Rigol DS1000E Series User Manual page 61

Use the horizontal

portion.
Use the horizontal

To change the main time base, turn off the Delayed Scan mode.

Since both the main and Delayed Scan are displayed; there are half as many

vertical divisions so the vertical scaling is doubled. Notice the changes in the
status bar.
Delayed Scan Shortcut Key:
Delayed Scan function can be activated not only by menu but also by pressing
horizontal
