Table 29 PCI Express Signal Descriptions (x16 Graphics)
Signal Pin # Description
PEG_RX0+ C52 PCI Express Graphics Receive Input differential pairs.
PEG_RX0- C53
PEG_RX1+ C55
PEG_RX1- C56
PEG_RX2+ C58
PEG_RX2- C59
PEG_RX3+ C61
PEG_RX3- C62
PEG_RX4+ C65
PEG_RX4- C66
PEG_RX5+ C68
PEG_RX5- C69
PEG_RX6+ C71
PEG_RX6- C72
PEG_RX7+ C74
PEG_RX7- C75
PEG_RX8+ C78
PEG_RX8- C79
PEG_RX9+ C81
PEG_RX9- C82
PEG_RX10+ C85
PEG_RX10- C86
PEG_RX11+ C88
PEG_RX11- C89
PEG_RX12+ C91
PEG_RX12- C92
PEG_RX13+ C94
PEG_RX13- C95
PEG_RX14+ C98
PEG_RX14- C99
PEG_RX15+ C101
PEG_RX15- C102
Copyright © 2018 congatec AG
I/O
I PCIE
TR44m17
PU/PD Comment
PEG_RX[8:15]± lanes are not
supported.
