To upgrade the Kaleido system software and firmware
1 Insert the USB key into any USB port on the multiviewer. After a while, a message
appears at the bottom left corner of the monitor wall, reporting that the Upgrade
Manager is verifying software, firmware, and safe mode versions.
Note: You can click the Details button to view more information. The
button label alternates between Details and Hide.
The firmware verification process may take a minute or so.
Note: If nothing happens, very that you have loaded onto the USB key the
Kaleido Software operating system file, with the following
correct
format:
kxos-9.00_build_xxxx-4GB.img
2 Once the verification process is complete, you will be advised what upgrade action, if
any, needs to be performed.
IMPORTANT
To cancel the upgrade process, you must click to ABORT within 30
seconds.
During the 30-second countdown period, you may expect that removing the
USB key will cancel the upgrade. However, if you do so, the system will still
report that it is updating the software, but the upgrade will fail after a minute
or so.
Insert the USB key again to properly update your system.
Kaleido-X (7RU)
Installation & Service Manual
Upgrade
dashboard
Click here to
show or hide
details
