3.2 DESCRIPTION OF TERMINALS AND JUMPERS
Terminal board
+
Positive terminal for local power supply
-
Negative terminal for local power supply

4 WIRING INSTRUCTIONS

Remove the insulation sheath of the CAT5 cable (with rigid wires) for at least 40mm.
Strip the conductors for no more than 6mm.
Insert the wires in the connector respecting the positions and colour codes shown (Standard T568B).
1
Proceed as shown below if a wire needs to be removed from the connector:
Refer to the instructions contained in the system manual for maximum distances and confi guration
operations.

5 SPEAKER VOLUME ADJUSTMENT

For information on sound levels settings, refer to the system manual.
10
8
1
2
Wire No.
1
White-Orange
2
3
4
5
6
7
8
1
Wire colour
Orange
White-Green
Blue
White-Blue
Green
White-Brown
Brown
2
DS1060-134A
