OLED display
12
8 bit / 16 bit
E500585
3 kinds of DMX interfaces
Dimming Curve: 0.1~9.9
CHANNELS
Protection: OTP/OCP/SCP
www.ltech-led.com
LT-912-OLED
Photoelectric
isolation
www.ltech-led.com
Product introduction
1. Designed for Hi-power multiple channels application, 12 channels output, and Max.
4A current per channel, up to 1152W output power.
2. Easy operation with OLED screen and touch buttons.
3. 3 kinds of mode optional: single color, color temperature, RGB.
4. 5-pin XLR, RJ45 and green terminal DMX interface with photoelectric isolation, improve
signal transmission efficiency and anti-interference ability, the green terminal also
has signal amplifier function.
5. With
RDM remote management protocol,
RDM master console, such as parameters browsing & setting, DMX address
setting, equipment recognition, etc.
6. With firmware upgrade function.
7.
With short circuit, over current and over temp. protection, as well as warning function
when fault.
8. With power-on state management and fast self-testing function.
9. 16bit (65536 levels) / 8bit (256 levels) grey level optional.
10. Optional for standard, linear, LOG or custom 0.1-9.9 dimming curve.
100%
Output
brightness
<1
>1
0
DMX value
5-pin XLR
RJ45
RDM
Photoelectric
isolation
the operations can be completed via the
1.0
0.8
6.5
3.5
Gamma value
0.9
2.5
1.5
255
Short circuit
Over temp.
Over current
protection
protection
protection
1
Display

Advertisement

loading
Need help?

Need help?

Do you have a question about the DMX512 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ltech DMX512

Summary of Contents for Ltech DMX512

  • Page 1 Product introduction 1. Designed for Hi-power multiple channels application, 12 channels output, and Max. 4A current per channel, up to 1152W output power. 2. Easy operation with OLED screen and touch buttons. 3. 3 kinds of mode optional: single color, color temperature, RGB.

  • Page 2: Technical Specs

    Technical specs Main component description Model : LT-912-OLED Input signal : DMX512/RDM OLED screen Input voltage : 12~24Vdc Current load : 4A × 12CH Max 48A Signal indicator (0~48W...96W) × 12CH Max. 1152W Output power : DMX interface :...
  • Page 3 OLED screen interface Press “∧" or “∨" key to choose. 6. Enhance DMX: 001 Hz: High Press "M" key, switch entries. dimming Mode: RGB 8bit Optional : Std (standard) Long press “M” key, back to main page. Curve: Standard Smo (smooth) Press "∧"...

  • Page 4: Wiring Diagram

    Wiring diagram Color temperature LEDs Single color LEDs 1. Connecting LED lights: DMX/RDM signal DMX/RDM signal Dimming mode CT mode RGB LEDs LT-912-OLED RGB mode Output port 12-24Vdc 2. DMX console onnection (Wiring method on P7) Power to...
  • Page 5 3. The connection diagram of 3 kinds of DMX/RDM terminals: Address setting table Resistor 5-pin XLR terminal Mode Mode connected LT-912-OLED LT-912-OLED LT-912-OLED in parallel Address Address Quantity Quantity Resolution 8bit 8bit 8bit Resolution 16bit 16bit 16bit Resistor...
  • Page 6 Work with RDM editor RDM editor App interface instruction LT-912-OLED can work with LTECH RDM editor (Model: WiFi-RDM01) to realize changing the Download the App, setting the LT-912-OLED parameters (frequency, bit, curve, modes, dimming parameters by long-range setting, wiring diagram as below: range, screensaver, etc.) after well connecting the RDM editor, more details, please check the...
