www.ltech-led.com
3. The connection diagram of 2 kinds of DMX/RDM terminals:
LT-905-OLED
LT-905-OLED
Installation distance > 20mm
These 2 terminals can be connected in a mixed way.
*
Installation attentions:
be sure not to block the vent, or it will affect lifetime of decoder for
LT-905-OLED
5-pin XLR connected in parallel
Vent
LT-905-OLED
RJ45 connected in parallel
Please reserve enough ventilation distance between decoders (>20mm),
8
Resistor
terminal
LT-905-OLED
Resistor
terminal
LT-905-OLED
poor heat dissipation
.
