Table 21 SPI BIOS Flash Interface Signal Descriptions
Signal Pin # Description
SPI_CS# B97 Chip select for Carrier Board SPI BIOS Flash.
SPI_MISO A92 Data in to module from carrier board SPI BIOS flash.
SPI_MOSI A95 Data out from module to carrier board SPI BIOS flash.
SPI_CLK A94 Clock from module to carrier board SPI BIOS flash.
SPI_POWER A91 Power source for carrier board SPI BIOS flash. SPI_POWER shall
be used to power SPI BIOS flash on the carrier only.
BIOS_DIS0# A34 Selection strap to determine the BIOS boot device.
BIOS_DIS1# B88 Selection strap to determine the BIOS boot device.
Table 22 General Purpose I/O Signal Descriptions
Signal Pin # Description
GPO0 A93 General purpose output pins.
GPO1 B54 General purpose output pins.
GPO2 B57 General purpose output pins.
GPO3 B63 General purpose output pins.
GPI0 A54 General purpose input pins. Pulled high internally on the module.
GPI1 A63 General purpose input pins. Pulled high internally on the module.
GPI2 A67 General purpose input pins. Pulled high internally on the module.
GPI3 A85 General purpose input pins. Pulled high internally on the module.
Table 23 Miscellaneous Signal Descriptions
Signal Pin # Description
I2C_CK B33 General purpose I²C port clock output/input
I2C_DAT B34 General purpose I²C port data I/O line
SPKR B32 Output for audio enunciator, the "speaker" in PC-AT systems
WDT B27 Output indicating that a watchdog time-out event has occurred. O 3.3V
FAN_PWMOUT B101 Fan speed control. Uses the Pulse Width Modulation (PWM)
technique to control the fan's RPM.
FAN_TACHIN B102 Fan tachometer input.
TPM_PP A96 Physical Presence pin of Trusted Platform Module (TPM). Active
high. TPM chip has an internal pull-down. This signal is used to
indicate Physical Presence to the TPM.
