2 Install the Emerson 430 SpeedVue
Topics covered in this chapter:
• Mounting methods
• Mount the Emerson 430 SpeedVue onto the AMS 2140
• Power the Emerson 430 SpeedVue
2.1 Mounting methods
You can mount the Emerson 430 SpeedVue in a variety of ways depending on
the application.
AMS 2140 sensor holder mount
You can mount the Emerson 430 SpeedVue onto either side of the AMS
2140. Use the two shoulder strap connectors on either side of the analyzer to
mount the sensor holder.
Note
An electrostatic discharge is possible when you clean the exterior of the
sensor holder. The Emerson 430 is not approved for use in a hazardous
location. Do not use any abrasive or corrosive chemicals or materials. Do not
use petroleum distillates and ketone solvents, for example, acetone, gasoline
and kerosene. Use a dry, lint-free towel or cloth dampened with a mild soap
and water solution.
3/8-24 thread mount
On the side of the Emerson 430 SpeedVue is a 3/8-24 threaded hole for use
with Emerson's Magnetic Swivel Base (B404-BASE). The Magnetic Swivel Base
provides a strong magnetic mount for precise speed measurements and
unlimited positioning.
1/4-28 thread mount
On the other side of the Emerson 430 SpeedVue is a 1/4-28 thread for use
with Emerson's rare earth magnets. Emerson offers a magnetic mounting kit
for this thread, which includes a rare earth magnet and a 2-pole magnet
base. The kit provides a strong magnetic mount in a convenient pocket size.
