3-4. Wall mounted type
23
Front panel B
Part no.
9387473018
Air filter
9323546004
Intake grille assy
9333719009
Grille clamper L
9333704005
Grille clamper R
22
Part name
- (02-41) -
Front panel total assy
24
Front panel
Panel cover
Service part
♦
♦
♦
♦
3. Indoor unit parts list
