SOLID-STATE MEMORY CAMCORDER
PXW-Z190V
PXW-Z190T
SERVICE MANUAL
1st Edition

Advertisement

Table of Contents
loading

Related Manuals for Sony PXW-Z190V

Summary of Contents for Sony PXW-Z190V

  • Page 1 SOLID-STATE MEMORY CAMCORDER PXW-Z190V PXW-Z190T SERVICE MANUAL 1st Edition...
  • Page 2 警告 このマニュアルは，サービス専用です。 お客様が，このマニュアルに記載された設置や保守，点検，修理などを行うと感電や火災， 人身事故につながることがあります。 危険をさけるため，サービストレーニングを受けた技術者のみご使用ください。 WARNING This manual is intended for qualified service personnel only. To reduce the risk of electric shock, fire or injury, do not perform any servicing other than that contained in the operating instructions unless you are qualified to do so. Refer all servicing to qualified service personnel.
  • Page 3 注意 FÖRSIKTIGHET! 指定以外の電池に交換すると，破裂する危険があり Fara för explosion vid felaktigt placerat batteri. ます。 Byt endast mot samma eller likvärdig typ av batteri, 必ず指定の電池に交換してください。 enligt tillverkarens rekommendationer. 使用済みの電池は，国または地域の法令に従って När du kasserar batteriet ska du följa rådande lagar 処理してください。 för regionen eller landet. CAUTION PAS PÅ...

  • Page 4: Table Of Contents

    Table of Contents Manual Structure .....................................3 Purpose of this manual ..................................3 Related manuals ....................................3 Trademarks ......................................3 Section 1 Service Overview..................................4 1-1. Product Comparison Table ................................4 1-2. Location of Boards ..................................5 1-3. Circuit Description ..................................6 1-3-1. TG-289 Board ..................................6 1-3-2. AR-5 Board ....................................6 1-3-3.
  • Page 5 2-2. Outside Panel Assembly ................................25 2-3. CT-287A board ................................... 27 2-4. VC-41 Board ....................................29 2-5. DC Fan ......................................33 2-6. Lens ......................................35 2-6-1. LD-136 Board, Lens Assembly ............................35 2-6-2. SE-1187 Board, Lens (LSV-1740B), Prism Assembly (LSV-1620) ..................37 2-7.

  • Page 6: Manual Structure

    Manual Structure Purpose of this manual This manual describes the maintenance and block service of this unit. The contents are written for system engineers and service engineers with special knowledge. Related manuals For this unit, the following manuals are prepared for engineers. •...

  • Page 7: Section 1 Service Overview

    Section 1 Service Overview 1-1. Product Comparison Table Model PXW-Z190V PXW-Z190T Destination UC, J, CEE, CN1, UC, CEE COLOR system NTSC/PAL (Selectable) NTSC/PAL (Selectable) — — Internal recording media LENS LSV-1740B LSV-1740B — — Projector ✓ ✓ ✓ ✓ Wi-Fi 2.4/5.2/5.3/5.6 GHz...

  • Page 8: Location Of Boards

    1-2. Location of Boards VF-98 PSW-109 GP-1019 SH-85 HN-441 PD-126 RS-55 IO-283 SD-66 IF-1346 SH-85 JK-106 TC-117 SW-1735 SS-107 VC-41 CT-287A AXM-60 FU-82 DD-53 BI-342 AR-5 SEC-58 BI-350 KSW-71 WF-1008 DC-184 MEC-43A TG-289A VSW-81A IR-73A GCN-19 SE-1187 LD-136...

  • Page 9: Circuit Description

    1-3. Circuit Description 1-3-1. TG-289 Board The TG-289 board contains a Gain switch and a WB switch. 1-3-2. AR-5 Board The AR-5 board contains IC0700, IC0300, IC2101 and an SD slot. IC0700 has an interface conversion function between IC0600 and IC6000 on the VC-41 board and an audio function. The PCIe signal from IC6000 on the VC-41 board is distributed to four devices (IC2000, IC2101, IC2602, and wired LAN) through IC0300.

  • Page 10: Board

    1-3-8. IO-283 Board The IO-283 board contains the NFC and a USB2.0 connector. The NFC receives data from IC6000 on the VC-41 board through the NFC antenna. USB2.0 signals from IC2602 on the VC-41 board are connected to the USB connector. The USB2.0 connector is provided only for connection to an LTE dongle.

  • Page 11: Se-1187 Board

    1-3-16 SE-1187 Board The SE-1187 board contains a gyro sensor. The gyro sensor signal is input to IC9600 on the LD-136 board. 1-3-17. VSW-81 Board The VSW-81 board contains a switch for selecting “Preset” or “Variable” of the variable liquid crystal ND. 1-3-18.

  • Page 12: Board

    1-3-29. BI-342 Board The BI-342 board contains a 1/3-type CMOS image sensor. The BI-342 board is used for Rch and Bch. 1-3-30. BI-350 Board The BI-350 board contains a 1/3-type CMOS image sensor. The BI-350 board is used for Gch 1-3-31.

  • Page 13: Connectors And Cables

    1-4. Connectors and Cables When connecting cables to connectors during installation or service, use connectors and cables that meet the specifications of this unit. 1-5. Connector Input/Output Signals 1-5-1. Input Signals DC IN DC jack EXT DC - External View -...

  • Page 14: Output Signals

    AUDIO INPUT 1/2 XLR 3-pin, Female - External View - (0 dBu = 0.775 V rms) Signal Specifications — XLR HOT LINE: +4 dBu/0 dBu/-3 dBu (/EBUL)/10 kΩ MIC: -80 dBu ～ -30 dBu/3 kΩ XLR COLD LINE: +4 dBu/0 dBu/-3 dBu(/EBUL)/10 kΩ MIC: -80 dBu ～...
  • Page 15 10. USB2.0 (HOST) Host: USB 2.0 type A 11. LAN RJ-45 1000BASE-T, 100BASE-T, 10BASE-T...

  • Page 16: Functions Of Onboard Led Indicators

    1-6. Functions of Onboard LED Indicators 1-6-1. AR-5 Board D1000 D0851 AR-5 Board/Side B Ref No. Name Color Description Normal State (address) (Power On) D0851 DONE Yellow green Indicates completion of IC0700 configuration Yellow green D1000 Yellow green Indicates IC1000 operating state. Yellow green 1-6-2.

  • Page 17: Notes On Replacing The Part And Printed Wiring Board

    1-7. Notes on Replacing the Part and Printed Wiring Board 1-7-1. Power Supply during Repairs AC power adaptor Use the AC power adaptor when repairing the unit. 1-7-2. Precaution on Replacing the VC-41 Board The following data need to be written on a brand-new board for repair because the board has no information that is unique to a model.

  • Page 18: Notes For Replacing The Evf Display Device (Lcd902)

    Update of MAC Address When a board that contains Wi-Fi has been replaced or when replacing a board that contains the main IC (CPU) has been replaced, the MAC address must be reloaded. Procedure of the MAC address update: Note Perform the below operations after all work has been done.

  • Page 19: Checking The Wi-Fi Function

    When replacing VC board (in case adjustment values cannot be read): Read the QR code printed in EVF display device (LCD902) using with “QR_Code_Reader_Ver1.0_x64”. Make sure the adjustment value from the read value as shown below, and memorize it. Example when QR code is 1958817021A Brightness value White balance value Start the Adjust Manual in the Adjust Station and execute the “EVF Data Input”...

  • Page 20: Circuit Protection Parts

    1-9. Circuit Protection Parts 1-9-1. Replacing Fuses Fuses are essential parts for safe operation. Be sure to use the parts specified in this manual. Replacing a fuse with an unspecified one may cause fire or electric shock. The unit is equipped with fuses. The fuses blow if overcurrent flows in the unit due to an abnormality. In that case, turn off the main power of the unit once, inspect inside of the unit, and then remove the cause of the overcurrent.

  • Page 21: Flexible Flat Cable, Flexible Board And Fine-Wire Coaxial Cable

    1-11. Flexible Flat Cable, Flexible Board and Fine-Wire Coaxial Cable 1-11-1. Disconnecting/Connecting Flexible Flat Cable and Flexible Board Note • Be very careful not to fold flexible flat cables and flexible board. Life of flexible flat cable will be significantly shortened if them are folded and flexible board.

  • Page 22: Disconnecting/Connecting Fine-Wire Coaxial Cable

    1-11-2. Disconnecting/Connecting Fine-Wire Coaxial Cable Note • Be very careful when handling the fine-wire coaxial cable so that fine wires are not disconnected. • When disconnecting the fine-wire coaxial cable, be sure to hold the connector. Do not attempt to pull the cable. •...
  • Page 23 Type B Disconnecting Hold both sides of the fine-wire coaxial cable connector, and pull the connector straight to disconnect it. Both sides of connector Hold the connector to disconnect. Correct Do not attempt to disconnect by Fine-wire coaxial cable Wrong pulling the cable.
  • Page 24 Type C Disconnecting Use a tool with a hook as shown above. Hook the tool's hook to the connector of the fine-wire coaxial cable. Lift the tool straight in the arrow direction with the hook hooked to disconnect the connector of the fine-wire coaxial cable. Connector Hook the tool's hook to the connector of Tool...
  • Page 25 Type D Disconnecting Raise the pull-bar in the direction of arrow A to unlock it. Hold both sides of the fine-wire coaxial cable connector, and pull the connector straight to disconnect it. Pull-bar Correct Hold the connector to disconnect. Fine-wire coaxial cable Connector Wrong...

  • Page 26: Connecting/Disconnecting Coaxial Cable

    1-11-3. Connecting/Disconnecting Coaxial Cable Type A Disconnecting Correct Hold the plug to remove. Wrong Do not attempt to remove by pulling the cable. Hold the plug of coaxial cable. Pull out the coaxial cable in the direction arrow. Note Be sure to hold the plug when disconnecting the coaxial cable. Do not pull the cable. Connecting Hold the plug to connect Connecting connector...

  • Page 27: Section 2 Replacement Of Parts

    Section 2 Replacement of Parts Replacement procedures are described for only main parts. 2-1. Tightening Torque When tightening screws used in this unit, be sure to use a torque driver and tighten screws to the specified tightening torque. If the specified tightening torque is described in the figure in this section, tighten screws to the specified tightening torque in the figure.

  • Page 28: Outside Panel Assembly

    2-2. Outside Panel Assembly Procedure Remove the shoulder screw (M2 x 3.5), and then remove the outside guard. Remove the four precision screws (P2.6 x 8) and six precision screws (P2 x 4), and then remove the cabinet (BM). Precision screws (P2 x 4) Shoulder screw Precision screws...
  • Page 29 Remove the precision screw (P2 x 4), and then DC cable clamper. Remove the 12 precision screws (P2 x 4). Release the two hooks, and then remove the outside panel assembly. Note Be careful not to break the flexible flat cable. Disconnect the flexible flat cable from the connector (CN4612) on the CT-287A board.

  • Page 30: Ct-287A Board

    2-3. CT-287A board Preparation Remove the outside panel assembly. (Refer to “2-2. Outside Panel Assembly”.) Procedure Disconnect the coaxial cable and the flexible board from the two connectors (J7381, CN4612) on the CT-287A board. Release the coaxial cable from the CT inner. CT-287A board CT inner Coaxial cable...
  • Page 31 Remove the two precision screws. Release the two hooks, and then remove the WF block. Hooks WF block Precision screws (P2 x 4) Remove the three precision screws, and then remove the CT inner and the CT-287A board. Precision screws (P2 x 4) CT-287A board Precision screw...

  • Page 32: Board

    2-4. VC-41 Board Preparation Remove the outside panel assembly. (Refer to “2-2. Outside Panel Assembly”.) Remove the CT-287A board. (Refer to “2-3. CT-287A Board”.) Procedure Disconnect the two fine-wire coaxial cables from the two connectors (CN4200, CN4202) on the VC-41 board. VC-41 board Fine-wire coaxial cable CN4202...
  • Page 33 Disconnect the flexible board from the connector (CN100) on the SD-66 board. Disconnect the flexible flat cable from the connector (CN1001) on the JK-106 board. Detach the protection sheet (duct). Remove the four screws, and then remove the jack assembly, copper leaf tape (VC), and VC shield frame. Protection sheet (duct) Flexible board SD-66 board...
  • Page 34 Disconnect the six fine-wire coaxial cables from the six connectors (CN0400, CN0401, CN0402, CN4103, CN4104, CN4105) on the VC-41 board. 10. Disconnect the three flexible boards from the three connectors (CN4102, CN4301, CN4600) on the VC-41 board. Fine-wire coaxial cable Flexible board Flexible board VC-41 board...
  • Page 35 14. Disconnect the two flexible boards from the three connectors (CN2600, CN4202) on the VC-41 board. 15. Disconnect the flexible flat cable from the connector (CN4201) on the VC-41 board. 16. Remove the five radiation sheets from the VC-41 board. Radiation sheet BT-1 Flexible boards CN2600...

  • Page 36: Dc Fan

    2-5. DC Fan Preparation Remove the outside panel assembly. (Refer to “2-2. Outside Panel Assembly”.) Remove the CT-287A board. (Refer to “2-3. CT-287A Board”.) Remove the VC-41 board. (Refer to “2-4. VC-41 Board”.) Procedure Remove the five precision screws, and then remove the VC heat sink assembly. VC heat sink assembly Precision screws (P2 x 4)
  • Page 37 Remove the DC fan. Label Harness DC fan Remove the fan cushion from the DC fan. Fan cushion Label Harness DC fan Install the removed parts by reversing the steps of removal.

  • Page 38: Lens

    2-6. Lens 2-6-1. LD-136 Board, Lens Assembly Preparation Remove the outside panel assembly. (Refer to “2-2. Outside Panel Assembly”.) Remove the CT-287A board. (Refer to “2-3. CT-287A Board”.) Remove the VC-41 board. (Refer to “2-4. VC-41 Board”.) Remove the DC fan. (Refer to “2-5. DC Fan”.) Procedure Remove the two precision screws, and then open the LD-136 board.
  • Page 39 Remove the five precision screws, and then remove the lens assembly. Lens assembly Precision screws (P2.6 x 5) Install the removed parts by reversing the steps of removal.

  • Page 40: Se-1187 Board, Lens (Lsv-1740B), Prism Assembly (Lsv-1620)

    2-6-2. SE-1187 Board, Lens (LSV-1740B), Prism Assembly (LSV-1620) Preparation Remove the outside panel assembly. (Refer to “2-2. Outside Panel Assembly”.) Remove the CT-287A board. (Refer to “2-3. CT-287A Board”.) Remove the VC-41 board. (Refer to “2-4. VC-41 Board”.) Remove the DC fan. (Refer to “2-5. DC Fan”.) Remove the lens assembly.
  • Page 41 Remove the IM cover cushion. Attaching start position IM cover cushion IM cover cushion Note At the time of the installation, attach the IM cover cushion from the position as shown above. Detach the GND tape (lens). GND tape (lens) GND tape (lens) Remove the precision screw, and then remove the IM cover lid.
  • Page 42 Detach the IM radiation sheet (972). IM radiation sheet (972) Remove the three precision screws. Open the IM heat sink assembly. Detach the AR radiation sheet from the IM heat sink assembly. IM heat sink assembly Precision screws (TP2 x 5) AR radiation sheet Hook Remove the AR radiation sheet.
  • Page 43 10. Remove the four precision screws, and then remove the IM cover (972). Precision screws (TP2 x 5) IM cover (972) Precision screw (TP2 x 5) 11. Release the fine-wire coaxial cables from the IM clamp (972). IM clamp (972) IM clamp (972) Fine-wire coaxial cable (red) Fine-wire coaxial cable (green)
  • Page 44 12. Remove the precision screw, and then remove the IM clamp (972). Precision screw (TP2 x 5) IM clamp (972) 13. Remove the IM radiation sheet (972). IM radiation sheet (972)
  • Page 45 14. Disconnect the flexible board from the connector (CN1700) on the SE-1187 board. 15. Remove the two precision screws, and then remove the SE-1187 board. 16. Remove the GND tape (lens). Precision screws (TP2 x 5) SE-1187 board CN1700 GND tape (lens) Flexible board 17.
  • Page 46 18. Remove the three fine-wire coaxial cables from the three connectors of the prism assembly. Connectors Prism assembly Fine-wire coaxial cable (blue) Fine-wire coaxial cable (red) Fine-wire coaxial cable (green) 19. Install the removed parts by reversing the steps of removal.

  • Page 47: Inside Panel

    2-7. Inside Panel 2-7-1. Inside Panel Assembly Preparation Remove the cabinet (BM). (Refer to “2-2. Outside Panel Assembly”.) Procedure Open the ME lid and the DC lid. Remove the 10 precision screws. Release the three hooks, and then remove the inside panel assembly. Note Be careful not to break the flexible board.

  • Page 48: Lithium Battery

    2-7-2. Lithium Battery Preparation Remove the inside panel assembly. (Refer to “2-7-1. Inside Panel Assembly”.) Procedure Remove the lithium battery with non-conductive stick. Lithium secondary battery Hooks Hooks KSW-71 board Battery holder Inside panel assembly Install the removed parts by reversing the steps of removal.

  • Page 49: Board

    2-7-3. KSW-71 Board Preparation Remove the inside panel assembly. (Refer to “2-7-1. Inside Panel Assembly”.) Procedure Remove the four precision screws, and then remove the AU lid lock claw. Disconnect the four flexible flat cables from the four connectors (CN0106, CN0107, CN0109, CN0110) on the KSW-71 board. Inside panel assembly KSW-71 board AU lid lock claw...
  • Page 50 Remove the two precision screws. Release the two hooks, and then remove the front cabinet assembly. Front cabinet assembly Hooks Precision screws (TP2 x 5) Remove the four precision screws, and then remove the KSW-71 board. Disconnect the flexible board from the connector (CN0101) on the KSW-71 board. Inside panel assembly Flexible board KSW-71 board...

  • Page 51: Handle

    2-8. Handle 2-8-1. Handle Assembly Preparation Remove the outside panel assembly. (Refer to “2-2. Outside Panel Assembly”.) Remove the CT-287A board. (Refer to “2-3. CT-287A Board”.) Remove the jack assembly. (Refer to “2-4. VC-41 board”.) Remove the inside panel assembly. (Refer to “2-7-1. Inside Panel Assembly”.) Procedure Remove the six precision screws, and then remove the BT panel assembly.
  • Page 52 Detach the protection sheet (VC). Disconnect the flexible board from the connector (CN4301) on the VC-41 board. Disconnect the fine-wire coaxial cable from the connector (CN4300) on the VC-41 board. Remove the four precision screws, and then remove the handle assembly. Precision screws (P2.6 x 5) Handle assembly...

  • Page 53: Vf Assembly

    2-8-2. VF Assembly Procedure Open the display panel. Remove the four precision screws, and then remove the handle top cabinet assembly. Disconnect the flexible board from the connector (CN7002) on the HN-441 board. Handle top cabinet assembly Display panel Precision screws (P2 x 4) Flexible board CN7002...
  • Page 54 Turn the VF assembly in the direction of the arrow (A). Remove the two precision screws, and then remove the handle rear cabinet assembly in the direction of the arrow (B). Remove the four precision screws, and then remove the SH-85 assembly. Precision screws (M2 x 4) SH-85 assembly...
  • Page 55 Disconnect the flexible board from the connector (CN7008) on the HN-441 board. Remove the four precision screws, and then remove the VF assembly. Precision screws (M2 x 4) Flexible board VF assembly HN-441 board Precision screws CN7008 (M2 x 4) Install the removed parts by reversing the steps of removal.

  • Page 56: If-1346 Board

    2-8-3. IF-1346 Board Preparation Remove the outside panel assembly. (Refer to “2-2. Outside Panel Assembly”.) Remove the CT-287A board. (Refer to “2-3. CT-287A Board”.) Remove the jack assembly. (Refer to “2-4. VC-41 board”.) Remove the inside panel assembly. (Refer to “2-7-1. Inside Panel Assembly”.) Remove the handle assembly.
  • Page 57 Remove the two precision screws (A), and then remove the handle cabinet (horizontal). Remove the precision screw (B). Remove the four precision screws (C), lift the control panel block, and then remove the microphone cabinet assembly in the direction of the arrow (D) Lifting the control panel block releases the engagement with the microphone cabinet.
  • Page 58 Remove the waterproof sheet (IF). Remove the four precision screws, and then remove the control panel block and the microphone unit. Disconnect the flexible board from the connector (CN9015) on the IF-1346 board. Disconnect the flexible flat cable from the connector (CN9018) on the IF-1346 board. Waterproof sheet (IF) Precision screws (P2 x 4)
  • Page 59 Disconnect the flexible board from the connector (CN1000) on the IF-1346 board. 10. Disconnect the flexible flat cable from the connector (CN2000) on the IF-1346 board, and then remove the microphone unit. 11. Remove the two precision screws, and then remove the panel electrostatic plate. 12.

  • Page 60: Board, Lcd Assembly

    2-8-4. PD-126 Board, LCD Assembly Procedure Remove the two precision screws, and then remove the handle cabinet (horizontal). Disconnect the harness from the connector (CN6003) on the IF-1346 board. Disconnect the fine-wire coaxial cable from the connector (CN9003) on the IF-1346 board. Remove the four precision screws, and then remove the panel block.
  • Page 61 Turn the hinge portion in the direction of the arrow. Remove the two precision screws. Release the two hooks (hanging portion) and five hooks, and then remove the P cabinet C assembly. Hooks Hooks (hanging portion) Hinge portion Precision screws Hooks (P2 x 4) P cabinet C assembly...
  • Page 62 12. Remove the PD frame. 13. Remove the LCD cushion. 14. Remove the LCD assembly. LCD assembly LCD cushion PD frame 15. Install the removed parts by reversing the steps of removal.

  • Page 63: Board

    2-9. DC-184 Board Preparation Remove the outside panel assembly. (Refer to “2-2. Outside Panel Assembly”.) Remove the CT-287A board. (Refer to “2-3. CT-287A Board”.) Remove the jack assembly. (Refer to “2-4. VC-41 board”.) Remove the inside panel assembly. (Refer to “2-7-1. Inside Panel Assembly”.) Remove the BT panel assembly.

  • Page 64: Board

    2-10. AR-5 Board Preparation Remove the outside panel assembly. (Refer to “2-2. Outside Panel Assembly”.) Remove the CT-287A board. (Refer to “2-3. CT-287A Board”.) Remove the jack assembly. (Refer to “2-4. VC-41 board”.) Remove the inside panel assembly. (Refer to “2-7-1. Inside Panel Assembly”.) Remove the handle assembly.
  • Page 65 Disconnect the flexible board from the connector (CN0150) on the AR-5 board. Disconnect the fine-wire coaxial cable from the connector (CN0105) on the AR-5 board CN0150 Flexible board AR-5 board CN0105 Duct cover (lower) Fine-wire coaxial cable Note At the time of the installation, pass the fine-wire coaxial cable through the duct cover (lower). Remove the five precision screws.
  • Page 66 10. Disconnect the flexible board from the connector (CN0101) on the AR-5 board. 11. Disconnect the fine-wire coaxial cable from the connector (CN0102) on the AR-5 board. Fine-wire coaxial cable Flexible board CN0102 CN0101 AR-5 board 12. Install the removed parts by reversing the steps of removal.

  • Page 67: Board, Dd Clamper

    2-11. DD-53 Board, DD Clamper Preparation Remove the outside panel assembly. (Refer to “2-2. Outside Panel Assembly”.) Remove the CT-287A board. (Refer to “2-3. CT-287A Board”.) Remove the VC-41 board. (Refer to “2-4. VC-41 board”.) Remove the inside panel assembly. (Refer to “2-7-1. Inside Panel Assembly”.) Remove the handle assembly.
  • Page 68 Disconnect the harness from the connector (CN0100) on the DD-53 board. Remove the four precision screws, and then remove the BT holder assembly. Arrangement of harness Harness BT holder assembly CN0100 DD-53 board Harness Precision screws (P2 x 4) Remove the four precision screws. Release the two bosses, and then remove the DD-53 board in the direction of the arrow.
  • Page 69 10. Remove the DD heat sink assembly. 11. Remove the DD clamper in the direction of the arrow. Boss DD heat sink assembly Boss Holes DD clamper 12. Release the hook, and then remove the two fine-wire coaxial cables. Fine-wire coaxial cables DD clamper Hook Projection...

  • Page 70: Section 3 Error Code

    Section 3 Error Code If a problem occurs during operation of the unit, an error code will appear in the view finder display. Check the content of the error code and respond accordingly. 3-1. Error Code List Error Description Check and Action code Check: lens block, IC9600 (LD-136 board), IC6000 (VC-41 board), and the E10-005...
  • Page 71 Error Description Check and Action code Check: IC0700 (AR-5 board), and the peripheral devices. E91-377 Memory failure in IC0700 (AR-5 board) Repair or replace: AR-5 board. Check: IC0600 (VC-41 board), IC2000 (JK-106 board), and the peripheral Communication error from IC0600 (VC-41 E91-380 devices.

  • Page 72: Section 4 Service Menu

    Section 4 Service Menu 4-1. Overview The unit is provided with the Service menu that is useful for maintenance and adjustment. The menu content is displayed on the viewfinder. The Service menu consists of the following menus. Menu Item Description CMOS Adjustment CMOS imager adjustment White Shading...
  • Page 73 Menu Item Submenu Item Choice Function Reflection of setting Black Shading Setting On / Off Switches black shading correction Instantly on and off. Channel Select Red, Green, Blue Selects the channel (Red or Green Instantly or Blue) to execute the manual black shading correction.

  • Page 74: Description Of Service Menu

    4-4. Description of SERVICE Menu 4-4-1. CMOS Adjustment Menu The CMOS Adjustment menu allows to adjust CMOS registration deviation (CMOS Regi). Overview of CMOS Adjustment menu R CMOS H Regi The R CMOS H Regi function can adjust horizontal registration deviation of the R channel CMOS from the G channel CMOS. R CMOS V Regi The R CMOS V Regi function can adjust vertical registration deviation of the R channel CMOS from the G channel CMOS.

  • Page 75: Auto Black Balance Menu

    White V Para The White V Para menu enables the vertical Parabola white shading correction (sensitivity correction at the vertical center with respect to both ends) level. White shading adjustment method Preparation ・ Connect an HD waveform monitor to the SDI OUT terminal. ・...
  • Page 76 Black H Para The Black H Para menu enables the horizontal Parabola black shading correction (black level correction at the horizontal center with respect to both ends) level. Black V Saw The Black V Saw menu enables the vertical Saw black shading correction (linear increase and decrease) level. Black V Para The Black H Para menu enables the horizontal Parabola black shading correction (black level correction at the horizontal center with respect to both ends) level.

  • Page 77: Auto Shading Menu

    4-4-5. Auto Shading Menu The Auto Shading menu can execute auto-shading (auto-adjustment of shading correction). Note Disable SLS and S&Q before executing the Auto Shading menu. Overview of Auto Shading Menu Auto White Shading The Auto White Shading menu can execute auto-white shading. Pressing the CANCEL/BACK button during execution of auto-white shading interrupts the auto-white shading processing, and restores the unit to the state before the execution.

  • Page 78: Flare Menu

    4-4-6. Flare Menu The Flare adjustment menu enables flare compensation for the respective channels of G-channel, B-channel and R-channel. Flare Adjustment Method Preparation Connect an HD waveform monitor to the SDI OUT terminal. Select the center of the gray scale with the waveform monitor. Shoot a gray-scale chart to fill the entire screen of the picture frame and execute the white balance.

  • Page 79: Auto Fb Adjust Menu

    4-4-7. Auto FB Adjust Menu The Auto FB Adjust menu allows to automatically adjust the lens flange back. Flange Back Adjustment Method Adjustment Procedure Set all exposure adjustments to manual mode. Set the gain to 0 dB and open the iris completely. Place a high-contrast object at three meters from the front of the camera lens, and then adjust the illumination, camera shutter, and ND filter so that adequate video output can be obtained.

  • Page 80: Section 5 Spare Parts

    Therefore, specified parts should be used in the case 指定の部品を使ってください。 of replacement. 2. 部品の共通化 2. Standardization of Parts ソニーから供給する補修用部品は，セットに使われ Some repair parts supplied by Sony differ from those ているものと異なることがあります。 used for the unit. These are because of parts common- これは部品の共通化，改良等によるものです。 ality and improvement. 3. 部品の在庫...

  • Page 81: Exploded Views

    5-2. Exploded Views Overall-1 P2.6 x 8 Refer to “Overall-2” Refer to “Outside” P2.6 x 8...
  • Page 82 Part No. SP Description X-2589-888-4 s HOOD (941) ASSY X-2596-733-1 s HOLDER (973) ASSY, MICROPHONE 2-178-804-02 s BELT, GRIP 2-630-005-31 s SCREW(M2),NEW TRUSTER,P2 3-080-206-21 s SCREW, TAPPING, P2 3-284-621-11 s CUSHION, MICROPHONE HOLDER 3-694-181-11 s TYPE1,AROCK PRECISION +P2.6X5 3-965-077-11 s SCREW, SPECIAL (M2) 4-438-734-12 s SHOE CAP (875) 4-488-856-01 o CLAMP, DC CABLE 4-540-533-01 s FOOT (941), RUBBER...

  • Page 83: Overall-3

    Overall-2 Refer to “Jack” Refer to “Overall-3” Part No. SP Description A-2195-610-A s CT-287A MOUNT A-2225-512-A s VC-41 COMPL X-2596-728-1 s HEAT SINK ASSY, VC 1-912-723-11 s CABLE, FLEXIBLE FLAT (18 CORE) 1-983-027-11 s PWB, FP-273 FLEXIBLE 1-983-033-11 s PWB, FP-279 FLEXIBLE 2-630-005-31 s SCREW(M2),NEW TRUSTER,P2 2-891-494-31 s SCREW(M2),NEW TRUSTER,P2 3-079-115-01 s TAPE AS...
  • Page 84 Overall-3 Refer to “Handle-1” Refer to “Inside-1” To VC-41 board Refer to “Lens” Refer to “Main Chassis” Part No. SP Description A-2194-018-A s LD-136 MOUNT X-2596-722-1 s PANEL ASSY (972), BT 1-855-374-11 s DC FAN 1-893-191-11 s FP-2244 FLEXIBLE PWB 2-630-005-31 s SCREW(M2),NEW TRUSTER,P2 2-891-494-31 s SCREW(M2),NEW TRUSTER,P2 3-694-181-11 s TYPE1,AROCK PRECISION +P2.6X5...

  • Page 85: Main Chassis

    Main Chassis To VC-41 board To VC-41 board To VC-41 board Part No. SP Description A-2193-977-A s DC-184 MOUNT A-2225-398-A s DD-53 COMPL A-2225-511-A s AR-5 COMPL X-2596-715-1 s HEAT SINK ASSY, DD X-2596-716-1 s HOLDER ASSY, BT 1-780-986-11 s TERMINAL BOARD, BATTERY 1-969-036-11 s HARNESS (DPR-CMOS B) 1-970-362-11 s HARNESS (DD-1012) 1-972-386-11 s HARNESS (VC-AR-50P)

  • Page 86: Lens

    Lens To LD-136 board To LD-136 board To VC-41 board To VC-41 board To VC-41 board Part No. SP Description A-2226-152-A s SE-1187 COMPL A-2226-549-A s LENS, LSV-1740B SERVICE A-2226-666-A s LSV-1620C(RP) X-2596-727-1 s HEAT SINK ASSY, IM X-2596-731-1 s SUB FRAME ASSY, VC 1-972-329-11 s HARNESS (COAXIAL 48P) 3-079-115-01 s TAPE AS 3-080-206-21 s SCREW, TAPPING, P2...

  • Page 87: Outside

    Outside To CT-287A board...
  • Page 88 Part No. SP Description A-2193-988-A s SS-107 MOUNT A-2194-011-A s SW-1735 MOUNT A-2194-012-A s TC-117 MOUNT 1-493-502-11 s SWITCH BLOCK CONTROL(PZ97300) 1-912-724-11 s CABLE, FLEXIBLE FLAT (16 CORE) 1-912-725-11 s CABLE, FLEXIBLE FLAT (6 CORE) 1-912-732-11 s CABLE, FLEXIBLE FLAT (6 CORE) 3-079-115-01 s TAPE AS 3-080-206-21 s SCREW, TAPPING, P2 4-165-331-01 s BRACKET (REAR), GRIP BELT...

  • Page 89: Inside-1

    Inside-1 Refer to “Inside-2” Refer to “Front Cabinet” To AR-5 board To FU-82 board Part No. SP Description A-2193-986-A s KSW-71 MOUNT X-2596-726-1 s LID ASSY (972), ME 1-493-503-11 s SWITCH BLOCK CONTROL(AU97300) 1-756-134-18 s BATTERY, LITHIUM (SECONDARY) 1-912-729-11 s CABLE, FLEXIBLE FLAT (16 CORE) 1-912-734-11 s CABLE, FLEXIBLE FLAT (6 CORE) 1-983-038-11 s PWB, FP-284 FLEXIBLE 2-249-361-01 s PIN, PARALLEL...
  • Page 90 Inside-2 KSW-71 board...
  • Page 91 Part No. SP Description A-2201-099-A s FU-82 MOUNT A-2201-100-A s SEC-58 MOUNT A-2203-445-A s MEC-43A MOUNT A-2226-711-A s TG-289A MOUNT X-2596-724-1 s CABINET ASSY (972), IN SIDE 1-492-342-11 s SWITCH BLOCK, CONTROL(KP40400) 1-912-730-11 s CABLE, FLEXIBLE FLAT (6 CORE) 1-912-733-11 s CABLE, FLEXIBLE FLAT (6 CORE) 2-891-494-31 s SCREW(M2),NEW TRUSTER,P2 3-079-115-01 s TAPE AS 3-080-206-21 s SCREW, TAPPING, P2...

  • Page 92: Front Cabinet

    Front Cabinet KSW-71 board IR-73A board Part No. SP Description A-2194-008-A s GCN-19 MOUNT A-2195-613-A s VSW-81A MOUNT A-2195-614-A s IR-73A MOUNT 1-492-897-11 s SWITCH BLOCK CONTROL (ID94100) 1-858-706-23 s LOUDSPEAKER (1.8CM) 1-912-725-11 s CABLE, FLEXIBLE FLAT (6 CORE) 1-912-731-11 s CABLE, FLEXIBLE FLAT (12 CORE) 2-178-550-01 s HOLDER, SPEAKER 2-891-494-31 s SCREW(M2),NEW TRUSTER,P2 3-080-206-21 s SCREW, TAPPING, P2...

  • Page 93: Handle-1

    Handle-1 Refer to “EVF” Refer to “Handle-2” Part No. SP Description A-2193-985-A s SH-85 MOUNT X-2596-718-1 s CABINET ASSY, HANDLE (TOP) X-2596-719-1 s CABINET ASSY, HANDLE (REAR) 1-480-298-11 s SWITCH BLOCK, CONTROL(GZ92000) 2-630-005-31 s SCREW(M2),NEW TRUSTER,P2 2-891-494-31 s SCREW(M2),NEW TRUSTER,P2 3-080-206-21 s SCREW, TAPPING, P2 3-288-483-01 s SPRING, SS LOCK 3-288-511-02 s CLAW, LOCK...

  • Page 94: Handle-2

    Handle-2 1005 1012 1005 1007 1009 1005 1016 1017 1015 1008 HN-441 board 1004 Refer to “LCD Panel” 1001 Refer to “Handle-3” 1010 1006 1013 AR-5 board 1006 1003 1013 1014 1019 1018 1019 1005 1002 1011 1018 1005 VC-41 board Part No.
  • Page 95 Handle-3 1110 1119 1110 1113 1101 1127 1110 SH-85 board 1110 1114 1105 1108 1110 VC-41 board 1127 1103 1110 1109 1126 1120 1122 1121 1125 1118 1104 1112 1123 1122 1106 AR-5 board IF-1346 board 1107 1102 1110 Refer to “Handle-4” 1109 1111 1109...
  • Page 96 Part No. SP Description 1101 A-2059-048-A s GP-1019COMPLE(SN11) 1102 A-2193-982-A s AXM-60 MOUNT 1103 A-2193-984-A s HN-441 MOUNT 1104 A-2193-987-A s PSW-109 MOUNT 1105 1-893-019-11 s FP-2231 FLEXIBLE PWB 1106 1-912-726-11 s CABLE, FLEXIBLE FLAT (20 CORE) 1107 1-912-727-11 s CABLE, FLEXIBLE FLAT (26 CORE) 1108 1-912-728-11 s CABLE, FLEXIBLE FLAT (24 CORE) 1109...

  • Page 97: Handle-3

    Handle-4 1212 1201 1211 1219 1205 1204 1219 1213 1216 1210 IF-1346 board 1215 1217 1206 1203 1218 1209 1208 1214 1207 1202 1205 Part No. SP Description 1201 A-2193-985-A s SH-85 MOUNT 1202 X-2596-720-1 s CABINET ASSY, MICROPHONE 1203 1-894-979-11 s MIC UNIT 1204 1-912-728-11 s CABLE, FLEXIBLE FLAT (24 CORE)

  • Page 98: Evf

    1317 1309 1319 1305 1314 1310 1303 1301 1312 1310 HN-441 board 1310 1313 1304 1316 1307 1311 1308 1315 1302 1320 1318 1306 Part No. SP Description 1301 A-1902-812-A s FP-2005 MOUNT 1302 A-2165-562-A s VF PANEL ASSY EP3N 1303 A-2194-020-A s VF-98 MOUNT 1304...

  • Page 99: Lcd Panel

    LCD Panel 1409 1405 1412 1413 1406 1414 1402 1409 1411 1409 1417 1407 IF-1346 board 1408 1418 1419 1410 1401 1416 1415 1404 1409 1403 Part No. SP Description 1401 A-2066-639-A s SERVICE, LCD BLOCK ASSY 1402 A-2066-640-A s P CAB M ASSY (SERVICE ) 1403 A-2116-011-A s P CAB C ASSY (SERVICE) 1404...

  • Page 100: Jack

    Jack 1522 1513 To VC-41 board 1507 1503 To VC-41 board 1515 1510 1508 1510 1509 1501 1514 1516 1506 1512 1517 1505 1510 1502 1518 1511 1519 BTP2.6 x 10 1504 1521 1520 Part No. SP Description 1501 A-2193-978-A s IO-283 MOUNT 1502 A-2194-015-A s JK-106 MOUNT 1503...

  • Page 101: Supplied Accessories

    5-3. Supplied Accessories Q'ty Part No. SP Description X-2597-449-1 S EYE CUP (LARGE) ASSY 1-846-424-32 S CORD SET, POWER-SUPPLY [For J] 1-846-425-33 S CORD SET, POWER-SUPPLY [For UC] 1-846-428-33 S CORD SET, POWER-SUPPLY [For CEE] 1-846-433-34 S CORD SET, POWER-SUPPLY [For CN1] 1-846-615-12 S CABLE, CONNECTION (USB) 1-848-066-32 S AC POWER SUPPLY CORD SET [For India] 4-740-707-01 S CD-ROM PACK...

  • Page 102: Section 6 Diagrams

    Section 6 Diagrams Overall Overall (1/3) VC-41(1/3) PD-126 IF-1346(1/2) (ROSE)2(LCD)_R2-R9/ LCD901 BI-342 IC0600 G2-G9/B2-B9/HD/VD/CLK (LCD MODULE) (1/3) IC1001 IC0100 IC0901 IC6001 D0+/-_PANEL-D2+/-_PANEL, D0+/-_PANEL-D2+/-_PANEL, (CIS)2(DFE)_A_DT_P[0]-P[11], (DFE)2(ROSE)_A_DT_P[0]-P[5], PANEL_R0-R7 CLK+/-_PANEL CLK+/-_PANEL CMOS (CIS)2(DFE)_A_DT_N[0]-N[11] (DFE)2(ROSE)_A_DT_N[0]-N[5] LVDS LVDS /G0-G7/B0-B7 3.5 INCH COLOR IMAGER (CIS)2(DFE)_A_CLK_P/N (DIF)2(ROSE)_A_CLK_P/N PANEL_VD/HD IC9001 F9001...
  • Page 103 Overall (2/3) VC-41(2/3) KSW-71 AR-5(1/2) IC6000 SEC-58 FU-82 (2/3) SLOT KEY1_AD7 KEY1_AD7 KEY1_AD7 KEY1_AD7 ADC1_IN7 SELECT ANTENNA FULL IO-283 AUTO IC7401 KEY1_AD9_AS6 KEY1_AD9 ADC1_IN9 NFC_SIO/SCK NFC_SIO/SCK ASSIGN6 MEC-43 ASSIGN1-5 INTERFACE CONTROL SHUTER SWITCH (ON/OFF) (KY)2(AST)_DIAL0A/DIAL0B (KY)2(AST)_DIAL0A/DIAL0B BLOCK IC2612 CN101 KEY1_AD5 USB2.0 (KP40400) CN2_USB_D+/D-...
  • Page 104 Overall (3/3) AR-5(2/2) VC-41(3/3) IC6000 IC0300 (3/3) IC2000 (SW)2(SD0)_PETP1/PETN1, (SD0)2(SW)_PERP1/PERN1 SD0_UHS-II_D0P/D0N MEMORY CARD CONTROL SLOT A UHS-II (AST)_I2C_SDA1/SCL1 (AST)_I2C_SDA_1/SCL_1 PCIe SWITCH IC2101 FROM (SW)2(USB)_PETP3/PETN3, (SW)2(USB)_PETP3/PETN3, (SW)2(SD1)_PETP2/PETN2, VC-41 (USB)2(SW)_PERP3/PERN3 (USB)2(SW)_PERP3/PERN3 (SD1)2(SW)_PERP2/PERN2 SD1_UHS-II_D0P/D0N (2/3) MEMORY CARD (SW)2(ETH)_PETP4/PETN4, CONTROL (ETH)2(SW)_PERP4/PERN4 SLOT B UHS-II IC0600,0604 CLOCK (CLKGEN)2(SD0)_REFCLKP0/REFCLKN0...

  • Page 105: Frame Wiring

    Frame Wiring VC-41 JK-106 J1000 RS-55 FLEXIBLE FLAT CABLE CN1100 WIRED LAN SH-85 (18 CORE) HARNESS FLEXIBLE FLAT CABLE MULTI J101 INTERFACE (SW-116) (24 CORE) D1100 S7501 SHOE(FRONT) RECORDING/ PANEL TC IN/OUT HARNESS TALLY LAMP(FRONT) (DPR-AVP) REVERSE PD-126 IF-1346 HARNESS SE-1187 LD-136 (COAXIAL CABLE)

  • Page 106: Revision History

    Revision History Date History Contents ― 2018. 7 1st Edition 9-932-618-01...
  • Page 107 PXW-Z190V (UC) PXW-Z190V (CEE) PXW-Z190V (CN1) PXW-Z190V (J) PXW-Z190T (UC) Printed in Japan PXW-Z190T (CEE) J, E 2018. 7 08 Sony Corporation 9-932-618-01 © 2018...

This manual is also suitable for:

Pxw-z190t
