Revision History
Revision Date (yyyy.mm.dd) Author Changes
0.1 2018.01.15
1.0 2018.10.15
1.1 2019.03.19
1.2 2019.04.02
1.3 2019.07.30
1.4 2020.01.07
1.5 2020.03.04
1.6 2020.06.02
1.7 2020.11.19
Copyright © 2018 congatec AG
BEU • Preliminary release
•
BEU Updated "Electrostatic Sensitive Device" information on page 3
• Corrected single/dual channel MT/s rates for two variants in table 2
• Updated section 2.2 "Supported Operating Systems"
•
Added values for four variants in section 2.5 "Power Consumption"
• Added values in section 2.6 "Supply Voltage Battery Power"
• Updated images in section 4 "Cooling Solutions"
• Added note about requiring a re-driver on carrier for USB 3.1 Gen 2 in section 5.1.2 "USB" and 7.4 "USB Host Controller"
• Added Intel Ethernet Controller i211 as assembly option in table 4 "Feature Summary" and section 5.1.4 "Ethernet"
®
• Corrected section 7.4 "USB Host Controller"
• Added section 9 "System Resources"
BEU • Corrected image in section 2.4 "Supply Voltage Standard Power"
• Updated section 10.4 "Supported Flash Devices"
BEU • Corrected supported memory in table 2, 3, and added information about supported memory in table 4
• Added information about the new industrial variant in table 3 and 7
•
BEU Updated note in section 4 "Cooling Solutions"
• Changed number of supported USB 3.1 Gen 2 interfaces to two throughout the document
• Added note regarding USB 3.1 Gen 2 in section 7.4 "USB Host Controller"
BEU • Updated title page
• Updated CPU clock speed of variant 041603 in table 2
• Added variants 041620 and 041621 to table 3 and 7
•
Updated section 4 "Cooling Solutions"
• Updated references for power supply implementation guidelines in section 5.1.12 "Power Control"
• Added reference to BIOS Setup Description application note in section 10 "BIOS Setup Description"
•
Updated section 10.3 "Updating the BIOS"
• Updated supported flash device in section 10.4 "Supported Flash Devices"
• Added note to several button signals in table 24
•
Updated section 11 "Industry Specifications"
BEU • Added power consumption values and updated existing ones in table 7
•
BEU Corrected product name in section 4 "Cooling Solutions"
BEU • Added note to section 5.1.8 "LVDS"
• Added PWR_OK implementation recommendation to section 5.1.12 "Power Control"
•
Removed section 11 "Industry Specifications"
