2 General information

2.3.1 Loading and transport without occupants

Make the desired pack size and secure the wheelchair and all dismantled parts with adequate
load securing. Basically, the wheelchair is suitable for transport (land / air). Find out about suita-
ble load securing measures before transporting the wheelchair.
Carrying points:
• Frame tubes rear left / right
• front frame tubes left / right
• but not on the footplates.
2.3.2 Transport of the wheelchair with occupants in the vehicle
Due to their purpose, wheelchairs can never achieve the stable properties of a seat sys-
tem that is permanently mounted in the vehicle. Whenever possible, we recommend using a
fixed vehicle seat to transport a person in the vehicle.
Only wheelchairs that have successfully passed a crash test according to ISO
7176-19 may be used as a seat in a motor vehicle. Successfully tested wheelchairs are
marked with the symbol for the attachment point on the attached label.
The Dynamis MV has been successfully tested according to ISO 7176-19 and
is therefore approved as a seat in a motor vehicle if you have the necessary
restraint devices.
Please check whether your wheelchair is custom-made and may therefore not be used as
a seat in a motor vehicle.
For more information, see the crash test booklet:
www.sorgrollstuhltechnik.de/downloadportal.
We can recommend the following manufacturers of restraint systems:
• SORG transport brackets on the wheelchair
• AMF-BRUNS GmbH & Co.KG
• Q'Straint Europe
Attachment points / methods for transportation in motor vehicles
When using the wheelchair as a seat in the motor vehicle, only use the places
marked with the symbol for the attachment point. These are usually located in the back
left and right (1) and front left and right. (2)
(1) (1)
2x 2x
10 von 40
(2)
Instructions for use Dynamis MV
2x 2x
2021-12-01
