Flame Pattern

Periodically check the pilot and main burner flames . Correct pilot flame pattern has two strong blue flames:

1 flowing around the flame sensor and 1 flowing across the burner (it does not have to be touching the burner) .

Correct main burner flame pattern

Incorrect flame pattern will have small, probably yellow flames, not coming into proper contact with the rear burner

or flame sensor .

NOTE: If you have an incorrect flame pattern, contact your Faber dealer for further instructions .
