8 Parts List

Item Quantity
1 15
2 1
3 2
4 3
5 1
6 2
7 3
8 9
9 2
10 6
11 1
12 1
13 1
14 3
15 1
16 1
17 13
18 1
19 1
20 1
21 1
22 2
23 3
24 1
25 3
26 1
27 1
28 1
29 1
30 3
31 1
S5U13705B00C Rev 2.0 PCI Evaluation Board
Rev. 3.1
Reference
C1-C11, C16, C17, C24,
0.1uF, 20%, 50V
C25
C12 10uF, 10%, 25V
C22,C18 47uF, 10%, 16V
C19,C20,C21 4.7uF, 10%, 50V
C23 56uF, 20%, 35V, Low ESR
C36,C33 33uF, 10%, 20V
C34,C35,C37 68uF, 10%, 10V
C38-C46 0.22uF, 5%, 50V
H2,H1 HEADER 17X2
JP1,JP2,JP3,JP4,JP6,J
HEADER 3
P7
JP5 HEADER 2
J5 CON40A
L1 1uH
L2,L3,L4 Ferrite Bead
Q1 MMBT3906
Q2 MMBT3904
R1-R6, R10, R11, R33,
15K, 5%
R36-R39
R8 0R
R14 475K, 1%
R15 200K Pot.
R16 14K, 1%
R18, R17 10K, 5%
R19, R20, R32 100K, 5%
R21 100K Pot.
R34, R35, R40 1K, 5%
SW1 SW DIP-6
U1 S1D13705
U2 14-pin DIP socket
U2 6MHz
U3,U4,U5 74AHC244
U6 LT1117CM-3.3
Seiko Epson Corporation
Part
1206 pckg., ceramic capacitor
Tantalum capacitor size D
Tantalum capacitor size D
Tantalum capacitor size D
Electrolytic, radial, low ESR
Tantalum capacitor size D
Tantalum capacitor size D
X7R, 1206 pckg
0.1", 17x2, unshrouded header
0.1", 3x1, unshrouded header
0.1", 2x1, unshrouded header
0.1", 20x2, 0.025" sq. shrouded
header, center key, t/h
RCD MCI-1812 inductor 1uH MT or
MSI-1812 1uH MT
Philips BDS3/3/8.9-4S2
Generic MMBT3906
Generic MMBT3904
1206 resistor
1206 resistor, 0 ohms
1206 resistor
200K Trim POT Spectrol 63S204T607
or equiv.
1206 resistor
1206 resistor
1206 resistor
100K Trim POT Spectrol 63S104T607
or equiv.
1206 resistor
6 position DIP switch
Machined socket, 14-pin
Fox 6.0MHz oscillator or equiv., 14-pin
DIP pckg, socketed
SO-22, TI74AHC244 or equivalent
Linear Technology 5V to 3.3V
regulator, 800mA or equiv.
Parts List
Description
