5 SPEAKER VOLUME ADJUSTMENT

For information on sound levels settings, refer to the system manual.

6. RESTART BUTTON

Hold the restart button (13) pressed for 10 seconds to restart the device. The restarting of the device is
confirmed by the flashing of the camera LED.
Remove the metal cover of the panel to access the restart button.

7 DDA FUNCTIONS SIGNALS

There are three backlit icons with green LEDs dedicated to the system status signals (DDA) on the front of
the door unit. Specifically, the signals indicate:
Symbol Description
Call in progress
Conversation in progress
Open door indicator

8 OPENING THE DOOR USING A PROXIMITY KEY

Pass the proximity key near the reader on the panel.
For a correct reading of the transponder key, approach the key to the icon
If the key is valid, the icon LED
If the key is not valid, no indication will appear on panel and the door will remain closed.

9 KEY TO SYMBOLS

Symbol

10 TECHNICAL SPECIFICATIONS

Power voltage POE: ...................................................................................................................... 44 ÷ 57 V
Local power voltage .............................................................................................................................. 48 V
Maximum consumption during video calls:............................................................................................. 3,5 W
Maximum stand-by consumption: ............................................................................................................. 2 W
LAN maximum operating distance (with POE or without POE) ................................. 100 m with CAT5 cable
Max. distance from supplementary power supply: ..........25m with wire cross section area. 0.5 - 1.0 mm
Supported user key type: ...................................................................................................... Mifare (1125/54)
Name tag dimensions: ...........................................................................................................48.5 x 15.5 mm
Tag and button light: .................................................................................................................. White LEDs
Dimensions (WxHxD): ....................................................................................................... 100 x 180 x 28 mm
Degree of protection of casings: ...............................................................................................................IP55
Degree of protection from mechanical shocks: ........................................................................................IK07
Working temperature range:................................................................................................... -10 °C ÷ +55 °C
12
will light up green on the panel and the door will open.
Direct input voltage
See the installation manual of the device
.
Description
2
DS1060-133A
