3.1

Handling of the wheels

3.1.1 General information on wheels

Using the handrims to break the wheels creates frictional heat.
Handrim covers can stretch in the heat and loosen from the handrim.

3.1.2 Tire pressure

You can find the appropriate operating pressu-
re on the tire casing - usually 3-10 bar. (1)
If you have a flat tire, please contact your
specialist retailer.
3.1.3 Quick-release wheels
Remove:
(1)
1.
Insert:
(1)
(2) After insertion, the locking ball (A) must protrude visibly. After each insertion, pull at
least 1x to test whether the quick-release axle is engaged. It should no longer be possible to
pull the wheels outwards.
2021-12-01
(1)
(2)
(2)
(A)
Instructions for use Dynamis MV
1.
13 von 40
