Restart Button; Technical Specifications - urmet domus iPerCom Mikra2 1060 Installation Handbook

6. RESTART BUTTON

Hold the restart button (13) pressed for 10 seconds to restart the device. The restarting of the device is
confi rmed by the fl ashing of the camera LED.
Remove the metal cover of the panel to access the restart button.

7 TECHNICAL SPECIFICATIONS

Power voltage POE: ...................................................................................................................... 44 ÷ 57 V
Local power voltage: ............................................................................................................................. 48 V
Maximum consumption during video calls:............................................................................................. 3,5 W
Maximum stand-by consumption: ............................................................................................................. 2 W
LAN maximum operating distance (with POE or without POE) ................................. 100 m with CAT5 cable
Max. distance from supplementary power supply: ..........25m with wire cross section area. 0.5 - 1.0 mm
2
Name tag dimensions: ...........................................................................................................48.5 x 15.5 mm
Tag and button light: .................................................................................................................. White LEDs
Dimensions (WxHxD): ....................................................................................................... 100 x 180 x 28 mm
Degree of protection of casings: ...............................................................................................................IP55
Degree of protection from mechanical shocks: ........................................................................................IK07
Working temperature range:................................................................................................... -10 °C ÷ +55 °C
11
DS1060-134A
