Table 27 SuperSpeed USB Signal Descriptions
Signal Pin # Description
USB_SSRX0+ C4 Additional receive signal differential pairs for the Superspeed USB data path
USB_SSRX0- C3
USB_SSTX0+ D4 Additional transmit signal differential pairs for the Superspeed USB data path O
USB_SSTX0- D3
USB_SSRX1+ C7 Additional receive signal differential pairs for the Superspeed USB data path
USB_SSRX1- C6
USB_SSTX1+ D7 Additional transmit signal differential pairs for the Superspeed USB data path O
USB_SSTX1- D6
USB_SSRX2+ C10 Additional receive signal differential pairs for the Superspeed USB data path
USB_SSRX2- C9
USB_SSTX2+ D10 Additional transmit signal differential pairs for the Superspeed USB data path O
USB_SSTX2- D9
USB_SSRX3+ C13 Additional receive signal differential pairs for the Superspeed USB data path
USB_SSRX3- C12
USB_SSTX3+ D13 Additional transmit signal differential pairs for the Superspeed USB data path O
USB_SSTX3- D12
Table 28 PCI Express Signal Descriptions (general purpose)
Signal Pin # Description
PCIE_RX6+ C19 PCI Express channel 6, Receive Input differential pair.
PCIE_RX6- C20
PCIE_TX6+ D19 PCI Express channel 6, Transmit Output differential pair.
PCIE_TX6- D20
PCIE_RX7+ C22 PCI Express channel 7, Receive Input differential pair.
PCIE_RX7- C23
PCIE_TX7+ D22 PCI Express channel 7, Transmit Output differential pair.
PCIE_TX7- D23
Copyright © 2018 congatec AG
I/O PU/PD Comment
I
I
O
I
I
O
I
I
O
I
I
O
I/O PU/PD Comment
I PCIE Supports PCI Express Base Specification, Revision 3.0
O PCIE Supports PCI Express Base Specification, Revision 3.0
I PCIE Not supported in R-Series.
Supports PCI Express Base Specification, Revision 3.0
O PCIE Not supported in R-Series.
Supports PCI Express Base Specification, Revision 3.0
