7. Tool
001
Screen: ON+Addr
Screensaver open and display address
without operating in two minutes.
Screen: ON+black
Screensaver open and black
without operating in two minutes..
DMX: 001 Hz: High
Mode: RGBW 8bit
Curve: Standard
Dim: Smo TOOL&v
Screen: OFF
Screensaver not enable.
DMX: 001 Hz: High
Mode: RGBW 8bit
Curve: Standard
Dim: Smo TOOL&v
Screen: ON+Addr
Contrast: 40%
Beep: ON TEST&v
EXIT&v
CH1: 255
CH3: 255
CH5: 255
Fast self-testing function: press "
simultaneously for 2-3 seconds under any page,
decoder will enter self-testing function.
5
Press "∧" or "∨"
key to enter submenu
Test
Press "∧" or "∨"
key to enter
submenu of test.
Brightness setting
CH2: 255
(range: 0~255)
CH4: 255
ALL: 255
Press"∨" to exit
EXIT &V
∧" or " ∨" keys
