Signal

Pin # Description

USB0+

A46

USB Port 0, data + or D+

USB0-

A45

USB Port 0, data - or D-

USB1+

B46

USB Port 1, data + or D+

USB1-

B45

USB Port 1, data - or D-

USB2+

A43

USB Port 2, data + or D+

USB2-

A42

USB Port 2, data - or D-

USB3+

B43

USB Port 3, data + or D+

USB3-

B42

USB Port 3, data - or D-

USB4+

A40

USB Port 4, data + or D+

USB4-

A39

USB Port 4, data - or D-

USB5+

B40

USB Port 5, data + or D+

USB5-

B39

USB Port 5, data - or D-

USB6+

A37

USB Port 6, data + or D+

USB6-

A36

USB Port 6, data - or D-

USB7+

B37

USB Port 7, data + or D+

USB7-

B36

USB Port 7, data - or D-

USB_0_1_OC#

B44

USB over-current sense, USB ports 0 and 1. A pull-up for this line shall

be present on the module. An open drain driver from a USB current

monitor on the carrier board may drive this line low.

USB_2_3_OC#

A44

USB over-current sense, USB ports 2 and 3. A pull-up for this line shall

be present on the module. An open drain driver from a USB current

monitor on the carrier board may drive this line low.

USB_4_5_OC#

B38

USB over-current sense, USB ports 4 and 5. A pull-up for this line shall

be present on the module. An open drain driver from a USB current

monitor on the carrier board may drive this line low.

USB_6_7_OC#

A38

USB over-current sense, USB ports 6 and 7. A pull-up for this line shall

be present on the module. An open drain driver from a USB current

monitor on the carrier board may drive this line low.

I/O

PU/PD Comment

I/O
