Parts List
Item Quantity
32 1
33 1
34 1
35 1
36 1
37 1
38 1
39 1
40 1
41 6
42 1
43 2
22
Reference
U7 14-pin DIP socket
U7 50MHz
U8 74AHC04/SO
U9 74HCT86/SO
U10 RD-0412
U11 EPN001
U14 EPF6016TC144-2
U15 8-pin DIP socket
U15 EPC1441PC8
JP1,JP2,JP3,JP4,JP6,J
Jumper shunt for 0.1" header
P7
Bracket
Scew
Seiko Epson Corporation
Part
Machined socket, 14-pin
Fox 50.0MHz oscillator or equiv., 14-
pin DIP pckg, socketed
SO-14, 74AHC04
SO-14, 74HCT86
Xentek RD-0412, positive power
supply
Xentek EPN001, negative power
supply
Altera EPF6016TC144-2
Machined socket, 8-pin
Altera EPC1441PC8, socketed
Computer Bracket, Blank - PCI,
Keystone - Cat. No. 9203
Pan Head, #4-40 x 1/4"
