height varies according to the ceiling mode setting of function setting No. 20. Ceiling height (m) Ceiling mode Standard High ceiling 18 model...

  • Page 61: Floor Type

    4-6. Floor type ¢ Models: AGYG09–14KVCA Unit: mm Side view Front view - 53 - 4-6. Floor type 4. Dimensions...
  • Page 62  Installation space Unit: mm 100 or more 80 or more 80 or more 50 or more 150 or below from the floor PROHIBITED Grating WARNING • The appliance shall be installed, operated and stored in a room with a floor area larger than X Minimum room area Amount of refrigerant charge M (kg)

  • Page 63: Wiring Diagrams

    5. Wiring diagrams 5-1. Compact cassette type ¢ Models: AUXG07–18KVLA - 55 - 5-1. Compact cassette type 5. Wiring diagrams...

  • Page 64: Mini Duct Type And Slim Duct Type

    5-2. Mini duct type and Slim duct type ¢ Models: ARXG07–18KSLAP and ARXG07–18KLLAP WLAN adapter, Converter etc. (Option) - 56 - 5-2. Mini duct type and Slim duct type 5. Wiring diagrams...

  • Page 65: Wall Mounted Type

    5-3. Wall mounted type ¢ Models: ASYG07–14KGTB - 57 - 5-3. Wall mounted type 5. Wiring diagrams...
  • Page 66 ¢ Models: ASYG07–14KGTE - 58 - 5-3. Wall mounted type 5. Wiring diagrams...
  • Page 67 ¢ Models: ASYG07–14KGTF - 59 - 5-3. Wall mounted type 5. Wiring diagrams...
  • Page 68 ¢ Model: ASYG18KMTB - 60 - 5-3. Wall mounted type 5. Wiring diagrams...
  • Page 69 ¢ Model: ASYG18KMTE - 61 - 5-3. Wall mounted type 5. Wiring diagrams...
  • Page 70 ¢ Models: ASYG07–14KMTB - 62 - 5-3. Wall mounted type 5. Wiring diagrams...
  • Page 71 ¢ Models: ASYG07–14KMCC - 63 - 5-3. Wall mounted type 5. Wiring diagrams...
  • Page 72 ¢ Models: ASYG07–14KMCE - 64 - 5-3. Wall mounted type 5. Wiring diagrams...
  • Page 73 ¢ Models: ASYG07–14KMCF - 65 - 5-3. Wall mounted type 5. Wiring diagrams...
  • Page 74 ¢ Models: ASYG07–14KETA and ASYG07–14KETA-B - 66 - 5-3. Wall mounted type 5. Wiring diagrams...
  • Page 75 ¢ Models: ASYG07–14KETE and ASYG07–14KETE-B - 67 - 5-3. Wall mounted type 5. Wiring diagrams...
  • Page 76 ¢ Models: ASYG07–14KETF and ASYG07–14KETF-B - 68 - 5-3. Wall mounted type 5. Wiring diagrams...

  • Page 77: Ceiling Type

    5-4. Ceiling type ¢ Model: ABYG18KRTA - 69 - 5-4. Ceiling type 5. Wiring diagrams...

  • Page 78: Floor Type

    5-5. Floor type ¢ Models: AGYG09–14KVCA - 70 - 5-5. Floor type 5. Wiring diagrams...

  • Page 79: Air Velocity And Temperature Distributions

    6. Air velocity and temperature distributions 6-1. Compact cassette type ¢ Models: AUXG07–09KVLA • Air velocity distribution Fan speed Operation mode Measuring conditions HIGH Unit : m/s 0.25 0.25 Top view Horizontal louver: Up 0.25 0.25 4 (m) Unit : m/s Side view Horizontal louver: Up 0.25...
  • Page 80 • Air velocity distribution Fan speed Operation mode Outlet directions Measuring conditions NOTE: Reference data HIGH HEAT 4-way air outlet Unit : m/s Side view Horizontal louver: Down 0.25 0.25 4 (m) • Air temperature distribution Fan speed Operation mode Outlet directions Measuring conditions NOTE: Reference data...
  • Page 81 ¢ Model: AUXG12KVLA • Air velocity distribution Fan speed Operation mode Measuring conditions HIGH Unit : m/s 0.25 0.25 Top view Horizontal louver: Up 0.25 0.25 4 (m) Unit : m/s Side view Horizontal louver: Up 0.25 0.25 4 (m) - 73 - 6-1.
  • Page 82 • Air velocity distribution Fan speed Operation mode Outlet directions Measuring conditions NOTE: Reference data HIGH HEAT 4-way air outlet Unit : m/s Side view Horizontal louver: Down 0.25 0.25 4 (m) • Air temperature distribution Fan speed Operation mode Outlet directions Measuring conditions NOTE: Reference data...
  • Page 83 ¢ Model: AUXG14KVLA • Air velocity distribution Fan speed Operation mode Measuring conditions HIGH Unit : m/s 0.25 Top view Horizontal louver: Up 0.25 0.25 0.25 4 (m) Unit : m/s Side view Horizontal louver: Up 0.25 0.25 4 (m) - 75 - 6-1.
  • Page 84 • Air velocity distribution Fan speed Operation mode Outlet directions Measuring conditions NOTE: Reference data HIGH HEAT 4-way air outlet Unit : m/s Side view Horizontal louver: Down 0.25 4 (m) • Air temperature distribution Fan speed Operation mode Outlet directions Measuring conditions NOTE: Reference data HIGH...
  • Page 85 ¢ Model: AUXG18KVLA Fan speed Operation mode Ceiling mode Measuring conditions HIGH STANDARD Unit: m/s 0.25 Top view Horizontal louver: Up 0.25 0.25 0.25 Unit: m/s Side view Horizontal louver: Up 0.25 0.25 Unit: m/s Side view Horizontal louver: Down 0.25 0.25 - 77 -...

  • Page 86: Mini Duct Type

    6-2. Mini duct type ¢ Model: ARXG07KSLAP NOTE: This data is measured after installing optional Auto louver grille kit. • Air velocity distribution Fan speed Operation mode Measuring conditions HIGH Unit: m/s Top view Horizontal louver: Up Vertical louver: Center Unit: m/s Top view Horizontal louver: Up...
  • Page 87 • Air velocity distribution Fan speed Operation mode Measuring conditions HIGH HEAT Unit: m/s Side view Horizontal louver: Down Vertical louver: Center • Air temperature distribution Fan speed Operation mode Measuring conditions HIGH HEAT Unit: °C Side view Horizontal louver: Down Vertical louver: Center - 79 - 6-2.
  • Page 88 ¢ Model: ARXG09KSLAP NOTE: This data is measured after installing optional Auto louver grille kit. • Air velocity distribution Fan speed Operation mode Measuring conditions HIGH Unit: m/s Top view Horizontal louver: Up Vertical louver: Center Unit: m/s Top view Horizontal louver: Up Vertical louver: Left &...
  • Page 89 • Air velocity distribution Fan speed Operation mode Measuring conditions HIGH HEAT Unit: m/s Side view Horizontal louver: Down Vertical louver: Center • Air temperature distribution Fan speed Operation mode Measuring conditions HIGH HEAT Unit: °C Side view Horizontal louver: Down Vertical louver: Center - 81 - 6-2.
  • Page 90 ¢ Model: ARXG12KSLAP NOTE: This data is measured after installing optional Auto louver grille kit. • Air velocity distribution Fan speed Operation mode Measuring conditions HIGH Unit: m/s Top view Horizontal louver: Up Vertical louver: Center Unit: m/s Top view Horizontal louver: Up Vertical louver: Left &...
  • Page 91 • Air velocity distribution Fan speed Operation mode Measuring conditions HIGH HEAT Unit: m/s Side view Horizontal louver: Down Vertical louver: Center • Air temperature distribution Fan speed Operation mode Measuring conditions HIGH HEAT Unit: °C Side view Horizontal louver: Down Vertical louver: Center - 83 - 6-2.
  • Page 92 ¢ Model: ARXG14KSLAP NOTE: This data is measured after installing optional Auto louver grille kit. • Air velocity distribution Fan speed Operation mode Measuring conditions HIGH Unit: m/s Top view Horizontal louver: Up Vertical louver: Center Unit: m/s Top view Horizontal louver: Up Vertical louver: Left &...
  • Page 93 • Air velocity distribution Fan speed Operation mode Measuring conditions HIGH HEAT Unit: m/s Side view Horizontal louver: Down Vertical louver: Center • Air temperature distribution Fan speed Operation mode Measuring conditions HIGH HEAT Unit: °C Side view Horizontal louver: Down Vertical louver: Center - 85 - 6-2.
  • Page 94 ¢ Model: ARXG18KSLAP NOTE: This data is measured after installing optional Auto louver grille kit. • Air velocity distribution Fan speed Operation mode Measuring conditions HIGH Unit: m/s Top view Horizontal louver: Up Vertical louver: Center Unit: m/s Top view Horizontal louver: Up Vertical louver: Left &...
  • Page 95 • Air velocity distribution Fan speed Operation mode Measuring conditions HIGH HEAT Unit: m/s Side view Horizontal louver: Down Vertical louver: Center • Air temperature distribution Fan speed Operation mode Measuring conditions HIGH HEAT Unit: °C Side view Horizontal louver: Down Vertical louver: Center - 87 - 6-2.

  • Page 96: Slim Duct Type

    6-3. Slim duct type ¢ Model: ARXG07KLLAP NOTE: This data is measured after installing optional Auto louver grille kit. • Air velocity distribution Fan speed Operation mode Measuring conditions HIGH Unit: m/s Top view Horizontal louver: Up Vertical louver: Center Unit: m/s Top view Horizontal louver: Up...
  • Page 97 • Air velocity distribution Fan speed Operation mode Measuring conditions HIGH HEAT Unit: m/s Side view Horizontal louver: Down Vertical louver: Center • Air temperature distribution Fan speed Operation mode Measuring conditions HIGH HEAT Unit: °C Side view Horizontal louver: Down Vertical louver: Center - 89 - 6-3.
  • Page 98 ¢ Model: ARXG09KLLAP NOTE: This data is measured after installing optional Auto louver grille kit. • Air velocity distribution Fan speed Operation mode Measuring conditions HIGH Unit: m/s Top view Horizontal louver: Up Vertical louver: Center Unit: m/s Top view Horizontal louver: Up Vertical louver: Left &...
  • Page 99 • Air velocity distribution Fan speed Operation mode Measuring conditions HIGH HEAT Unit: m/s Side view Horizontal louver: Down Vertical louver: Center • Air temperature distribution Fan speed Operation mode Measuring conditions HIGH HEAT Unit: °C Side view Horizontal louver: Down Vertical louver: Center - 91 - 6-3.
  • Page 100 ¢ Model: ARXG12KLLAP NOTE: This data is measured after installing optional Auto louver grille kit. • Air velocity distribution Fan speed Operation mode Measuring conditions HIGH Unit: m/s Top view Horizontal louver: Up Vertical louver: Center Unit: m/s Top view Horizontal louver: Up Vertical louver: Left &...
  • Page 101 • Air velocity distribution Fan speed Operation mode Measuring conditions HIGH HEAT Unit: m/s Side view Horizontal louver: Down Vertical louver: Center • Air temperature distribution Fan speed Operation mode Measuring conditions HIGH HEAT Unit: °C Side view Horizontal louver: Down Vertical louver: Center - 93 - 6-3.
  • Page 102 ¢ Model: ARXG14KLLAP NOTE: This data is measured after installing optional Auto louver grille kit. • Air velocity distribution Fan speed Operation mode Measuring conditions HIGH Unit: m/s Top view Horizontal louver: Up Vertical louver: Center Unit: m/s Top view Horizontal louver: Up Vertical louver: Left &...
  • Page 103 • Air velocity distribution Fan speed Operation mode Measuring conditions HIGH HEAT Unit: m/s Side view Horizontal louver: Down Vertical louver: Center • Air temperature distribution Fan speed Operation mode Measuring conditions HIGH HEAT Unit: °C Side view Horizontal louver: Down Vertical louver: Center - 95 - 6-3.
  • Page 104 ¢ Model: ARXG18KLLAP NOTE: This data is measured installing the Auto louver grille kit (option). Fan speed Operation mode Measuring conditions HIGH • Air velocity distribution Unit: m/s Top view Horizontal louver: Up Vertical louver: Center Unit: m/s Top view Horizontal louver: Up Vertical louver: Left &...
  • Page 105 Fan speed Operation mode Measuring conditions HIGH HEAT • Air velocity distribution Unit: m/s Side view Horizontal louver: Down Vertical louver: Center • Air temperature distribution Unit: °C Side view Horizontal louver: Down Vertical louver: Center - 97 - 6-3. Slim duct type 6.

  • Page 106: Wall Mounted Type

    6-4. Wall mounted type ¢ Models: ASYG07–09KGTB, ASYG07–09KGTE, ASYG07– 09KGTF, ASYG07–12KMTB, ASYG07–12KMCC, ASYG07– 12KMCE, ASYG07–12KMCF, ASYG07–12KETA, ASYG07– 12KETA-B, ASYG07–12KETE, ASYG07–12KETE-B, ASYG07– 12KETF, and ASYG07–12KETF-B Fan speed Operation mode Measuring conditions HIGH Unit: m/s Top view Horizontal louver: Up Vertical louver: Center Unit: m/s Top view Horizontal louver: Up...
  • Page 107 ¢ Models: ASYG18KMTB and ASYG18KMTE Fan speed Operation mode Measuring conditions HIGH Unit: m/s Top view Horizontal louver: Up Vertical louver: Center Unit: m/s Top view Horizontal louver: Up Vertical louver: Left & Right Unit: m/s Side view Horizontal louver: Up Vertical louver: Center Unit: m/s Side view...
  • Page 108 ¢ Models: ASYG12–14KGTB, ASYG12–14KGTE, ASYG12– 14KGTF, ASYG14KMTB, ASYG14KMCC, ASYG14KMCE, ASYG14KMCF, ASYG14KETA, ASYG14KETA-B, ASYG14KETE, ASYG14KETE-B, ASYG14KETF, and ASYG14KETF-B Fan speed Operation mode Measuring conditions HIGH Unit: m/s Top view Horizontal louver: Up Vertical louver: Center Unit: m/s Top view Horizontal louver: Up Vertical louver: Left &...

  • Page 109: Ceiling Type

    6-5. Ceiling type ¢ Model: ABYG18KRTA Fan speed Operation mode Measuring conditions HIGH Unit: m/s 0.25 Top view Horizontal louver: Up Vertical louver: Center Unit: m/s 0.25 Top view Horizontal louver: Up Vertical louver: Left & Right 0.25 Unit: m/s Side view 0.25 Horizontal louver: Up...

  • Page 110: Floor Type

    6-6. Floor type ¢ Models: AGYG09–14KVCA Fan speed Operation mode Fan select Measuring conditions HIGH Upper and lower Unit: m/s Top view Horizontal louver: Up Vertical louver: Center UPPER LOWER Unit: m/s Top view Horizontal louver: Up Vertical louver: Left & Right Unit: m/s Side view Horizontal louver: Up...

  • Page 111: Fan Performance

    7. Fan performance NOTE: Airflow and capacity/outlet temperature curve data are measured based on the same condi- tions mentioned in "Specifications". 7-1. Mini duct type ¢ Model: ARXG07KSLAP Quiet (SP mode 00) SP mode 03 upper limit Quiet (Normal SP) Quiet (SP mode 03) Hi (SP mode 03) Normal SP upper limit...
  • Page 112  Characteristics of air volume and capacity • Cooling Capacity Airflow (m • Heating Capacity Airflow (m - 104 - 7-1. Mini duct type 7. Fan performance...
  • Page 113 ¢ Model: ARXG09KSLAP Quiet (SP mode 00) SP mode 03 upper limit Quiet (Normal SP) Hi (SP mode 03) Quiet (SP mode 03) SP mode 00 upper limit SP mode 03 lower limit Normal SP upper limit Hi (Normal SP) Hi (SP mode 00) Airflow (m Available airflow rate range (High level)
  • Page 114  Characteristics of air volume and capacity • Cooling Capacity Airflow (m • Heating Capacity Airflow (m - 106 - 7-1. Mini duct type 7. Fan performance...
  • Page 115 ¢ Model: ARXG12KSLAP SP mode 03 upper limit Quiet (SP mode 03) Hi (SP mode 03) Quiet Normal SP (Normal SP) upper limit Quiet SP mode 03 (SP mode 00) lower limit SP mode 00 (Normal SP) upper limit Hi (SP mode 00) Airflow (m Available airflow rate range (High level) Hi (SP mode 03)
  • Page 116  Characteristics of air volume and capacity • Cooling Capacity Airflow (m • Heating Capacity Airflow (m - 108 - 7-1. Mini duct type 7. Fan performance...
  • Page 117 ¢ Model: ARXG14KSLAP Hi (SP mode 05) SP mode 05 upper limit Quiet (SP mode 00) Nomal SP Quiet upper limit (Nomal SP) Quiet Hi (Normal SP) (SP mode 05) SP mode 05 lower limit SP mode 00 upper limit...
  • Page 118  Characteristics of air volume and capacity • Cooling Capacity Airflow (m • Heating Capacity Airflow (m - 110 - 7-1. Mini duct type 7. Fan performance...
  • Page 119 ¢ Model: ARXG18KSLAP SP mode 05 Hi (SP mode 05) upper limit Quiet (SP mode 05) SP mode 05 lower limit Quiet (Normal SP) Quiet (SP mode 00) Normal SP upper limit Hi (Normal SP) Hi (SP mode 00) SP mode 00 upper limit 1,000 1,100...
  • Page 120  Characteristics of air volume and capacity • Cooling Capacity 1,000 1,100 Airflow (m • Heating Capacity 1,000 1,100 Airflow (m - 112 - 7-1. Mini duct type 7. Fan performance...

  • Page 121: Slim Duct Type

    7-2. Slim duct type ¢ Model: ARXG07KLLAP Hi (SP mode 09) SP mode 09 upper limit Quiet (SP mode 09) SP mode 09 lower limit Normal SP upper limit Quiet (Normal SP) Hi (Normal SP) SP mode 00 Normal SP upper limit lower limited Quiet (SP mode 00)
  • Page 122  Characteristics of air volume and capacity • Cooling Capacity Airflow (m • Heating Capacity Airflow (m - 114 - 7-2. Slim duct type 7. Fan performance...
  • Page 123 ¢ Model: ARXG09KLLAP Hi (SP mode 09) SP mode 09 upper limit Quiet (SP mode 09) SP mode 09 lower limit Normal SP upper limit Quiet (Normal SP) Hi (Normal SP) Hi (SP mode00) SP mode 00 upper limit Quiet (SP mode 00) Airflow (m Available airflow rate range (High level) Hi (SP mode 09)
  • Page 124  Characteristics of air volume and capacity • Cooling Capacity Airflow (m • Heating Capacity Airflow (m - 116 - 7-2. Slim duct type 7. Fan performance...
  • Page 125 ¢ Model: ARXG12KLLAP SP mode 09 upper limit Hi (SP mode 09) Quiet (SP mode 09) SP mode 09 lower limit Normal SP upper limit Quiet (Normal SP) Hi (Normal SP) SP mode 00 Hi (SP mode 00) upper limit Quiet (SP mode 00) Airflow (m Available airflow rate range (High level)
  • Page 126  Characteristics of air volume and capacity • Cooling Capacity Airflow (m • Heating Capacity Airflow (m - 118 - 7-2. Slim duct type 7. Fan performance...
  • Page 127 ¢ Model: ARXG14KLLAP SP mode 09 upper limit Hi (SP mode 09) Quiet (SP mode 09) Nomal SP upper limit SP mode 09 lower limit Quiet (Nomal SP) Hi (Normal SP) SP mode 00 upper limit Hi (SP mode 00) Quiet (SP mode 00) 1,000...
  • Page 128  Characteristics of air volume and capacity • Cooling Capacity 1,000 Airflow (m • Heating Capacity 1,000 Airflow (m - 120 - 7-2. Slim duct type 7. Fan performance...
  • Page 129 ¢ Model: ARXG18KLLAP SP mode 09 upper limit Hi (SP mode 09) Quiet (SP mode 09) SP mode 09 lower limit Normal SP upper limit Quiet (Normal SP) SP mode 00 Hi (Normal SP) upper limit Hi (SP mode 00) Quiet (SP mode 00) 1,000 1,100...
  • Page 130  Characteristics of air volume and capacity • Cooling Capacity 1,000 1,100 Airflow (m • Heating Capacitty 1,000 1,100 Airflow (m - 122 - 7-2. Slim duct type 7. Fan performance...

  • Page 131: Airflow

    8. Airflow Conversion factor: • 1 m /h = 0.2778 l/s = 0.5886 CFM • 3.6 m /h = 1 l/s • 1.699 m /h = 1 CFM 8-1. Compact cassette type Airflow Model Operation mode Fan speed High Cooling AUXG07KVLA Quiet AUXG09KVLA...

  • Page 132: Mini Duct Type

    High Heating Quiet High Cooling Quiet ARXG09KSLAP High Heating Quiet High Cooling Quiet ARXG12KSLAP High Heating Quiet High Cooling Quiet ARXG14KSLAP High Heating Quiet High Cooling Quiet ARXG18KSLAP High Heating Quiet - 124 - 8-2. Mini duct type 8. Airflow...

  • Page 133: Slim Duct Type

    8-3. Slim duct type Airflow Model Operation mode Fan speed High Cooling Quiet ARXG07KLLAP High Heating Quiet High Cooling Quiet ARXG09KLLAP High Heating Quiet High Cooling Quiet ARXG12KLLAP High Heating Quiet High Cooling Quiet ARXG14KLLAP High Heating Quiet High Cooling Quiet ARXG18KLLAP High...
  • Page 134 8-4. Wall mounted type Airflow Model Operation mode Fan speed High Cooling Quiet ASYG07KGTB High Heating Quiet High Cooling Quiet ASYG09KGTB High Heating Quiet High Cooling Quiet ASYG12KGTB High Heating Quiet High Cooling Quiet ASYG14KGTB High Heating Quiet High Cooling Quiet ASYG07KGTE High...
  • Page 135 Airflow Model Operation mode Fan speed High Cooling Quiet ASYG12KGTE High Heating Quiet High Cooling Quiet ASYG14KGTE High Heating Quiet High Cooling Quiet ASYG07KGTF High Heating Quiet High Cooling Quiet ASYG09KGTF High Heating Quiet High Cooling Quiet ASYG12KGTF High Heating Quiet High Cooling...
  • Page 136 Airflow Model Operation mode Fan speed High Cooling Quiet ASYG18KMTB High 1,020 Heating Quiet High Cooling Quiet ASYG18KMTE High 1,020 Heating Quiet High Cooling Quiet ASYG07KMTB High Heating Quiet High Cooling Quiet ASYG09KMTB High Heating Quiet High Cooling Quiet ASYG12KMTB High Heating Quiet...
  • Page 137 Airflow Model Operation mode Fan speed High Cooling Quiet ASYG07KMCC High Heating Quiet High Cooling Quiet ASYG09KMCC High Heating Quiet High Cooling Quiet ASYG12KMCC High Heating Quiet High Cooling Quiet ASYG14KMCC High Heating Quiet High Cooling Quiet ASYG07KMCE High Heating Quiet High Cooling...
  • Page 138 Airflow Model Operation mode Fan speed High Cooling Quiet ASYG12KMCE High Heating Quiet High Cooling Quiet ASYG14KMCE High Heating Quiet High Cooling Quiet ASYG07KMCF High Heating Quiet High Cooling Quiet ASYG09KMCF High Heating Quiet High Cooling Quiet ASYG12KMCF High Heating Quiet High Cooling...
  • Page 139 Airflow Model Operation mode Fan speed High Cooling ASYG07KETA Quiet ASYG07KETA-B High Heating Quiet High Cooling ASYG09KETA Quiet High ASYG09KETA-B Heating Quiet High Cooling ASYG12KETA Quiet ASYG12KETA-B High Heating Quiet High Cooling ASYG14KETA Quiet High ASYG14KETA-B Heating Quiet High Cooling ASYG07KETE Quiet High...
  • Page 140 Airflow Model Operation mode Fan speed High Cooling ASYG12KETE Quiet ASYG12KETE-B High Heating Quiet High Cooling ASYG14KETE Quiet High ASYG14KETE-B Heating Quiet High Cooling ASYG07KETF Quiet ASYG07KETF-B High Heating Quiet High Cooling ASYG09KETF Quiet High ASYG09KETF-B Heating Quiet High Cooling ASYG12KETF Quiet High...
  • Page 141 8-5. Ceiling type Airflow Model Operation mode Fan speed High Cooling Quiet ABYG18KRTA High Heating Quiet - 133 - 8-5. Ceiling type 8. Airflow...
  • Page 142 8-6. Floor type Airflow Model Operation mode Fan speed High Cooling Quiet AGYG09KVCA High Heating Quiet High Cooling Quiet AGYG12KVCA High Heating Quiet High Cooling Quiet AGYG14KVCA High Heating Quiet - 134 - 8-6. Floor type 8. Airflow...

  • Page 143: Noise Level Curve

    9. Noise level curve 9-1. Compact cassette type ¢ Model: AUXG07KVLA  Cooling  Heating NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 HIGH NC-45 NC-45 HIGH NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 QUIET QUIET NC-20 NC-20 NC-15 NC-15 1,000 2,000...
  • Page 144 ¢ Model: AUXG12KVLA  Cooling  Heating NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 HIGH NC-45 NC-45 HIGH NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 QUIET QUIET NC-20 NC-20 NC-15 NC-15 1,000 2,000 4,000 8,000 1,000 2,000 4,000 8,000 Octave band center frequency, Hz Octave band center frequency, Hz...
  • Page 145 ¢ Model: AUXG18KVLA  Cooling  Heating NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 HIGH HIGH NC-45 NC-45 NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 QUIET NC-25 QUIET NC-25 NC-20 NC-20 NC-15 NC-15 1,000 2,000 4,000 8,000 1,000 2,000 4,000 8,000 Octave band center frequency, Hz Octave band center frequency, Hz...

  • Page 146: Mini Duct Type

    9-2. Mini duct type ¢ Model: ARXG07KSLAP  Cooling  Heating NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 NC-45 NC-45 NC-40 NC-40 HIGH NC-35 NC-35 HIGH NC-30 NC-30 NC-25 NC-25 NC-20 NC-20 NC-15 NC-15 QUIET QUIET 1,000 2,000 4,000 8,000 1,000 2,000...
  • Page 147 QUIET QUIET NC-15 NC-15 1,000 2,000 4,000 8,000 1,000 2,000 4,000 8,000 Octave band center frequency ,Hz Octave band center frequency ,Hz ¢ Model: ARXG14KSLAP  Cooling  Heating NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 NC-45 NC-45 NC-40...
  • Page 148 ¢ Model: ARXG18KSLAP  Cooling  Heating NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 NC-45 NC-45 NC-40 NC-40 NC-35 NC-35 HIGH HIGH NC-30 NC-30 NC-25 NC-25 NC-20 NC-20 QUIET QUIET NC-15 NC-15 1,000 2,000 4,000 8,000 1,000 2,000 4,000 8,000 Octave band center frequency ,Hz Octave band center frequency ,Hz...

  • Page 149: Slim Duct Type

    9-3. Slim duct type ¢ Model: ARXG07KLLAP  Cooling  Heating NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 NC-45 NC-45 NC-40 NC-40 NC-35 NC-35 HIGH HIGH NC-30 NC-30 NC-25 NC-25 QUIET QUIET NC-20 NC-20 NC-15 NC-15 1,000 2,000 4,000 8,000 1,000 2,000...
  • Page 150 ¢ Model: ARXG12KLLAP  Cooling  Heating NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 NC-45 NC-45 NC-40 NC-40 HIGH HIGH NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 QUIET NC-20 NC-20 QUIET NC-15 NC-15 1,000 2,000 4,000 8,000 1,000 2,000 4,000 8,000 Octave band center frequency, Hz Octave band center frequency, Hz...
  • Page 151 ¢ Model: ARXG18KLLAP  Cooling  Heating NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 NC-45 HIGH NC-45 NC-40 NC-40 HIGH NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 NC-20 QUIET NC-20 QUIET NC-15 NC-15 1,000 2,000 4,000 8,000 1,000 2,000 4,000 8,000 Octave band center frequency, Hz Octave band center frequency, Hz...

  • Page 152: Wall Mounted Type

    9-4. Wall mounted type ¢ Models: ASYG07KGTB, ASYG07KGTE, and ASYG07KGTF  Cooling  Heating NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 NC-45 NC-45 HIGH HIGH NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 NC-20 NC-20 NC-15 NC-15 QUIET QUIET 1,000 2,000 4,000...
  • Page 153 ¢ Models: ASYG12KGTB, ASYG12KGTE, and ASYG12KGTF  Cooling  Heating NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 HIGH NC-45 NC-45 HIGH NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 NC-20 NC-20 NC-15 NC-15 QUIET QUIET 1,000 2,000 4,000 8,000 1,000 2,000 4,000...
  • Page 154 ¢ Models: ASYG18KMTB and ASYG18KMTE  Cooling  Heating NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 HIGH HIGH NC-45 NC-45 NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 NC-20 NC-20 QUIET NC-15 NC-15 QUIET 1,000 2,000 4,000 8,000 1,000 2,000 4,000 8,000...
  • Page 155 ¢ Models: ASYG09KMTB, ASYG09KMCC, ASYG09KMCE, ASYG09KMCF, ASYG09KETA, ASYG09KETA-B, ASYG09KETE, ASYG09KETE-B, ASYG09KETF, and ASYG09KETF-B  Cooling  Heating NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 HIGH HIGH NC-45 NC-45 NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 NC-20 NC-20 NC-15 NC-15 QUIET QUIET...
  • Page 156 ¢ Models: ASYG14KMTB, ASYG14KMCC, ASYG14KMCE, ASYG14KMCF, ASYG14KETA, ASYG14KETA-B, ASYG14KETE, ASYG14KETE-B, ASYG14KETF, and ASYG14KETF-B  Cooling  Heating NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 HIGH HIGH NC-45 NC-45 NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 NC-20 NC-20 QUIET NC-15 NC-15 QUIET...

  • Page 157: Ceiling Type

    9-5. Ceiling type ¢ Model: ABYG18KRTA  Cooling  Heating NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 HIGH HIGH NC-50 NC-50 NC-45 NC-45 NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 QUIET QUIET NC-25 NC-25 NC-20 NC-20 NC-15 NC-15 1,000 2,000 4,000 8,000 1,000 2,000 4,000...

  • Page 158: Floor Type

    9-6. Floor type ¢ Model: AGYG09KVCA  Cooling  Heating NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 HIGH HIGH NC-50 NC-50 NC-45 NC-45 NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 QUIET QUIET NC-20 NC-20 NC-15 NC-15 1,000 2,000 4,000 8,000 1,000 2,000 4,000...
  • Page 159 ¢ Model: AGYG14KVCA  Cooling  Heating NC-65 NC-65 NC-60 NC-60 HIGH NC-55 NC-55 HIGH NC-50 NC-50 NC-45 NC-45 NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 QUIET QUIET NC-20 NC-20 NC-15 NC-15 1,000 2,000 4,000 8,000 1,000 2,000 4,000 8,000 Octave band center frequency, Hz Octave band center frequency, Hz...

  • Page 160: Sound Level Check Point

    9-7. Sound level check point ¢ Compact cassette type Microphone 1.5 m Microphone - 152 - 9-7. Sound level check point 9. Noise level curve...
  • Page 161 ¢ Mini duct type Measuring duct Measuring duct Set the static pressure as rating in this area Microphone Microphone Side view Front view ¢ Slim duct type Measuring duct Measuring duct Set the static pressure as rating in this area Microphone Microphone Side view...
  • Page 162 ¢ Ceiling type Microphone Microphone ¢ Floor type Microphone Microphone ● ● Airflow Airflow - 154 - 9-7. Sound level check point 9. Noise level curve...

  • Page 163: Electrical Characteristics

    AUXG12KVLA 0.24 0.19 AUXG14KVLA 0.28 0.22 AUXG18KVLA 0.38 0.30 ARXG07KSLAP 0.33 0.29 ARXG09KSLAP 0.38 0.33 Mini duct ARXG12KSLAP 0.42 0.38 ARXG14KSLAP 0.67 0.58 ARXG18KSLAP 0.61 0.49 ARXG07KLLAP 0.41 0.33 ARXG09KLLAP 0.38 0.30 Slim duct ARXG12KLLAP 0.44 0.35 ARXG14KLLAP 0.64 0.51 ARXG18KLLAP 0.55...
  • Page 164 Wiring spec. of connection Power supply cable Indoor rated (50 Hz, 230 V) (Indoor unit to outdoor unit) Cross- Limited Input sectional wiring power Type Model name area length ASYG07KETA 0.25 0.20 ASYG07KETA-B ASYG09KETA 0.30 0.24 ASYG09KETA-B ASYG12KETA 0.30 0.24 ASYG12KETA-B ASYG14KETA 0.38...

  • Page 165: Safety Devices

    Compact AUXG12KVLA cassette Reset: 95 ±10°C AUXG14KVLA Fan motor restart AUXG18KVLA ARXG07KSLAP ARXG09KSLAP Mini duct ARXG12KSLAP Activate: 135 ±15°C ARXG14KSLAP Fan motor stop 250 V, 5 A ― ○ ARXG18KSLAP Reset: 105 ±15°C ARXG07KLLAP Fan motor restart ARXG09KLLAP ARXG12KLLAP ARXG14KLLAP Slim duct Activate: 135 ±15°C...
  • Page 166 Terminal Indoor unit Float Model name PCB* fuse Fan motor thermal protector thermal type switch fuse ASYG07KGTB Activate: 110 ±15°C Fan motor speed down Reset: 110 ±15°C ASYG09KGTB Fan motor speed recover ASYG12KGTB Activate: 125 ±10°C Fan motor stop Reset: 100 ±10°C ASYG14KGTB Fan motor restart ASYG07KGTE...
  • Page 167 Terminal Indoor unit Float Model name PCB* fuse Fan motor thermal protector thermal type switch fuse ASYG07KMCC ASYG09KMCC ASYG12KMCC ASYG14KMCC Activate: 170 °C ASYG07KMCE Fan motor stop ASYG09KMCE ― ASYG12KMCE Reset: 145 °C ASYG14KMCE Fan motor restart ASYG07KMCF ASYG09KMCF ASYG12KMCF ASYG14KMCF ASYG07KETA ASYG07KETA-B...

  • Page 168: External Input And Output

    12. External input and output 12-1. Compact cassette type, Mini duct type, and Slim duct type Exterior of the indoor unit PCB and the component location differ by the type of the indoor unit as follows. • Compact cassette type: Indoor unit PCB CN47 (Ext.
  • Page 169 ¢ External input With using external input function, some functions on this product can be controlled from an external device. • “Operation/Stop” mode or "Forced stop" mode can be selected with function setting of indoor unit. • A twisted pair cable (22AWG) should be used. Maximum length of cable is 150 m. •...
  • Page 170 ¢ Combination of external input and output By combining the function setting of the indoor unit, you can select various combinations of func- tions. Combination examples of external input and output are as follows: External input External output Mode Function setting Terminal CN47 60—00...
  • Page 171 ¢ Details of function  Control input function • When function setting is "Operation/Stop" mode 1 Function setting External input Input signal Command Off → On Operation 46—00 Terminal On → Off Stop Input Operation Indoor unit Stop Remote controller NOTES: •...
  • Page 172 • When function setting is "Operation/Stop" mode 2 Function setting External input Input signal Command Off → On Operation 46—03 Terminal Stop (Remote controller On → Off disabled) Input Operation Indoor unit Stop (R.C. disabled) Remote controller NOTE: When "Operation/Stop" mode 2 function is used with forming a remote controller group, connect the same equipment to each indoor unit within the group.
  • Page 173  Indoor unit fan operation status Function setting External output Output signal Command Low → High Fan run 60—10 CN47 High → Low Fan stop Output signal Condition The indoor unit fan is operating. Low → High The fan is stopped or during cold air prevention. During thermostat off when in dry mode operation.

  • Page 174: 12-2.Wall Mounted Type (Kgtb, 18-24Kmtb, Keta, And Keta-B)

    12-2. Wall mounted type (KGTB, 18-24KMTB, KETA, and KETA- External input and output PCB SW301 SW302 Rotary switch CN314 CN313 CN312 CN311 CN310 CN308 To CN6 on Indoor unit PCB Input External input External output Connector Input select signal Operation/Stop CN313/ Edge/Pulse Dry contact/...
  • Page 175 ¢ External input With using external input function, some functions on this product can be controlled from an external device. • “Operation/Stop” mode or "Forced stop" mode can be selected with function setting of indoor unit. • A twisted pair cable should be used. Maximum length of cable is 150 m. •...
  • Page 176 ¢ External output Use an external output cable with appropriate external dimension, depending on the number of ca- bles to be installed.  External Input and Output PCB • A twisted pair cable (22AWG) should be used. Maximum length of cable is 25 m. •...
  • Page 177 ¢ Combination of external input and output By combining the function setting of the indoor unit and rotary switch setting of the External Input and Output PCB, you can select various combinations of functions. Combination examples of external input and output are as follows: External input External Input Function...
  • Page 178  Input signal type External Input and Output PCB: The input signal type can be selected. Signal type (edge or pulse) can be switched by the DIP switch SW302 on the External Input and Output PCB. The width of pulse must be longer than 200 msec.
  • Page 179 ¢ Details of function  Control input function • When function setting is "Operation/Stop" mode 1 – In the case of "Edge" input: Rotary SW on Function External Input and External input Input signal Command setting / Output PCB Off → On Operation External Input and 46-00...
  • Page 180 • When function setting is "Forced stop" mode – In the case of "Edge" input: Rotary SW on Function External Input and External input Input signal Command setting / Output PCB Off → On Forced stop External Input and 46-02 60-00 / 1 CN313 Output PCB...
  • Page 181 • When function setting is "Operation/Stop" mode 2 – In the case of "Edge" input: Rotary SW on Function External Input and External input Input signal Command setting / Output PCB Off → On Operation Stop External Input and 46-03 60-00 / 1 CN313 (Remote...
  • Page 182 • Forced thermostat off function Rotary SW on Function External Input and External input Input signal Command setting / Output PCB Thermostat 60-00 / 2 Off → On External Input and Output 60-09 / B CN313 Normal 60-10 / C On →...
  • Page 183  Control output function • Operation/Stop status Rotary SW on Function Output External Input and External output Command setting / signal Output PCB Off → On Operation External Input and Output 60-00 / 1 CN310 On → Off Stop The output is low when the unit is stopped. Operation Indoor unit Stop...

  • Page 184: 12-3.Wall Mounted Type (07-14Kmtb And Kmcc)

    12-3. Wall mounted type (07-14KMTB and KMCC) With using external input and output functions, this product can be operated inter-connectedly with an external device. Connector Input Output Remarks CNA01 Control input — See external input/output CNB01 — Operation status output settings for details.

  • Page 185: Remote Controller

    • Circuit diagram example • Contact capacity: DC 24 V or more, 10 Indoor unit mA or more. Communication kit Connected unit control PCB • *: Make the distance from the PCB to Example: Switch Connector the connected unit within 10 m. •...
  • Page 186 • Optional part Part name Model name Exterior External input wire External Connect Kit UTY-XWZXZ5 Communication Kit UTY-TWBXF2 * For operating the external function, the wall mounted type requires the communication kit in addi- tion to the wire (UTY-XWZXZ5). - 178 - 12-3.
  • Page 187 ¢ External output With using external output function, operating status of this product can be transmitted to the exter- nal device, and also, this product can be inter-connected with the external device.  Operation status output Air conditioner operation status signal can be output. •...
  • Page 188  Error status output Air conditioner error status signal can be output. • Circuit diagram example: Indoor unit control PCB Communication kit Connected unit Connector DC 24 V Example: Relay unit Example: Display Relay power supply 10 m* Signal Optional parts Locally purchased –...
  • Page 189 12-4. Wall mounted type (KGTE, KGTF, KMTE, KMCE, KMCF, KETE, KETE-B, KETF, and KETF-B) External input and output PCB Indoor unit PCB CN47 (Ext. out) CN65 (Ext. in/out PCB) CN46 (Ext. in) SW301 SW302 Rotary switch CN314 CN313 CN312 CN311 CN310 CN308 Input...
  • Page 190 ¢ External input With using external input function, some functions on this product can be controlled from an external device. • “Operation/Stop” mode or "Forced stop" mode can be selected with function setting of indoor unit. • A twisted pair cable should be used. Maximum length of cable is 150 m. •...
  • Page 191  External Input and Output PCB The indoor unit Operation/Stop can be set by using the input connector on the PCB. • Input select: Use either one of these types of connectors according to the application. (Both types of connec- tors cannot be used simultaneously.) –...
  • Page 192 ¢ External output Use an external output cable with appropriate external dimension, depending on the number of ca- bles to be installed.  Indoor unit • A twisted pair cable should be used. Maximum length of cable is 25 m. •...
  • Page 193  External Input and Output PCB • A twisted pair cable should be used. Maximum length of cable is 25 m. • Output voltage: High DC 12 V±2 V, Low 0 V. • Permissible current: 50 mA • For details, refer to "Combination of external input and output"...
  • Page 194 ¢ Combination of external input and output By combining the function setting of the indoor unit and rotary switch setting of the External Input and Output PCB, you can select various combinations of functions. Combination examples of external input and output are as follows: External input Function Rotary...
  • Page 195  Input signal type External Input and Output PCB: The input signal type can be selected. Signal type (edge or pulse) can be switched by the DIP switch SW302 on the External Input and Output PCB. The width of pulse must be longer than 200 msec.
  • Page 196 ¢ Details of function  Control input function • When function setting is “Operation/Stop” mode 1 – In the case of “Edge” input: Function Rotary SW on External External input Input signal Command setting Input and Output PCB Off → On Operation External Input and 46-00...
  • Page 197 • When function setting is “Forced stop” mode – In the case of “Edge” input: Function Rotary SW on External External input Input signal Command setting Input and Output PCB Off → On Forced stop External Input and 46-02 CN313 Output PCB On →...
  • Page 198 • When function setting is “Operation/Stop” mode 2 – In the case of “Edge” input: Function Rotary SW on External External input Input signal Command setting Input and Output PCB Off → On Operation Stop External Input and 46-03 CN313 (Remote Output PCB On →...
  • Page 199 • Forced thermostat off function Rotary SW on Input Function setting / External Input External input Command signal and Output PCB Thermostat 60-00 Off → On External Input and 60-09 CN313 Output PCB Normal On → Off 60-10 operation Input Compressor Room temp.
  • Page 200  Control output function • Operation/Stop status Rotary SW on Output Function setting / External Input External output Command signal and Output PCB 60-00 / 1 Off → On Operation Output of indoor unit CN47 60-00 / 2 On → Off Stop 60-00 / 1 Off →...
  • Page 201 • Indoor unit fan operation status Rotary SW on Output Function setting / External Input External output Command signal and Output PCB Off → On Fan run 60-10 / C Output of indoor unit CN47 On → Off Fan stop 60-00 / 2 Off →...
  • Page 202 12-5. Ceiling type Rotary switch CN65 CN47 (Ext.in/out PCB) (Ext.out) Terminal (Ext.in) Fig. Indoor unit PCB Fig. External input and output PCB External Input connect kit External input External output Connector Input select signal (Optional parts) Operation/Stop — Terminal Dry contact Edge —...
  • Page 203  External input and output PCB The indoor unit Operation/Stop can be set by using the input terminal on the PCB.  Input select Use either one of these types of terminals according to the application. (Both types of terminals cannot be used simultaneously.) •...
  • Page 204 ¢ External output Use an external output cable with appropriate external dimension, depending on the number of ca- bles to be installed.  Indoor unit • A twisted pair cable (22AWG) should be used. Maximum length of cable is 25 m. •...
  • Page 205 ¢ Combination of external input and output By combining the function setting of the indoor unit and rotary switch setting of the External input and output PCB, you can select various combinations of functions. Combination examples of external input and output are as follows: External input External input Function...
  • Page 206  Input signal type • Indoor unit Input signal type is only "Edge". Edge • External input and output PCB The input signal type can be selected. Signal type (edge or pulse) can be switched by the DIP switch 2 (SW2) on the External input and output PCB.
  • Page 207 ¢ Details of function  Control input function • When function setting is "Operation/Stop" mode 1 – In the case of "Pulse" input Rotary SW of Function External input and External input Input signal Command setting / output PCB Input 1 Pulse Operation External input and...
  • Page 208 • When function setting is "Forced stop" mode – In the case of "Edge" input Rotary SW of Function External input and External input Input signal Command setting / output PCB Off → On Forced stop Input of indoor unit Terminal On →...
  • Page 209 • When function setting is "Operation/Stop" mode 2 – In the case of "Edge" input Rotary SW of Function External input and External input Input signal Command setting / output PCB Off → On Operation Stop Input of indoor unit Terminal (Remote On →...
  • Page 210  Forced thermostat off function Function Rotary SW of External External input Input signal Command setting / input and output PCB 60-00 / 2 Off → On Thermostat off 60-09 / B External input and output Input 1 60-10 / C Normal On →...
  • Page 211  Error status Function Rotary SW of External External output Output signal Command setting / input and output PCB Low → High Error 60-09 / B Output of indoor unit CN47 High → Low Normal Off → On Error 60-00 / 2 Output 1 On →...
  • Page 212  External heater output Function Rotary SW of External External output Output signal Command setting / input and output PCB Low → High Heater on 60-11 / D Output of indoor unit CN47 High → Low Heater off 60-00 / 2 Off →...
  • Page 213 12-6. Floor type Indoor unit PCB CN 23 CN 21 CN 15 CN 14 P 190 External input External output Connector Input signal Operation/Stop CN14 Forced stop — Edge Forced thermostat off CN15 Operation status Indoor unit Error status CN20/CN21/ —...
  • Page 214 ¢ External output Use an external output cable with appropriate external dimension, depending on the number of ca- bles to be installed.  Indoor unit • A twisted pair cable (22AWG) should be used. Maximum length of cable is 25 m . •...
  • Page 215 ¢ Combination of external input and output By combining the function setting of the indoor unit, you can select various combinations of func- tions. Combination examples of external input and output are as follows: External input Function Mode Indoor unit setting CN14 CN15...
  • Page 216 ¢ Details of function  Control input function • When function setting is "Operation/Stop" mode 1 – In the case of "Edge" input Mode Function setting External input Input signal Command Off → On Operation — CN14 On → Off Stop 46-00 Input of indoor unit...
  • Page 217 • When function setting is "Operation/Stop"mode 2 – In the case of "Edge" input Mode Function setting External input Input signal Command Off → On Operation Stop — CN14 (Remote On → Off controller disabled) 46-03 Input of indoor unit Off →...
  • Page 218  Control output function • Operation/Stop status Output Mode Function setting External output Command signal Low → High Operation 60-00 CN15 High → Low Stop Output of indoor unit Off → On Operation 60-00 CN20 On → Off Stop The output is low when the unit is stopped. Operation Indoor unit Stop...
  • Page 219 • Indoor unit fan operation status Output Mode Function setting External output Command signal Low → High Fan run 60-10 CN15 High → Low Fan stop Output of indoor unit Off → On Fan run 60-00 CN22 On → Off Fan stop Output signal Condition...
  • Page 220 • Design and install external heater appropriately with considering its protection. • Inappropriate designing and installation of external heater may cause a fire by emitted heat from the external heater. • Fujitsu General Ltd. is not responsible for inappropriate designing or installation of external heating device. - 212 - 12-6.
  • Page 221 • Auxiliary heater control 1 Operation Condition Heater on Heater is on as shown in following diagram of heating temperature. • Heater is off as shown in following diagram of heating temperature. • Other than heating mode Heater off • Error occurred •...
  • Page 222 13. Group connection NOTE: Group control cannot be used together with WLAN Adapter. Installation procedure for group control system: A number of indoor units can be operated at the same time using a single remote controller. NOTE: When different type of indoor units (such as wall mounted type and cassette type, cassette type and duct type, or other combinations) are connected using group control system, some functions may no longer be available.
  • Page 223 2. Set the remote controller address. (Function setting) • Addresses will be automatically set when initially starting up this unit. In such a case, do not change the remote controller address for the indoor unit, and keep it at the initial setting of “00”.

  • Page 224: Part 2. Outdoor Unit (3 Units Type)

    14. Remote controller 14-1. Wireless remote controller (AR-REW4E, AR-REM4E, and AR-REB1E) ¢ Overview AR-REW4E Signal transmitter MODE button FAN button 10°C HEAT button SWING button ECONOMY button TEMP. button OUTDOOR UNIT SET button LOW NOISE button POWERFUL button WEEKLY button TIMER SETTING button Start/Stop button...
  • Page 225 To facilitate explanation, the accompanying illustration has been drawn to show all possible indicators; in actual operation, however, the display will only show those indicators appropriate to the current oper- ation. - 217 - 14-1. Wireless remote controller (AR-REW4E, AR-REM4E, and AR-REB1E) 14.
  • Page 226 AR-REM4E Signal SENSOR button transmitter MODE button FAN button 10°C HEAT button SWING button ECONOMY button TEMP. button OUTDOOR UNIT SET button LOW NOISE button POWERFUL button WEEKLY button TIMER SETTING button Start/Stop button ON/OFF button SEND button SLEEP button SELECT button RESET button NEXT button...
  • Page 227 AR-REB1E Signal transmitter MODE button FAN button 10°C HEAT button ECONOMY button SWING button OUTDOOR UNIT SET button LOW NOISE button TEMP. button ON TIMER button POWERFUL button OFF TIMER button Start/Stop button TIMER SELECT button RESET button SLEEP TIMER button CLOCK ADJUST button TIMER CANCEL button NOTE: Functions may differ by type of the indoor unit.

  • Page 228: Specifications

    ¢ Specifications  Controller Unit: mm Top view Front view Side view Size (H × W × D) 205 × 61 × 17 Weight 124 (without batteries)  Holder Unit: mm 48.5 Ø 3.5 (Hole) Hole 26.2 69.3 Front View Side View Bottom View Size (H ×...
  • Page 229 14-2. Wireless remote controller (AR-REW3E) ¢ Overview Signal SENSOR button transmitter MODE button FAN button 10°C HEAT button SWING button ECONOMY button TEMP. button OUTDOOR UNIT SET button LOW NOISE button POWERFUL button WEEKLY button TIMER SETTING button Start/Stop button ON/OFF button SEND button SLEEP button...
  • Page 230 ¢ Specifications  Controller Unit: mm Top view Front view Side view Size (H × W × D) 205 × 61 × 17 Weight 124 (without batteries)  Holder Unit: mm 48.5 Ø 3.5 (Hole) Hole 26.2 69.3 Front View Side View Bottom View Size (H ×...
  • Page 231 14-3. Wireless remote controller (AR-REW2E) ¢ Overview Signal transmitter MODE button FAN button 10°C HEAT button SWING button ECONOMY button TEMP. button OUTDOOR UNIT SET button LOW NOISE button POWERFUL button WEEKLY button TIMER SETTING button Start/Stop button ON/OFF button SEND button SLEEP button SELECT button...
  • Page 232 ¢ Specifications  Controller Unit: mm Top view Front view Side view Size (H × W × D) 205 × 61 × 17 Weight 125 (without batteries)  Holder Unit: mm 48.5 Ø 3.5 (Hole) Hole 26.2 69.3 Front View Side View Bottom View Size (H ×...
  • Page 233 14-4. Wireless remote controller (AR-REM7E) ¢ Overview Signal transmitter MODE button FAN button 10 °C HEAT button SWING button ECONOMY button TEMP. button OUTDOOR UNIT SET button LOW NOISE button POWERFUL button WEEKLY button TIMER SETTING button Start/Stop button ON/OFF button SEND button SLEEP button SELECT button...
  • Page 234 ¢ Specifications  Controller Unit: mm Top view Front view Side view Size (H × W × D) 205 × 61 × 17 Weight 124 (without batteries)  Holder Unit: mm 48.5 Ø 3.5 (Hole) Hole 26.2 69.3 Front View Side View Bottom View Size (H ×...
  • Page 235 14-5. Wireless remote controller (AR-RMB1E) ¢ Overview Signal transmitter MODE button FAN button 10°C HEAT button ECONOMY button SWING button OUTDOOR UNIT SET button LOW NOISE button TEMP. button ON TIMER button POWERFUL button OFF TIMER button Start/Stop button TIMER SELECT button RESET button SLEEP TIMER button TEST RUN button...
  • Page 236 ¢ Specifications  Controller Unit: mm Top view Front view Side view Size (H × W × D) 205 × 61 × 17 Weight 124 (without batteries)  Holder Unit: mm 48.5 Ø 3.5 (Hole) Hole 26.2 69.3 Front View Side View Bottom View Size (H ×...
  • Page 237 14-6. Wireless remote controller (UTY-LNTY: Optional part) ¢ Overview Signal transmitter MODE button FAN button 10°C HEAT button TEMP. SWING button button SET button Economy button ON TIMER button OFF TIMER button Start/Stop button REG1U TIMER SELECT button RESET button SLEEP TIMER button TEST RUN button TIMER CANCEL button...
  • Page 238 ¢ Specifications  Controller Unit: mm Top view Front view Side view Size (H × W × D) 205 × 61 × 17 Weight 124 (without batteries)  Holder Unit: mm 48.5 Ø 3.5 (Hole) Hole 26.2 69.3 Front View Side View Bottom View Size (H ×...
  • Page 239 14-7. IR receiver kit with Wireless remote controller (UTY- LBTYM: Optional part) ¢ Overview Signal transmitter FAN button MODE button 10°C HEAT button TEMP. SWING button button SET button Economy button ON TIMER button OFF TIMER button Start/Stop button REG1U TIMER SELECT button RESET button SLEEP TIMER button...
  • Page 240 ¢ Specifications  Controller Unit: mm Top view Front view Side view Size (H × W × D) 205 × 61 × 17 Weight 124 (without batteries)  Holder Unit: mm 48.5 Ø 3.5 (Hole) Hole 26.2 69.3 Front View Side View Bottom View Size (H ×...
  • Page 241  IR receiver Unit: mm 13.6 57.4 13.6 11.5 18.5 Front view Side view Rear view Size (H × W × D) 145 × 90 × 30 Weight - 233 - 14-7. IR receiver kit with Wireless remote controller (UTY-LBTYM: Optional part) 14.
  • Page 242 14-8. Wired remote controller (UTY-RNNYM: Optional part) ¢ Overview a START/STOP button Starts and stops operation. b SET TEMP. button Selects the setting temperature. c MODE button Selects the operating mode (AUTO , HEAT ,FAN COOL , and DRY d FAN button Selects the fan speed AUTO ,QUIET , LOW...
  • Page 243 ¢ System diagram 1 remote controller: 2 remote controllers: Indoor unit Indoor unit A, B, C: Remote controller cable A ≤ 500 m;B + C ≤ 500 m Primary Secondary Remote controllers Remote controller ¢ Electrical wiring 1 remote controller: 2 remote controllers: Indoor unit Indoor unit...
  • Page 244 ¢ Specifications Dimensions and other specifications on the wired remote controller are as follows. Unit: mm Front view Side view Size (H × W × D) 120 × 120 × 18 Weight Cable length (accessory) Power  Wiring specifications Cable size Wire type Remarks Remote controller cable...
  • Page 245  When connecting to Communication Kit (for KM models in Wall mounted type) When connecting the remote controller to optional Communication Kit, follow the procedures men- tioned below. Modify the remote controller cable as follows: • Use a tool to cut off the terminal on the end of the remote controller cable and then remove the insulation from the cut end of the cable as shown in following figure.
  • Page 246 14-9. Wired remote controller (UTY-RLRY: Optional part) ¢ Overview a LED lamp (Operation indicator) Lights while the indoor unit is operating. Blinks when an error occurred. b FAN button Each time the button is pressed, fan speed switches as follows: Auto High Quiet...
  • Page 247 ¢ System diagram 1 remote controller: 2 remote controllers: Indoor unit Indoor unit A, B, C: Remote controller cable A ≤ 500 m;B + C ≤ 500 m Primary Secondary Remote controllers Remote controller ¢ Electrical wiring 1 remote controller: 2 remote controllers: Indoor unit Indoor unit...
  • Page 248 ¢ Specifications Dimensions and other specifications on the wired remote controller are as follows. Unit: mm Hole: 9 × 4.5 Hole: 12.5 × 4.5 Hole: 6 × 4.5 Front view Side view Rear view Size (H × W × D) 120 ×...
  • Page 249 14-10. Wired remote controller (UTY-RVNYM: Optional part) ¢ Overview a Display panel (with backlight) b Screen switch button (Left) c Menu button d Cancel button e Cursor button f Screen switch button (Right) g Power indicator h On/off button i Enter button - 241 - 14-10.
  • Page 250 ¢ System diagram 1 remote controller: 2 remote controllers: Indoor unit Indoor unit A, B, C: Remote controller cable A ≤ 500 m;B + C ≤ 500 m Primary Secondary Remote controllers Remote controller ¢ Electrical wiring 1 remote controller: 2 remote controllers: Indoor unit Indoor unit...
  • Page 251 ¢ Specifications Unit: mm 21.3 Front view Side view Size (H × W × D) 120 × 120 × 21.3 Weight  Wiring specifications Cable size Wire type Remarks Remote controller cable Polar 3 core Use sheathed PVC cable. 0.33 mm - 243 - 14-10.
  • Page 252 ¢ Installation (Remote control main unit) Installation space: Unit : mm or more or more or more 220 or more* NOTE: Secure enough space where a flat-blade screwdriver to remove the case can be inserted. Installation procedures: 1. Process the remote controller cable. Unit : mm 1.
  • Page 253 3. Attach the remote controller. • When attaching to switch box: a. Seal the wiring hole of the remote controller cable. b. Put a remote controller cable through the hole of the rear case. c. Fix the rear case by securing it with attached screws (2 places). •...
  • Page 254 4. Connect the cable to the terminals on the front case. Fix the cable together with the sheath with the cable tie. Cut off the excess cable tie. Tightening torque Terminal screw 0.8 to 1.2 N•m 1. 12V (Red) 2. Signal (White) 3.
  • Page 255 5. Attach the front case. • Insert after adjusting upper part of front case. • When insert the front case, do not pinch the cable. Front case Click! Good Prohibited Prohibited Prohibited CAUTION Insert the upper case firmly. If improperly attached, it will cause the upper case to fall off. ¢...
  • Page 256  When connecting to Communication Kit (for KM models in Wall mounted type) When connecting the remote controller to optional Communication Kit, follow the procedures men- tioned below. Modify the remote controller cable as follows: • Use a tool to cut off the terminal on the end of the remote controller cable and then remove the insulation from the cut end of the cable as shown in following figure.
  • Page 257 14-11. Wired remote controller (UTY-RNRYZ*: Optional part) ¢ Overview a Remote temperature sensor (inside) b On/off button Operable only while displaying the “Monitor mode” screen. c LED lamp (operation indicator) d Touch panel display e Set temperature Operating temperature can be set. f Remote controller group name g Mode Operation mode can be set.
  • Page 258 ¢ System diagram 1 remote controller: 2 remote controllers: Indoor unit Indoor unit A, B, C: Remote controller cable A ≤ 500 m;B + C ≤ 500 m Primary Secondary Remote controllers Remote controller ¢ Electrical wiring 1 remote controller: 2 remote controllers: Indoor unit Indoor unit...
  • Page 259 ¢ Specifications Dimensions and other specifications on the wired remote controller are as follows. [Unit : mm] 20.4 Model name UTY-RNRYZ* Display 3.8-inch FSTN LCD (255 × 160 dots) with touch panel Dimensions (H × W × D) 120 × 120 × 20.4 Weight Input voltage DC 12...
  • Page 260 14-12. Simple remote controller (UTY-RSNYM: Optional part) ¢ Overview a START/STOP button Starts and stops operation. b Display backlight button Lights during operation. c Operation lamp Lights during operation. d FAN button Selects the fan speed (AUTO ,HIGH , MED , and QUIET ).
  • Page 261 ¢ System diagram 1 remote controller: 2 remote controllers: Indoor unit Indoor unit A, B, C: Remote controller cable A ≤ 500 m;B + C ≤ 500 m Primary Secondary Remote controllers Remote controller ¢ Electrical wiring 1 remote controller: 2 remote controllers: Indoor unit Indoor unit...
  • Page 262 ¢ Specifications Dimensions and other specifications on the wired remote controller are as follows. Unit: mm hole x 2 hole x 2 Front View Side View Rear View Size (H × W × D) 120 × 75 × 14 Weight Cable length (accessory) Power ...
  • Page 263  When connecting to Communication Kit (for KM models in Wall mounted type) When connecting the remote controller to optional Communication Kit, follow the procedures men- tioned below. Modify the remote controller cable as follows: • Use a tool to cut off the terminal on the end of the remote controller cable and then remove the insulation from the cut end of the cable as shown in following figure.
  • Page 264 14-13. Wired remote controller (UTY-RCRYZ1: Optional part) ¢ Overview a Display panel b MODE button c Menu button buttons (Set temperature buttons) e FAN button f On/off button g Wireless remote controller signal receiving section - 256 - 14-13. Wired remote controller (UTY-RCRYZ1: Optional part) 14.
  • Page 265 ¢ System diagrams • Single remote control I.U. Remote controller cable A ≤ 500 m ¢ Electrical wiring Indoor unit Remote controller - 257 - 14-13. Wired remote controller (UTY-RCRYZ1: Optional part) 14. Remote controller...
  • Page 266 ¢ Specifications Unit: mm Hole × 2 (for M4 screws) Size (H × W × D) 86 × 86 × 32 Weight  Wiring specifications Cable size Wire type Remarks Remote controller 0.33 to 1.25 mm Non polar 2-core Use sheathed twist pair cable.* cable (22 to 16 AWG) *: Use shielded cable (locally purchased) in accordance with the regional cable standard.
  • Page 267 • Pattern B 1. Use a tool to cut off the terminal on the end of the remote controller cable, and then remove the insulation from the cut end of the cable as shown below. 20 mm Remote controller cable (Non-polar) 2.
  • Page 268 14-14. Simple remote controller (UTY-RSRY and UTY-RHRY: Optional parts) ¢ Overview a LED lamp Lights during operation. b Louver button Adjusts the airflow direction. c START/STOP button Starts and stops operation. d FAN control button Switches the fan speed as follows: Auto High Quiet...
  • Page 269 ¢ System diagram 1 remote controller: 2 remote controllers: Indoor unit Indoor unit A, B, C: Remote controller cable A ≤ 500 m;B + C ≤ 500 m Primary Secondary Remote controllers Remote controller ¢ Electrical wiring 1 remote controller: 2 remote controllers: Indoor unit Indoor unit...
  • Page 270 ¢ Specifications Dimensions and other specifications on the wired remote controller are as follows. Unit: mm 30.0 30.0 Hole: 9 × 4.5 23.0 Hole: 6 × 4.5 Hole: 12.5 × 4.5 Front View Side View Rear View Size (H × W × D) 120 ×...
  • Page 271 15. Function settings To adjust the functions of this product according to the installation environment, various types of function settings are available. NOTE: Incorrect settings can cause a product malfunction. 15-1. Compact cassette, Mini duct, Slim duct types indoor unit (setting by DIP switch) By using some components on the PCB, you can change the function settings.
  • Page 272 ¢ DIP switch setting • SW100: Remote controller address setting When operating a number of indoor units by using a wired remote controller, DIP switch set- ting for assigning unit number to each indoor unit is required. The slide switches are normally set to make the unit number 00. Remote Switch number controller...
  • Page 273 15-2. Indoor unit (setting by wireless remote controller) CAUTION This setting changes the function settings used to control the indoor unit according to the installa- tion conditions. Incorrect settings can cause a product malfunction. • After the power is turned on, perform the “Function setting” according to the installation conditions using the remote controller.
  • Page 274 ¢ AR-REM4E (for Wall mounted type KGTB), AR-REW3E (for Wall mounted type KGTE and KGTF), AR-REW4E (for Wall mounted type KETA[-B], KETE[-B], and KETF[-B]), AR-REW2E (for Wall mounted type KMTB and KMTE), and AR-REM7E (for Floor type)  Button name and function During address setting mode, indoor unit reject the any operation command from remote con- troller.
  • Page 275  Function setting procedure Connect the power supply of the outdoor unit. To enter the function setting mode, while holding down the POWERFUL and TEMP. button, press the RESET button. POWERFUL TEMP. ( RESET Function setting mode display Select the function number by pressing the or the buttons.
  • Page 276 Press the MODE button once to transmit the function mode information. Press the button once to transmit the function setting information. 2 short beeps will be emitted from the indoor unit when the signal is received correctly. If wrong code is set, no beep sound will be emitted.
  • Page 277  Resetting the power after setting up all indoor units Important: • If the reset is not performed, function cannot be read correctly. • After all the functions have been set, the circuit breaker needs to be switched off for at least 2 minutes.
  • Page 278  Remote controller custom code setting Custom code setting of wireless remote controller needs to be same as the setting of the indoor unit. When you change the custom code setting of the wireless remote controller, do as follows: Press the START/STOP button until only the clock is displayed on the display. Press the MODE button for at least 5 seconds to display the current custom code (initially set to Press the TEMP.
  • Page 279 ¢ AR-REB1E (for Wall mounted type KMCC) and AR-RMB1E (for Wall mounted type KMCE and KMCF)  Button name and function During address setting mode, indoor unit reject the any operation command from remote con- troller. Function number Refer to Function details. Setting number Refer to Function details.
  • Page 280  Function setting procedure Connect the power supply of the outdoor unit. To enter the function setting mode, while holding down the POWERFUL and SET TEMP. buttons, press the RESET button. POWERFUL SET TEMP. ( RESET Function setting mode display Select the function number by pressing the or the buttons.
  • Page 281 Press the MODE button once to transmit the function mode information. 2 short beeps Press the button once to transmit the function setting information. 2 short beeps will be emitted from the indoor unit when the signal is received correctly. If wrong code is set, no beep sound will be emitted.
  • Page 282  Resetting the power after setting up all indoor units Important: • If the reset is not performed, function cannot be read correctly. • After all the functions have been set, the circuit breaker needs to be switched off for at least 2 minutes.
  • Page 283  Remote controller custom code setting Custom code setting of wireless remote controller needs to be same as the setting of the indoor unit. When you change the custom code setting of the wireless remote controller, do as follows: Press the START/STOP button until only the clock is displayed on the display. Press the MODE button for at least 5 seconds to display the current custom code (initially set to Press the SET TEMP.
  • Page 284 ¢ UTY-LNTY (for Compact cassette type) or AR-REJ1E (included in UTY-LBTYM for Duct type)  Button name and function During address setting mode, indoor unit reject the any operation command from remote con- troller. Function number Refer to Function details. Setting number Refer to Function details.
  • Page 285  Function setting procedure Connect the power supply of the outdoor unit. To enter the function setting mode, while holding down the ECONOMY and SET TEMP. buttons, press the RESET button. ECONOMY SET TEMP. ( RESET Function setting mode display - 277 - 15-2.
  • Page 286 Select the function number by pressing the or the buttons. Each time the 10°C HEAT button is pressed, it switches between the right digit and the left digit. Change digit Change digit Proceed to the setting number by pressing the ECONOMY button. (To return to the function number selection, press the ECONOMY button again.) Select the function number by pressing the or the...
  • Page 287 Press the button once to transmit the function setting information. 1 short beep will be emit- ted from the indoor unit or the IR receiver when the signal is received correctly. If wrong code is set, no beep sound will be emitted. 1 short beep NOTE: Press button within 30 seconds after pressing MODE button.
  • Page 288  Resetting the power after setting up all indoor units Important: • If the reset is not performed, function cannot be read correctly. • After all the functions have been set, the circuit breaker needs to be switched off for at least 2 minutes.
  • Page 289  Remote controller custom code setting Custom code setting of wireless remote controller needs to be same as the setting of the indoor unit. When you change the custom code setting of the wireless remote controller, do as follows: Press the START/STOP button until only the clock is displayed on the display. Press the MODE button for at least 5 seconds to display the current custom code (initially set to Press the SET TEMP.
  • Page 290 15-3. Indoor unit (setting by wired remote controller) • The function settings of the control of the indoor unit can be changed by this procedure according to the installation conditions. Incorrect settings can cause the indoor unit malfunction. • After the power is turned on, perform the “Function setting” according to the installation conditions using the remote controller.
  • Page 291 ¢ UTY-RNNYM  Button name and function During address setting mode, indoor unit reject the any operation command from remote controller. Function number Refer to Function details Remote controller address Setting number Refer to Function details Λ SET TEMP. “V” and “ ”...
  • Page 292 Confirm the setting by pressing the TIMER SET button. The data will be transferred to the indoor unit. Not good Good ● Data is not set up on the indoor unit Data is correctly set up on the indoor unit correctly (-- is displayed.) (Flashing display changes to illuminated display.) ●...
  • Page 293 ¢ UTY-RLRY  Setting procedure by using wired remote controller The function number and the associated setting value are displayed on the LCD of the remote con- troller. Follow the instructions written in the local setup procedure supplied with the remote controller, and select appropriate setting according to the installation environment.
  • Page 294 Pressing the "+" or "-" button, to select the function number. Then press the "ENTER" button. Function number Pressing the "+" or "-" button, to select the setting number. Then press the "ENTER" button. Setting number Example: Function number 30 Setting number 01 Error Good...
  • Page 295 ¢ UTY-RVNYM  Function setting procedure Connect the power supply of the outdoor unit. Switch to the function setting mode. When [Menu button] is pressed twice while “Monitor” screen is displayed, it switches to the “Submenu” screen. If [Menu button] is pressed while the “Submenu” screen is displayed, the display returns to the “Monitor”...
  • Page 296 Select the [Function No.] with pressing the [Cursor button (Left/Right)], and select the Function No. to be set with pressing the [Cursor button (Up/Down)]. Function setting Mo 10:00AM R.C. Function Setting address Cancel: Version Error history Select the [Setting No.] with pressing the [Cursor button (Left/Right)], and select the Setting No. to be set with pressing the [Cursor button (Up/Down)].
  • Page 297 When [Cancel button] is pressed twice while “Function setting” screen is displayed, it switches to the “Submenu” screen. Function setting Mo 10:00AM R.C. Function Setting Submenu Mo 10:00AM address Date and time Screen Cancel: Filter sign Version Error history R.C. sensor control Room temp.
  • Page 298 ¢ UTY-RNRYZ*  Setting procedure by using wired remote controller The function number and the associated setting value are displayed on the LCD of the remote con- troller. Follow the instructions written in the local setup procedure supplied with the remote controller, and select appropriate setting according to the installation environment.
  • Page 299 “Function No.” screen is displayed. Set the “Function No.” with Function No. Cancel When the “OK” is touched, the display returns to the “Function Setting” screen. Touch the “Function No.” on the “Function Setting” screen. Function Setting Address [002–01] Function No. [30] Setting No.
  • Page 300 Touch the “Yes” of the verification screen. Function Setting Function setting will be performed. OK? In case of “ERROR” In case of “OK” Function Setting Function Setting Address [002–01] Address [002–01] Function No. [30] Function No. [30] Setting No. [01] Setting No.
  • Page 301 15-4. Indoor unit (setting by simple remote controller) • The function settings of the control of the indoor unit can be changed by this procedure according to the installation conditions. Incorrect settings can cause the indoor unit malfunction. • After the power is turned on, perform the “Function setting” according to the installation conditions using the remote controller.
  • Page 302 ¢ UTY-RSNYM  Button name and function During address setting mode, indoor unit reject the any operation command from remote controller. Function number Setting number Refer to Function details Refer to Function details Remote controller address START/STOP button Transmits function setting FAN button SET TEMP.
  • Page 303 Select the setting number by pressing the SET TEMP. or SET TEMP. button. The setting number indicator flashes during setting number selection. Setting number Example) Function number : 30, Setting number : 01 Confirm the setting by pressing the TIMER SET button. The data will be transferred to the indoor unit.
  • Page 304  Resetting the power after setting up function of all indoor units NOTES: • If the reset is not performed, function cannot be read correctly. • After all the functions have been set, the circuit breaker needs to be switched off for at least 2 minutes.
  • Page 305 ¢ UTY-RSRY/UTY-RHRY  Setting procedure by using wired remote controller The function number and the associated setting value are displayed on the LCD of the remote con- troller. Follow the instructions written in the local setup procedure supplied with the remote controller, and select appropriate setting according to the installation environment.
  • Page 306 Select the item number to be set with the SET TEMP. or SET TEMP. button, and press button to switch to the setting screen. Select the “13” in Menu 2-F1 settings. Then, press the button. Select the 2-wire remote controller address with the SET TEMP. or SET TEMP.
  • Page 307 Setting results are displayed after data transmission. Press the button to return to the 2-wire remote controller address selection screen of step 9. If setting has been completed, press the FAN button to return to the Menu 2-F1 item se- lection screen.
  • Page 308 15-5. Function details ¢ Contents of function setting Each function setting listed in this section is adjustable in accordance with the installation environ- ment. NOTE: Setting will not be changed if invalid numbers or setting values are selected.  Function setting list Functio Compact Functions...
  • Page 309 Wall mounted Functio Functions n no. KGTB KGTE KGTF KMTB KMTE Remote controller ● — — ● — address setting Filter sign ● ● ● ● ● Ceiling height — — — — — Outlet directions — — — — —...
  • Page 310 Wall mounted Functio Functions n no. KMCC KMCE KMCF KETA(-B) KETE(-B) KETF(-B) Remote controller ● — — ● — — address setting Filter sign ● ● ● ● ● ● Ceiling height — — — — — — Outlet directions —...
  • Page 311 1) Remote controller address setting (for Wall-mounted type only) NOTES: • Because this setting is normally done automatically when 2-wire-type wired remote controller is installed, setting is unnecessary. • This setting is configurable only by wireless remote controller, but not configurable by Polar 3- wired remote controller.
  • Page 312 3) Ceiling height (for Compact cassette type and Ceiling type only) Select the appropriate ceiling height according to the place of installation. Function number Setting value Setting description Factory setting Standard ♦ High ceiling For the specific height for each setting value, refer to “Installation space” in Chapter 4. "Dimensions"...
  • Page 313 5) Static pressure (for Mini duct type and Slim duct type) Select the appropriate static pressure according to the installation conditions. For mini duct type: Function number Setting value Setting description Factory setting 0 Pa 10 Pa 20 Pa 30 Pa 40 Pa 50 Pa Standard...
  • Page 314 7) Room temperature control for indoor unit sensor (for other than Floor type) NOTE: If the remote sensor unit option is selected, perform this setting. Depending on the installed environment, correction of the room temperature sensor may be re- quired. Select the appropriate control setting according to the installed environment. The temperature of the room temperature sensor is corrected as follows: Corrected temp.
  • Page 315 8) Room temperature control for wired remote controller sensor (for other than Floor type) Depending on the installed environment, correction of the wire remote temperature sensor may be required. Select the appropriate control setting according to the installed environment. To change this setting, set Function 42 to Both “01”. Ensure that the Thermo Sensor icon is displayed on the remote controller screen.
  • Page 316 11) Remote controller custom code (Only for wireless remote controller) The indoor unit custom code can be changed. Select the appropriate custom code. Function number Setting value Setting description Factory setting ♦ 12) External input control "Operation/Stop" mode or "Forced stop" mode can be selected. Function number Setting value Setting description...
  • Page 317 15) Switching functions for external output terminal (For other than 18KMTB and KETA mod- els in Wall-mounted type) Functions of the external output terminal can be switched. For details, refer to “External input and output”. Function number Setting value Setting description Factory setting Operation status ♦...
  • Page 318 15-6. Wired remote controller (UTY-RNNYM) Prohibited Dual remote controller setting Prohibited DIP switch 1 °F/°C switch Prohibited Memory backup setting * Do not use DIP switch 2. ¢ Switch location Front case (back side) DIP switch 2 DIP switch 1 ¢...
  • Page 319  SW6: Memory backup setting Set to “ON” to use batteries for the memory backup. When batteries are not used, all of settings stored in memory will be deleted if there is a power failure. Memory backup Factory setting Disable ♦...
  • Page 320 15-7. Wired remote controller (UTY-RVNYM) Memory backup setting DIP switch 1 Dual remote controller setting ¢ Switch location ¢ DIP switch setting  SW1: Memory backup setting Set to “ON” to use batteries for the memory backup. When batteries are not used, all of settings stored in memory will be deleted if there is a power failure.
  • Page 321 15-8. Wired remote controller (UTY-RLRY) DIP switch Memory backup setting ¢ Switch location Front case (back side) Set the DIP switch to ON ¢ Dip switch setting  SW1: Memory backup setting Set to “ON” to use batteries for the memory backup. When batteries are not used, all of settings stored in memory will be deleted if there is a power failure.
  • Page 322 15-10. Simple remote controller (UTY-RSNYM) Prohibited Dual remote controller setting °F/°C switch DIP switch Prohibited Prohibited Prohibited ¢ Switch location DIP Switch ¢ DIP switch setting  SW2: Dual remote controller setting Set the remote controller SW2 according to the following table. Primary unit Secondary unit Number of remote controller...
  • Page 323 16. Accessories 16-1. Compact cassette type ¢ Models: AUXG07–18KVLA Part name Exterior Part name Exterior Operation manual Drain hose insulation Operation manual Hose band (CD-ROM) Coupler heat insulation Installation manual (large) Coupler heat insulation Template (Carton top) (small) M10 nut A Cable tie (with flange) M10 nut B...
  • Page 324 16-2. Mini duct type ¢ Models: ARXG07–14KSLAP Part name Exterior Part name Exterior Operation manual Drain hose Operation manual Hose band (CD-ROM) Installation manual Drain hose insulation B Installation template Washer (Carton top) Coupler heat insulation Cable tie (large) (large) Coupler heat insulation Cable tie (medium) (small)
  • Page 325 ¢ Model: ARXG18KSLAP Part name Exterior Part name Exterior Operation manual Drain hose Operation manual Hose band (CD-ROM) Installation manual Drain hose insulation B Installation template Washer (Carton top) Coupler heat insulation Cable tie (large) (large) Coupler heat insulation Cable tie (medium) (small) Insulation Filter (large)
  • Page 326 16-3. Slim duct type ¢ Models: ARXG07–18KLLAP Part name Exterior Part name Exterior Operation manual Cable tie (Large) Installation manual Cable tie (Small) Installation template Drain hose Washer Hose band Coupler heat insulation Drain hose insulation B (Large) Coupler heat insulation Remote controller (Small) Filter (Small)
  • Page 327 16-4. Wall mounted type ¢ Models: ASYG07–14KGTB, ASYG07–14KMTB, and ASYG07– 14KMCC Part name Exterior Part name Exterior Operation manual Cloth tape Operation manual Self-tapping screw (CD-ROM) (large) Self-tapping screw Installation manual (small) Remote controller Wall hook bracket Battery Filter holder Remote controller Air cleaning filters holder...
  • Page 328 ¢ Models: ASYG07–14KGTE and ASYG07–14KGTF Part name Exterior Part name Exterior Operation manual Cloth tape Operation manual Self-tapping screw (CD-ROM) (large) Self-tapping screw Installation manual (small) Remote controller Wall hook bracket Battery Filter holder Remote controller Air cleaning filters holder - 320 - 16-4.
  • Page 329 ¢ Model: ASYG18KMTB Part name Exterior Part name Exterior Self-tapping screw Operation manual (large) Self-tapping screw Installation manual (small) Remote controller Battery Remote controller Filter holder holder Cloth tape Air cleaning filters Wall hook bracket - 321 - 16-4. Wall mounted type 16.
  • Page 330 ¢ Model: ASYG18KMTE Part name Exterior Part name Exterior Operation manual Cloth tape Operation manual Self-tapping screw (CD-ROM) (large) Self-tapping screw Installation manual (small) Remote controller Wall hook bracket Remote controller Filter holder holder Battery Air cleaning filters - 322 - 16-4.
  • Page 331 ¢ Models: ASYG07–14KMCE and ASYG07–14KMCF Part name Exterior Part name Exterior Operation manual Cloth tape Operation manual Self-tapping screw (CD-ROM) (large) Self-tapping screw Installation manual (small) Remote controller Wall hook bracket Battery Filter holder Remote controller Air cleaning filters holder - 323 - 16-4.
  • Page 332 ¢ Models: ASYG07–14KETA, ASYG07–14KETA-B, ASYG07– 14KETE, ASYG07–14KETE-B, ASYG07–14KETF, and ASYG07– 14KETF-B Part name Exterior Part name Exterior Operation manual Cloth tape Operation manual Self-tapping screw (CD-ROM) (large) Self-tapping screw Installation manual (small) Remote controller Wall hook bracket Battery Filter holder Remote controller Air cleaning filters holder...
  • Page 333 16-5. Ceiling type ¢ Model: ABYG18KRTA Part name Exterior Part name Exterior Operation manual Insulation Operation manual Drain hose (CD-ROM) Installation manual Hose band Template Cable tie (large) M10 nut A Cable tie (small) (with flange) M10 nut B Remote controller cable (with spring lock hole cap washer)
  • Page 334 16-6. Floor type ¢ Models: AGYG09–14KVCA Part name Exterior Part name Exterior Operation manual (CD- Operation manual ROM) Installation manual Cloth tape Self-tapping screws Wall hook bracket (large) Self-tapping screws Remote controller (small) Battery Air cleaning filters Remote controller holder - 326 - 16-6.
  • Page 335 17. Optional parts 17-1. Controllers ¢ Lineup Type Indoor unit type Wireless Remote Controller AR-REM4E AR-REM7E AR-REB1E AR-REW2E Compact cassette — — — — Mini duct — — — — Slim duct — — — — KGTB ● — — —...
  • Page 336 Type Indoor unit type Wired Remote Controller UTY-RNNYM UTY-RVNYM UTY-RLRY UTY-RNRYZ* UTY-RCRYZ1 Compact cassette ◌ ◌ ◌ ◌ ◌ Mini duct ◌ ◌ ◌ ◌ ◌ Slim duct ◌ ◌ ◌ ◌ ◌ KGTB — — ◌ ◌ ◌ KGTE —...
  • Page 337 ¢ Parts Exterior Part name Model name Summary Easy finger touch operation with LCD panel. Backlit LCD enables easy Wired Remote UTY-RNRYZ* operation in a dark room. Controller Wire type: Non-polar 2-wire High visibility and easy operation. Room temperature can be accurately Wired Remote UTY-RLRY controlled using the thermo sensor.
  • Page 338 Exterior Part name Model name Summary Compact remote controller concentrates on the basic functions such as Start/Stop, fan control, temperature setting, and operation Simple Remote UTY-RSNYM Controller mode. Wire type: Polar 3-wire IR Receiver Kit Unit control is performed by Wireless with Wireless UTY-LBTYM Remote Controller...
  • Page 339 17-2. Cassette grille ¢ Lineup Indoor unit type Model Compact cassette UTG-UFYF-W ¢ Part Exterior Part name Model name Summary This cassette grille can be installed Cassette Grille UTG-UFYF-W appropriately on the grid type ceiling common in the office. - 331 - 17-2.
  • Page 340 17-3. Others ¢ Lineup Type Air Outlet Shutter Insulation Kit for Fresh Air Intake Half Concealed Indoor unit type Plate High Humidity UTR-YDZB UTZ-KXGC UTZ-VXAA UTR-STA Compact cassette ◌ ◌ ◌ — Mini duct — — — — Slim duct —...
  • Page 341 Type External Input and Output Indoor unit type External Connect Kit UTY-XWZX UTY-XWZXZ5 UTY-XWZXZG UTY-XCSXZ2 UTY-XCSX Compact cassette — — ◌ — ◌ Mini duct — — ◌ — — Slim duct — — ◌ — — KGTB ◌ — —...
  • Page 342 Type Air Cleaning Indoor unit type Communication Kit Filter UTY-TWBXF2 UTY-TWRXZ2 UTY-TWRXZ3 UTR-FA16-5 Compact cassette — — — — Mini duct — — — — Slim duct — — — — KGTB — ◌ — — KGTE — ◌ — —...
  • Page 343 ¢ Parts Exterior Part name Model name Summary Thermo-sensor for sensing the Remote Sensor UTY-XSZX temperature of arbitrary place in the Unit room. Width: 683 mm For 07, 09, 12, and 14 models Auto Louver UTD-GXTA-W Grille Kit Width: 883 mm Auto Louver UTD-GXTB-W Grille Kit...
  • Page 344 Exterior Part name Model name Summary Communication Use to connect with optional devices UTY-TWBXF2 and air conditioner PCB. Use to connect with external devices and air conditioner PCB. External Input UTY-XCSX and Output PCB Optional External Connect Kit is necessary for installation. Use to connect with external devices and air conditioner PCB.
  • Page 345 Exterior Part name Model name Summary For connection between indoor unit Modbus with UART interface and a Modbus UTY-VMSX Converter open network. For connection between indoor unit with UART interface and a KNX open KNX Convertor UTY-VKSX network. This converter is required when Network connecting single split system to VRF UTY-VTGX...
  • Page 346 18. Indoor unit installation precautions NOTE: The information listed below are general precautions. Some models also include items that do not apply. 18-1. Places where prohibited for use • Places where there is a danger of combustible gas leakage. • Places where sulfur gas, chlorine gas, acid, alkali, or other matter which effects equipment is gen- erated.
  • Page 347 Condition Contents Countermeasures (Reference) When inside the When the indoor unit is installed where the inside of the 1. Add heat insulating material to ceiling is high ceiling is 30 °C RH80% or greater, the dew point the outside of the indoor unit temperature temperature of the outer perimeter may become higher cabinet.
  • Page 348 Condition which requires addition of outside heat insulation Relative humidity 80 % Dry bulb temperature 30 °C Figure 18-1 Moist air curve Slit of heat insulating material Heat insulation reinforcement material Flare connection facing upward (locally purchased) To indoor unit Covered gas pipe (heat insulation...
  • Page 349 Part 2. OUTDOOR UNIT (3 UNITS TYPE) MULTI-SPLIT TYPE: AOYG18KBTA3 AOYG24KBTA3...

  • Page 350: Dimensions

    1. Specifications Type Inverter heat pump Model name AOYG18KBTA3 AOYG24KBTA3 Power source 230 V 50 Hz Available voltage range 198—264V Wall mounted Wall mounted Standard combination of indoor unit ASYG07KMCC ASYG07KMCC ×3 ASYG09KMCC ×2 Rated Btu/h 18,400 23,200 Cooling 1.8—7 1.8—8.5 Min.—Max.
  • Page 351 Specifications for ErP Lot10 Model name AOYG18KBTA3 AOYG24KBTA3 Cooling Energy efficiency class Heating (Average) Cooling 5.4 (35 °C) 6.8 (35 °C) Pdesign Heating (Average) 5.0 (-10 °C) 6.0 (-10 °C) SEER Cooling 8.60 8.50 kWh/kWh SCOP Heating (Average) 4.70 4.60 Annual energy consumption kWh/a QHE (Average)

  • Page 352: Models: Aoyg18Kbta3 And Aoyg24Kbta3

    2. Dimensions 2-1. Models: AOYG18KBTA3 and AOYG24KBTA3 Unit: mm 4-M10 hole Pitch of bolts for installation Top view Side view Front view Side view Airflow Drain port Ø42 Bottom view Side view (Valve part) - 344 - 2-1. Models: AOYG18KBTA3 and AOYG24KBTA3 2.

  • Page 353: Installation Space

    3. Installation space 3-1. Models: AOYG18KBTA3 and AOYG24KBTA3 ¢ Space requirement Provide sufficient installation space for product safety. CAUTION Keep the space shown in the installation examples. If the installation is not performed accordingly, it could cause a short circuit and result in a lack of operating performance.
  • Page 354  Multiple outdoor unit installation • Provide at least 250 mm of space between the outdoor units if multiple units are installed. • When routing the piping from the side of an outdoor unit, provide space for piping. • No more than 3 units must be installed side by side. When 4 units or more are arranged in a line, provide the space as shown in the following ex- ample “When an obstruction in the upper space:”.
  • Page 355  Outdoor units installation in multi-row Unit: mm Single parallel unit arrangement Multiple parallel unit arrangement 100 or more 200 or more 1,000 or more 2,000 or more 200 or more 400 or more 500 or more 1,000 or more 200 or more 250 or more 1,000 or more...

  • Page 356: Refrigerant Circuit

    4. Refrigerant circuit 4-1. Models: AOYG18KBTA3 and AOYG24KBTA3 Pressure switch CONDENSER - 348 - 4-1. Models: AOYG18KBTA3 and AOYG24KBTA3 4. Refrigerant circuit...

  • Page 357: Wiring Diagram

    5. Wiring diagram 5-1. Models: AOYG18KBTA3 and AOYG24KBTA3 - 349 - 5-1. Models: AOYG18KBTA3 and AOYG24KBTA3 5. Wiring diagram...

  • Page 358: Capacity Table

    6. Capacity table 6-1. Combinations ¢ Model: AOYG18KBTA3  Cooling Rated capacity for each in- Total capacity Combination of indoor unit Input power (kW) Seasonal data door unit (kW) (kW) Room Room (W/W) Pdesign SEER Energy effi- Total Min. Rated Max.
  • Page 359  Heating Rated capacity for each in- Total capacity Combination of indoor unit Input power (kW) Seasonal data door unit (kBtu/h) (kBtu/h) Room Room (W/W) Pdesign SCOP Energy effi- Total Min. Rated Max. Min. Rated Max. (kW) (kWh/kWh) ciency class —...
  • Page 360 ¢ Model: AOYG24KBTA3  Cooling Rated capacity for each Total capacity Combination of indoor unit Input power (kW) Seasonal data indoor unit (kW) (kW) Room Room (W/W) Pdesign SEER Energy effi- Total Min. Rated Max. Min. Rated Max. (kW) (kWh/kWh) ciency class —...
  • Page 361  Heating Rated capacity for each in- Total capacity Combination of indoor unit Input power (kW) Seasonal data door unit (kW) (kW) Room Room (W/W) Pdesign SEER Energy effi- Total Min. Rated Max. Min. Rated Max. (kW) (kWh/kWh) ciency class —...

  • Page 362: Cooling Capacity

    6-2. Cooling capacity NOTE: Values mentioned in the table are calculated based on the maximum capacity. ¢ Model: AOYG18KBTA3 Indoor temperature Indoor unit connect- Outdoor temperature 18.0 °CDB 21.0 °CDB 23.0 °CDB 27.0 °CDB 29.0 °CDB 32.0 °CDB ing capacity 12.0 °CWB 15.0 °CWB 16.0 °CWB...
  • Page 363 Indoor temperature Indoor unit connect- Outdoor temperature 18.0 °CDB 21.0 °CDB 23.0 °CDB 27.0 °CDB 29.0 °CDB 32.0 °CDB ing capacity 12.0 °CWB 15.0 °CWB 16.0 °CWB 19.0 °CWB 21.0 °CWB 23.0 °CWB kBtu/h °CDB -10.0 0.88 0.89 0.90 0.91 0.92 0.92 1.04...
  • Page 364  Compact cassette type Model: AUXG07KVLA Indoor temperature (°CDB / °CWB) Outdoor temperature 18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0 (°CDB) -10.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13...
  • Page 365 1.28 2.93 1.46 3.09 1.68 3.31 1.89 3.54 2.06 3.65 2.36 Model: ARXG14KSLAP Indoor temperature (°CDB / °CWB) Outdoor temperature 18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0 (°CDB) -10.0 3.66...
  • Page 366  Slim duct type Model: ARXG07KLLAP Indoor temperature (°CDB / °CWB) Outdoor temperature 18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0 (°CDB) -10.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19...
  • Page 367  Wall mounted type Model: ASYG07KGTB Indoor temperature (°CDB / °CWB) Outdoor temperature 18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0 (°CDB) -10.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78...
  • Page 368 Model: ASYG07KGTE Indoor temperature (°CDB / °CWB) Outdoor temperature 18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0 (°CDB) -10.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04 -5.0 1.96...
  • Page 369 Model: ASYG07KGTF Indoor temperature (°CDB / °CWB) Outdoor temperature 18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0 (°CDB) -10.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04 -5.0 1.96...
  • Page 370 Model: ASYG07KMTB Indoor temperature (°CDB / °CWB) Outdoor temperature 18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0 (°CDB) -10.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04 -5.0 1.96...
  • Page 371 Model: ASYG07KMCC Indoor temperature (°CDB / °CWB) Outdoor temperature 18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0 (°CDB) -10.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04 -5.0 1.96...
  • Page 372 Model: ASYG07KMCE Indoor temperature (°CDB / °CWB) Outdoor temperature 18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0 (°CDB) -10.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04 -5.0 1.96...
  • Page 373 Model: ASYG07KMCF Indoor temperature (°CDB / °CWB) Outdoor temperature 18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0 (°CDB) -10.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04 -5.0 1.96...
  • Page 374 Model: ASYG07KETA, ASYG07KETA-B Indoor temperature (°CDB / °CWB) Outdoor temperature 18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0 (°CDB) -10.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04 -5.0...
  • Page 375 Model: ASYG07KETE, ASYG07KETE-B Indoor temperature (°CDB / °CWB) Outdoor temperature 18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0 (°CDB) -10.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04 -5.0...
  • Page 376 Model: ASYG07KETF, ASYG07KETF-B Indoor temperature (°CDB / °CWB) Outdoor temperature 18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0 (°CDB) -10.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04 -5.0...
  • Page 377  Floor type Model: AGYG09KVCA Indoor temperature (°CDB / °CWB) Outdoor temperature 18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0 (°CDB) -10.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53...
  • Page 378 ¢ Model: AOYG24KBTA3 Indoor temperature Indoor unit connect- Outdoor temperature 18.0 °CDB 21.0 °CDB 23.0 °CDB 27.0 °CDB 29.0 °CDB 32.0 °CDB ing capacity 12.0 °CWB 15.0 °CWB 16.0 °CWB 19.0 °CWB 21.0 °CWB 23.0 °CWB kBtu/h °CDB -10.0 1.23 1.25 1.26 1.27...
  • Page 379 Indoor temperature Indoor unit connect- Outdoor temperature 18.0 °CDB 21.0 °CDB 23.0 °CDB 27.0 °CDB 29.0 °CDB 32.0 °CDB ing capacity 12.0 °CWB 15.0 °CWB 16.0 °CWB 19.0 °CWB 21.0 °CWB 23.0 °CWB kBtu/h °CDB -10.0 1.23 1.25 1.26 1.27 1.29 1.30 1.46...
  • Page 380 Indoor temperature Indoor unit connect- Outdoor temperature 18.0 °CDB 21.0 °CDB 23.0 °CDB 27.0 °CDB 29.0 °CDB 32.0 °CDB ing capacity 12.0 °CWB 15.0 °CWB 16.0 °CWB 19.0 °CWB 21.0 °CWB 23.0 °CWB kBtu/h °CDB -10.0 0.85 0.87 0.87 0.88 0.89 0.90 1.02...
  • Page 381  Compact cassette type Model: AUXG07KVLA Indoor temperature (°CDB / °CWB) Outdoor temperature 18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0 (°CDB) -10.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13...
  • Page 382 Model: AUXG18KVLA Indoor temperature (°CDB / °CWB) Outdoor temperature 18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0 (°CDB) -10.0 4.80 2.91 5.42 3.31 5.72 3.81 6.12 4.28 6.54 4.69 6.74 5.37 -5.0 4.80...
  • Page 383 0.88 2.44 1.01 2.57 1.16 2.75 1.30 2.94 1.43 3.03 1.63 Model: ARXG14KSLAP Indoor temperature (°CDB / °CWB) Outdoor temperature 18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0 (°CDB) -10.0 3.92...
  • Page 384 Model: ARXG18KSLAP Indoor temperature (°CDB / °CWB) Outdoor temperature 18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0 (°CDB) -10.0 4.80 2.99 5.42 3.41 5.72 3.92 6.12 4.41 6.54 4.82 6.74 5.52 -5.0 4.80...
  • Page 385  Slim duct type Model: ARXG07KLLAP Indoor temperature (°CDB / °CWB) Outdoor temperature 18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0 (°CDB) -10.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19...
  • Page 386 Model: ARXG18KLLAP Indoor temperature (°CDB / °CWB) Outdoor temperature 18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0 (°CDB) -10.0 4.80 2.99 5.42 3.41 5.72 3.92 6.12 4.41 6.54 4.82 6.74 5.52 -5.0 4.80...
  • Page 387  Wall mounted type Model: ASYG07KGTB Indoor temperature (°CDB / °CWB) Outdoor temperature 18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0 (°CDB) -10.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78...
  • Page 388 Model: ASYG07KGTE Indoor temperature (°CDB / °CWB) Outdoor temperature 18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0 (°CDB) -10.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04 -5.0 1.96...
  • Page 389 Model: ASYG07KGTF Indoor temperature (°CDB / °CWB) Outdoor temperature 18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0 (°CDB) -10.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04 -5.0 1.96...
  • Page 390 Model: ASYG18KMTB Indoor temperature (°CDB / °CWB) Outdoor temperature 18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0 (°CDB) -10.0 4.80 3.24 5.42 3.69 5.72 4.25 6.12 4.77 6.54 5.22 6.74 5.98 -5.0 4.80...
  • Page 391 Model: ASYG07KMTB Indoor temperature (°CDB / °CWB) Outdoor temperature 18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0 (°CDB) -10.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04 -5.0 1.96...
  • Page 392 Model: ASYG07KMCC Indoor temperature (°CDB / °CWB) Outdoor temperature 18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0 (°CDB) -10.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04 -5.0 1.96...
  • Page 393 Model: ASYG07KMCE Indoor temperature (°CDB / °CWB) Outdoor temperature 18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0 (°CDB) -10.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04 -5.0 1.96...
  • Page 394 Model: ASYG07KMCF Indoor temperature (°CDB / °CWB) Outdoor temperature 18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0 (°CDB) -10.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04 -5.0 1.96...
  • Page 395 Model: ASYG07KETA, ASYG07KETA-B Indoor temperature (°CDB / °CWB) Outdoor temperature 18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0 (°CDB) -10.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04 -5.0...
  • Page 396 Model: ASYG07KETE, ASYG07KETE-B Indoor temperature (°CDB / °CWB) Outdoor temperature 18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0 (°CDB) -10.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04 -5.0...
  • Page 397 Model: ASYG07KETF, ASYG07KETF-B Indoor temperature (°CDB / °CWB) Outdoor temperature 18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0 (°CDB) -10.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04 -5.0...
  • Page 398  Ceiling type Model: ABYG18KRTA Indoor temperature (°CDB / °CWB) Outdoor temperature 18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0 (°CDB) -10.0 4.80 2.99 5.42 3.41 5.72 3.92 6.12 4.41 6.54 4.82 6.74...
  • Page 399  Floor type Model: AGYG09KVCA Indoor temperature (°CDB / °CWB) Outdoor temperature 18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0 (°CDB) -10.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53...

  • Page 400: Heating Capacity

    6-3. Heating capacity NOTE: Values mentioned in the table are calculated based on the maximum capacity. ¢ Model: AOYG18KBTA3 Indoor temperature Indoor unit connecting Outdoor temperature capacity 16.0 °CDB 18.0 °CDB 20.0 °CDB 22.0 °CDB 24.0 °CDB kBtu/h °CDB °CWB -15.0 -16.0 3.03...
  • Page 401 Indoor temperature Indoor unit connecting Outdoor temperature capacity 16.0 °CDB 18.0 °CDB 20.0 °CDB 22.0 °CDB 24.0 °CDB kBtu/h °CDB °CWB -15.0 -16.0 2.85 2.91 2.97 3.02 3.08 -10.0 -11.0 3.02 3.08 3.14 3.20 3.27 -5.0 -7.0 2.75 2.80 2.86 2.92 2.97 -2.0...
  • Page 402  Compact cassette type Model: AUXG07KVLA Indoor temperature (°CDB) Outdoor temperature 16.0 18.0 20.0 22.0 24.0 (°CDB) (°CWB) -15.0 -16.0 2.23 2.18 2.13 2.07 2.02 -10.0 -11.0 2.53 2.47 2.41 2.35 2.29 -5.0 -7.0 2.70 2.64 2.58 2.51 2.45 -2.0 2.94 2.87 2.80...
  • Page 403 4.92 4.80 4.68 4.56 20.0 15.0 5.04 4.92 4.80 4.68 4.56 24.0 18.0 5.04 4.92 4.80 4.68 4.56 Model: ARXG14KSLAP Indoor temperature (°CDB) Outdoor temperature 16.0 18.0 20.0 22.0 24.0 (°CDB) (°CWB) -15.0 -16.0 4.25 4.15 4.05 3.95 3.85 -10.0 -11.0...
  • Page 404  Slim duct type Model: ARXG07KLLAP Indoor temperature (°CDB) Outdoor temperature 16.0 18.0 20.0 22.0 24.0 (°CDB) (°CWB) -15.0 -16.0 2.23 2.18 2.13 2.07 2.02 -10.0 -11.0 2.53 2.47 2.41 2.35 2.29 -5.0 -7.0 2.70 2.64 2.58 2.51 2.45 -2.0 2.94 2.87 2.80...
  • Page 405  Wall mounted type Model: ASYG07KGTB Indoor temperature (°CDB) Outdoor temperature 16.0 18.0 20.0 22.0 24.0 (°CDB) (°CWB) -15.0 -16.0 2.23 2.18 2.13 2.07 2.02 -10.0 -11.0 2.53 2.47 2.41 2.35 2.29 -5.0 -7.0 2.70 2.64 2.58 2.51 2.45 -2.0 2.94 2.87 2.80...
  • Page 406 Model: ASYG07KGTE Indoor temperature (°CDB) Outdoor temperature 16.0 18.0 20.0 22.0 24.0 (°CDB) (°CWB) -15.0 -16.0 2.23 2.18 2.13 2.07 2.02 -10.0 -11.0 2.53 2.47 2.41 2.35 2.29 -5.0 -7.0 2.70 2.64 2.58 2.51 2.45 -2.0 2.94 2.87 2.80 2.73 2.66 2.94 2.87...
  • Page 407 Model: ASYG07KGTF Indoor temperature (°CDB) Outdoor temperature 16.0 18.0 20.0 22.0 24.0 (°CDB) (°CWB) -15.0 -16.0 2.23 2.18 2.13 2.07 2.02 -10.0 -11.0 2.53 2.47 2.41 2.35 2.29 -5.0 -7.0 2.70 2.64 2.58 2.51 2.45 -2.0 2.94 2.87 2.80 2.73 2.66 2.94 2.87...
  • Page 408 Model: ASYG07KMTB Indoor temperature (°CDB) Outdoor temperature 16.0 18.0 20.0 22.0 24.0 (°CDB) (°CWB) -15.0 -16.0 2.23 2.18 2.13 2.07 2.02 -10.0 -11.0 2.53 2.47 2.41 2.35 2.29 -5.0 -7.0 2.70 2.64 2.58 2.51 2.45 -2.0 2.94 2.87 2.80 2.73 2.66 2.94 2.87...
  • Page 409 Model: ASYG07KMCC Indoor temperature (°CDB) Outdoor temperature 16.0 18.0 20.0 22.0 24.0 (°CDB) (°CWB) -15.0 -16.0 2.23 2.18 2.13 2.07 2.02 -10.0 -11.0 2.53 2.47 2.41 2.35 2.29 -5.0 -7.0 2.70 2.64 2.58 2.51 2.45 -2.0 2.94 2.87 2.80 2.73 2.66 2.94 2.87...
  • Page 410 Model: ASYG07KMCE Indoor temperature (°CDB) Outdoor temperature 16.0 18.0 20.0 22.0 24.0 (°CDB) (°CWB) -15.0 -16.0 2.23 2.18 2.13 2.07 2.02 -10.0 -11.0 2.53 2.47 2.41 2.35 2.29 -5.0 -7.0 2.70 2.64 2.58 2.51 2.45 -2.0 2.94 2.87 2.80 2.73 2.66 2.94 2.87...
  • Page 411 Model: ASYG07KMCF Indoor temperature (°CDB) Outdoor temperature 16.0 18.0 20.0 22.0 24.0 (°CDB) (°CWB) -15.0 -16.0 2.23 2.18 2.13 2.07 2.02 -10.0 -11.0 2.53 2.47 2.41 2.35 2.29 -5.0 -7.0 2.70 2.64 2.58 2.51 2.45 -2.0 2.94 2.87 2.80 2.73 2.66 2.94 2.87...
  • Page 412 Model: ASYG07KETA, ASYG07KETA-B Indoor temperature (°CDB) Outdoor temperature 16.0 18.0 20.0 22.0 24.0 (°CDB) (°CWB) -15.0 -16.0 2.23 2.18 2.13 2.07 2.02 -10.0 -11.0 2.53 2.47 2.41 2.35 2.29 -5.0 -7.0 2.70 2.64 2.58 2.51 2.45 -2.0 2.94 2.87 2.80 2.73 2.66 2.94...
  • Page 413 Model: ASYG07KETE, ASYG07KETE-B Indoor temperature (°CDB) Outdoor temperature 16.0 18.0 20.0 22.0 24.0 (°CDB) (°CWB) -15.0 -16.0 2.23 2.18 2.13 2.07 2.02 -10.0 -11.0 2.53 2.47 2.41 2.35 2.29 -5.0 -7.0 2.70 2.64 2.58 2.51 2.45 -2.0 2.94 2.87 2.80 2.73 2.66 2.94...
  • Page 414 Model: ASYG07KETF, ASYG07KETF-B Indoor temperature (°CDB) Outdoor temperature 16.0 18.0 20.0 22.0 24.0 (°CDB) (°CWB) -15.0 -16.0 2.23 2.18 2.13 2.07 2.02 -10.0 -11.0 2.53 2.47 2.41 2.35 2.29 -5.0 -7.0 2.70 2.64 2.58 2.51 2.45 -2.0 2.94 2.87 2.80 2.73 2.66 2.94...
  • Page 415  Floor type Model: AGYG09KVCA Indoor temperature (°CDB) Outdoor temperature 16.0 18.0 20.0 22.0 24.0 (°CDB) (°CWB) -15.0 -16.0 2.87 2.80 2.74 2.67 2.60 -10.0 -11.0 3.25 3.17 3.10 3.02 2.94 -5.0 -7.0 3.48 3.39 3.31 3.23 3.15 -2.0 3.78 3.69 3.60 3.51...
  • Page 416 ¢ Model: AOYG24KBTA3 Indoor temperature Indoor unit connecting Outdoor temperature capacity 16.0 °CDB 18.0 °CDB 20.0 °CDB 22.0 °CDB 24.0 °CDB kBtu/h °CDB °CWB -15.0 -16.0 3.05 3.12 3.18 3.25 3.31 -10.0 -11.0 3.24 3.30 3.37 3.44 3.51 -5.0 -7.0 2.95 3.01 3.07...
  • Page 417 Indoor temperature Indoor unit connecting Outdoor temperature capacity 16.0 °CDB 18.0 °CDB 20.0 °CDB 22.0 °CDB 24.0 °CDB kBtu/h °CDB °CWB -15.0 -16.0 3.05 3.12 3.18 3.25 3.31 -10.0 -11.0 3.24 3.30 3.37 3.44 3.51 -5.0 -7.0 2.95 3.01 3.07 3.13 3.19 -2.0...
  • Page 418 Indoor temperature Indoor unit connecting Outdoor temperature capacity 16.0 °CDB 18.0 °CDB 20.0 °CDB 22.0 °CDB 24.0 °CDB kBtu/h °CDB °CWB -15.0 -16.0 1.77 1.81 1.84 1.88 1.92 -10.0 -11.0 1.87 1.91 1.95 1.99 2.03 -5.0 -7.0 1.71 1.74 1.78 1.81 1.85 -2.0...
  • Page 419  Compact cassette type Model: AUXG07KVLA Indoor temperature (°CDB) Outdoor temperature 16.0 18.0 20.0 22.0 24.0 (°CDB) (°CWB) -15.0 -16.0 1.97 1.92 1.88 1.83 1.78 -10.0 -11.0 2.23 2.18 2.13 2.07 2.02 -5.0 -7.0 2.38 2.32 2.27 2.21 2.15 -2.0 2.70 2.64 2.58...
  • Page 420 Model: AUXG18KVLA Indoor temperature (°CDB) Outdoor temperature 16.0 18.0 20.0 22.0 24.0 (°CDB) (°CWB) -15.0 -16.0 4.66 4.55 4.44 4.32 4.21 -10.0 -11.0 5.28 5.16 5.03 4.91 4.78 -5.0 -7.0 5.63 5.50 5.36 5.23 5.09 -2.0 6.39 6.24 6.09 5.94 5.79 6.95 6.79...
  • Page 421 4.92 4.80 4.68 4.56 20.0 15.0 5.04 4.92 4.80 4.68 4.56 24.0 18.0 5.04 4.92 4.80 4.68 4.56 Model: ARXG14KSLAP Indoor temperature (°CDB) Outdoor temperature 16.0 18.0 20.0 22.0 24.0 (°CDB) (°CWB) -15.0 -16.0 3.94 3.85 3.75 3.66 3.56 -10.0 -11.0...
  • Page 422 Model: ARXG18KSLAP Indoor temperature (°CDB) Outdoor temperature 16.0 18.0 20.0 22.0 24.0 (°CDB) (°CWB) -15.0 -16.0 4.66 4.55 4.44 4.32 4.21 -10.0 -11.0 5.28 5.16 5.03 4.91 4.78 -5.0 -7.0 5.63 5.50 5.36 5.23 5.09 -2.0 6.39 6.24 6.09 5.94 5.79 6.95 6.79...
  • Page 423  Slim duct type Model: ARXG07KLLAP Indoor temperature (°CDB) Outdoor temperature 16.0 18.0 20.0 22.0 24.0 (°CDB) (°CWB) -15.0 -16.0 1.97 1.92 1.88 1.83 1.78 -10.0 -11.0 2.23 2.18 2.13 2.07 2.02 -5.0 -7.0 2.38 2.32 2.27 2.21 2.15 -2.0 2.70 2.64 2.58...
  • Page 424 Model: ARXG18KLLAP Indoor temperature (°CDB) Outdoor temperature 16.0 18.0 20.0 22.0 24.0 (°CDB) (°CWB) -15.0 -16.0 4.66 4.55 4.44 4.32 4.21 -10.0 -11.0 5.28 5.16 5.03 4.91 4.78 -5.0 -7.0 5.63 5.50 5.36 5.23 5.09 -2.0 6.39 6.24 6.09 5.94 5.79 6.95 6.79...
  • Page 425  Wall mounted type Model: ASYG07KGTB Indoor temperature (°CDB) Outdoor temperature 16.0 18.0 20.0 22.0 24.0 (°CDB) (°CWB) -15.0 -16.0 1.97 1.92 1.88 1.83 1.78 -10.0 -11.0 2.23 2.18 2.13 2.07 2.02 -5.0 -7.0 2.38 2.32 2.27 2.21 2.15 -2.0 2.70 2.64 2.58...
  • Page 426 Model: ASYG07KGTE Indoor temperature (°CDB) Outdoor temperature 16.0 18.0 20.0 22.0 24.0 (°CDB) (°CWB) -15.0 -16.0 1.97 1.92 1.88 1.83 1.78 -10.0 -11.0 2.23 2.18 2.13 2.07 2.02 -5.0 -7.0 2.38 2.32 2.27 2.21 2.15 -2.0 2.70 2.64 2.58 2.51 2.45 2.94 2.87...
  • Page 427 Model: ASYG07KGTF Indoor temperature (°CDB) Outdoor temperature 16.0 18.0 20.0 22.0 24.0 (°CDB) (°CWB) -15.0 -16.0 1.97 1.92 1.88 1.83 1.78 -10.0 -11.0 2.23 2.18 2.13 2.07 2.02 -5.0 -7.0 2.38 2.32 2.27 2.21 2.15 -2.0 2.70 2.64 2.58 2.51 2.45 2.94 2.87...
  • Page 428 Model: ASYG18KMTB Indoor temperature (°CDB) Outdoor temperature 16.0 18.0 20.0 22.0 24.0 (°CDB) (°CWB) -15.0 -16.0 4.66 4.55 4.44 4.32 4.21 -10.0 -11.0 5.28 5.16 5.03 4.91 4.78 -5.0 -7.0 5.63 5.50 5.36 5.23 5.09 -2.0 6.39 6.24 6.09 5.94 5.79 6.95 6.79...
  • Page 429 Model: ASYG07KMTB Indoor temperature (°CDB) Outdoor temperature 16.0 18.0 20.0 22.0 24.0 (°CDB) (°CWB) -15.0 -16.0 1.97 1.92 1.88 1.83 1.78 -10.0 -11.0 2.23 2.18 2.13 2.07 2.02 -5.0 -7.0 2.38 2.32 2.27 2.21 2.15 -2.0 2.70 2.64 2.58 2.51 2.45 2.94 2.87...
  • Page 430 Model: ASYG07KMCC Indoor temperature (°CDB) Outdoor temperature 16.0 18.0 20.0 22.0 24.0 (°CDB) (°CWB) -15.0 -16.0 1.97 1.92 1.88 1.83 1.78 -10.0 -11.0 2.23 2.18 2.13 2.07 2.02 -5.0 -7.0 2.38 2.32 2.27 2.21 2.15 -2.0 2.70 2.64 2.58 2.51 2.45 2.94 2.87...
  • Page 431 Model: ASYG07KMCE Indoor temperature (°CDB) Outdoor temperature 16.0 18.0 20.0 22.0 24.0 (°CDB) (°CWB) -15.0 -16.0 1.97 1.92 1.88 1.83 1.78 -10.0 -11.0 2.23 2.18 2.13 2.07 2.02 -5.0 -7.0 2.38 2.32 2.27 2.21 2.15 -2.0 2.70 2.64 2.58 2.51 2.45 2.94 2.87...
  • Page 432 Model: ASYG07KMCF Indoor temperature (°CDB) Outdoor temperature 16.0 18.0 20.0 22.0 24.0 (°CDB) (°CWB) -15.0 -16.0 1.97 1.92 1.88 1.83 1.78 -10.0 -11.0 2.23 2.18 2.13 2.07 2.02 -5.0 -7.0 2.38 2.32 2.27 2.21 2.15 -2.0 2.70 2.64 2.58 2.51 2.45 2.94 2.87...
  • Page 433 Model: ASYG07KETA, ASYG07KETA-B Indoor temperature (°CDB) Outdoor temperature 16.0 18.0 20.0 22.0 24.0 (°CDB) (°CWB) -15.0 -16.0 1.97 1.92 1.88 1.83 1.78 -10.0 -11.0 2.23 2.18 2.13 2.07 2.02 -5.0 -7.0 2.38 2.32 2.27 2.21 2.15 -2.0 2.70 2.64 2.58 2.51 2.45 2.94...
  • Page 434 Model: ASYG07KETE, ASYG07KETE-B Indoor temperature (°CDB) Outdoor temperature 16.0 18.0 20.0 22.0 24.0 (°CDB) (°CWB) -15.0 -16.0 1.97 1.92 1.88 1.83 1.78 -10.0 -11.0 2.23 2.18 2.13 2.07 2.02 -5.0 -7.0 2.38 2.32 2.27 2.21 2.15 -2.0 2.70 2.64 2.58 2.51 2.45 2.94...
  • Page 435 Model: ASYG07KETF, ASYG07KETF-B Indoor temperature (°CDB) Outdoor temperature 16.0 18.0 20.0 22.0 24.0 (°CDB) (°CWB) -15.0 -16.0 1.97 1.92 1.88 1.83 1.78 -10.0 -11.0 2.23 2.18 2.13 2.07 2.02 -5.0 -7.0 2.38 2.32 2.27 2.21 2.15 -2.0 2.70 2.64 2.58 2.51 2.45 2.94...
  • Page 436  Ceiling type Model: ABYG18KRTA Indoor temperature (°CDB) Outdoor temperature 16.0 18.0 20.0 22.0 24.0 (°CDB) (°CWB) -15.0 -16.0 4.66 4.55 4.44 4.32 4.21 -10.0 -11.0 5.28 5.16 5.03 4.91 4.78 -5.0 -7.0 5.63 5.50 5.36 5.23 5.09 -2.0 6.39 6.24 6.09 5.94...
  • Page 437  Floor type Model: AGYG09KVCA Indoor temperature (°CDB) Outdoor temperature 16.0 18.0 20.0 22.0 24.0 (°CDB) (°CWB) -15.0 -16.0 2.53 2.47 2.41 2.35 2.29 -10.0 -11.0 2.87 2.80 2.74 2.67 2.60 -5.0 -7.0 3.06 2.99 2.92 2.84 2.77 -2.0 3.48 3.39 3.31 3.23...

  • Page 438: Capacity Compensation Rate For Pipe Length And Height Difference

    7. Capacity compensation rate for pipe length and height difference Height difference H Indoor unit is higher than outdoor unit Indoor unit is lower than outdoor unit Outdoor unit Indoor unit Outdoor unit Indoor unit Connection pipe Connection pipe 7-1. Models: AOYG18KBTA3 and AOYG24KBTA3 NOTE: Values mentioned in the table are calculated based on the maximum capacity.
  • Page 439 ¢ Indoor unit: 9,000 Btu/h Pipe length Cooling — — — 0.956 0.942 0.928 — — 0.977 0.963 0.950 0.936 Indoor unit is higher than outdoor unit *1 — 0.992 0.985 0.971 0.957 0.943 1.003 0.996 0.989 0.975 0.961 0.947 1.007 1.000 0.993...
  • Page 440 ¢ Indoor unit: 14,000 Btu/h Pipe length Cooling — — — 0.969 0.962 0.953 — — 0.982 0.977 0.970 0.961 Indoor unit is higher than outdoor unit *1 — 0.992 0.990 0.985 0.977 0.968 0.998 0.996 0.994 0.989 0.981 0.972 1.002 1.000 0.998...

  • Page 441: Additional Charge Calculation

    8. Additional charge calculation 8-1. Model: AOYG18KBTA3 Refrigerant type Refrigerant amount 1,800 Refrigerant charge Total pipe length 30 or less 50 (Max.) 20 g/m Additional charge amount 8-2. Model: AOYG24KBTA3 Refrigerant type Refrigerant amount 1,800 Refrigerant charge Total pipe length 30 or less 50 (Max.) 20 g/m...
  • Page 442 9. Airflow 9-1. Model: AOYG18KBTA3  Cooling 2,220 1,307  Heating 2,160 1,271 9-2. Model: AOYG24KBTA3  Cooling 2,270 1,336  Heating 2,730 1,607 - 434 - 9-1. Model: AOYG18KBTA3 9. Airflow...

  • Page 443: Operation Noise (Sound Pressure)

    10. Operation noise (sound pressure) 10-1. Noise level curve ¢ Model: AOYG18KBTA3  Cooling  Heating NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 NC-45 NC-45 NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 NC-20 NC-20 NC-15 NC-15 1,000 2,000 4,000 8,000 1,000...
  • Page 444 10-2. Sound level check point Rear Microphone Microphone Airflow Side view Rear view NOTE: Detailed shape of the actual outdoor unit might be slightly different from the one illustrated above. - 436 - 10-2. Sound level check point 10. Operation noise (sound pressure)

  • Page 445: Electrical Characteristics

    11. Electrical characteristics Model name AOYG18KBTA3 AOYG24KBTA3 Voltage 230 ~ Power supply Frequency 12.0 14.5 Maximum operating current * Starting current Main fuse (Circuit breaker) current Power cable Wiring spec. * Connection Cross-sectional area cable * Limited wiring length : Maximum operating current is the total current of the indoor unit and the outdoor unit. : Selected sample based on Japan Electrotechnical Standards and Codes Committee E0005.

  • Page 446: Safety Devices

    12. Safety devices Model Type of Protection form protection AOYG18KBTA3 AOYG24KBTA3 250 V, 5 A 250 V, 5 A Current fuse Circuit protection 250 V, 20 A 250 V, 25 A (Main PCB) 250 V, 3.15 A 250 V, 3.15 A 125 ±10°C 125 ±10°C Activate...

  • Page 447: Function Settings

    13. Function settings 13-1. Setting methods WARNING Never touch electrical components such as the terminal blocks or reactor except the switch on the display board. It may cause a serious accident such as electric shock. CAUTION • Once refrigerant charging is completed, be sure to open the valve prior to performing the local settings.
  • Page 448 ¢ Setting method Various settings can be adjusted by changing DIP switches and push switches on the PCB of the outdoor unit. LED display part POWER MONITOR ERROR /MODE ( GRN ) ( RED ) TEST RUN / SET 1 SET 2 CHECK PUMP DOWN...
  • Page 449 ¢ Description of display LED lamp Function or operation method • Turns on when the power supply is ON (Including when error occurs). (1) POWER/MODE Green • Indicate the MODE by the number of flashes when the installation function is active. (2) ERROR Flashes at high-speed when there is an error.
  • Page 450 13-2. Outdoor unit low noise operation function (option) Change the outdoor unit low noise operation by using this setting. CAUTION • When the low noise operation function is working, cooling and heating capacity will de- crease. • When changing the settings, explain to the customer beforehand that the capacity decreas- NOTES: •...

  • Page 451: Check And Test

    14. Check and test 14-1. Check run • The check run is a function to screen and detect any wiring errors. • After carrying out the check run, you can use the automatic wiring correction function to correct the wiring. •...
  • Page 452 ¢ Operating procedure for check run CAUTION Initiate check run after more than 12 hours after the power supply is connected. NOTE: Be sure that the indoor unit and outdoor unit are not operating before starting the check run. Press the CHECK switch for 3 seconds or more. CHECK The number of indoor units (and the places) connected through the communication lines is dis- played.
  • Page 453 After the check run is completed, results will be displayed. Fill the displayed results in the result table accordingly. • If the connection is correct (Example: When 4 indoor units are connected) After the number of connected units are displayed, the LED for each unit will light up in order from A to D.
  • Page 454 [How to record the contents] • Fill the displayed results according to the following example. Example: When piping A to D is connected but the wires for B and C are connected in reverse. <Displayed results> The LEDs will light up in 7 second intervals in the following order. POWER MONITOR ERROR...
  • Page 455 c. Select the correction method. Correct the wiring manually.*2 Proceed to step 6. Use the Automatic wiring correction function.*1 Proceed to step 5. Write down the same results in the label on the reverse side of the service panel. The results recorded are needed at the time of servicing. <Result Table>...
  • Page 456 ¢ Failure indication of check-run judgment The check run stops when there is an error, and the LED shows the relevant error indication. When you encounter the errors described here, perform checking by using the cooling test run of the indoor unit.
  • Page 457 14-2. Test run CAUTION Always connect the power supply 12 hours prior to the start of the operation in order to protect the compressor. 1. Indoor unit a. Is the drain normal? b. Is there any abnormal noise and vibration during operation? 2.
  • Page 458 Push TEST RUN switch for more than 3 seconds. POWER MONITOR ERROR /MODE ( GRN ) ( RED ) POWER/MODE LED will turn on, and test run stops. 14-3. Error code If an error occurs, the LED lights to inform the relevant location and the code. When error occurs, the error LED blinks at high speed.
  • Page 459 ¢ Error code display While the error is occurring, briefly push the SW1. The error code is displayed. Example: Coil error (Error cord = 9A.1) POWER ERROR MONITOR /MODE ( GRN ) ( RED ) [A(10)] Blink (High speed) (9-blink) Display mode LED on: Blink:...
  • Page 460 Error code Error type 11.3 Serial communication error 11.4 Serial communication error during operation 16.5 Communication error between controller and outdoor unit 22.1 Indoor unit capacity error 23.1 Connection prohibited (Series error) 5U.1 Indoor unit error 62.1 PCB model information error 62.3 EEPROM access error 62.8...
  • Page 461 14-4. Pump down WARNING During the pump down operation, make sure that compressor is off before you remove the refriger- ant pipe. Do not remove the connection pipe while the compressor is in operation with valve open. This may cause abnormal pressure in the refrigeration cycle that leads to breakage and even injury. ¢...
  • Page 462 7. Disconnect the power supply or turn off the breaker. NOTE: • Even if the pump down operation is not stopped by pushing the switch as in step 6, the operation stops automatically after 15 minutes, and the LED light as fol- lows.
  • Page 463 15. Accessories 15-1. Model: AOYG18KBTA3 Part name Exterior Q’ty Part name Exterior Q’ty Installation manual Drain pipe 15-2. Model: AOYG24KBTA3 Part name Exterior Q’ty Part name Exterior Q’ty Adapter K Installation manual 12.70 mm (1/2 in) to 9.52 mm (3/8 in) Drain pipe - 455 - 15-1.
  • Page 464 16. Outdoor unit installation precautions NOTE: The information listed below are general precautions. Some models also include items that do not apply. 16-1. Places where prohibited for use • Places where there is a danger of combustible gas leakage. • Places where sulfur gas, chlorine gas, acid, alkali, or other matter which effects equipment is gen- erated.

This manual is also suitable for:

Auxg09kvlaAuxg12kvlaAuxg14kvlaAuxg18kvlaArxg07kslapArxg09kslap ... Show all

Table of Contents
