Summary of Contents for Faber Fyn 450
- Page 1 Fyn 450...
- Page 2 1 < < < <...
- Page 3 2 < < < <...
-
Page 4: Safety Instructions
1 Introduction The appliance can only be installed by a competent person in accordance with the Gas Safety. We urgently advise you to read this installation manual properly. This appliance complies with the Gas Appliance Regulation (EU) 2016/426. Harmonized standards applied EN 613 2000/A1 2003. 2 Safety instructions ... -
Page 5: Installation Requirements
The false chimney breast and its construction may not rest on the appliance. Requirements flue system and outlets You should always make use of the materials prescribed by Faber International Ltd. Only by using these materials can Faber International Ltd. guarantee a proper functioning. -
Page 6: Preparation And Installation Instructions
Corners of the building. Roof overhangs and balconies. Eaves, with the exception of the roof ridge (See Capital 15). Existing chimney You can also connect the appliance to an existing chimney. The existing chimney will function as an air supply and a flexible stainless steel pipe drawn up through the chimney will remove the combustion gas. - Page 7 Clear a safe space to store the frame and the glass. Remove the frame, (if necessary) and the glass and take the separately wrapped parts out of the appliance. Prepare the gas connection to the gas control valve. Placing the appliance Take the installation requirements into account (see chapter 3).
-
Page 8: Removing The Glass
5 Removing the glass Remove the cover strips on the left and right hand side (see fig. 2.1). Remove the glass clips, by using a screwdriver (see fig. 2.2). Place the suction discs onto the glass (see fig. 1.6). ... -
Page 9: Checking The Installation
7 Checking the installation Checking the ignition of the pilot burner, main burner. Start the pilot and main burner according to the instructions in the user manual. Check whether the pilot light is properly positioned above the main burner and is not covered by chips, an imitation log or pebbles. -
Page 10: Instructing The Client
Checking the flame picture Allow the appliance to burn for at least 20 minutes at full and then check the flame picture for: Distribution of the flames. Color of the flames. If either one or both points are unacceptable, then check: ... -
Page 11: Annual Maintenance
If necessary the chips/embers. Cleaning the glass Most of the deposits can be removed with a dry cloth. Clean the glass with Faber glass polish. Note: prevent fingerprints on the glass. these will be burned into it once the appliance is used and cannot be removed anymore! Carry-out the check-up according to the instructions in chapter 7 “checking the... -
Page 12: Calculation Of Flue System
11 Calculation of flue system A simple way to calculate whether the exhaust configuration is possible in combination with your fire, use the free “Faber Flue App” and download it from: INTERNET: BlackBerry, Android, PC (Windows Store) APP store: iPhone, iPad and Mac. - Page 13 • Elbows 90° in the horizontal plane: Horizontal bends are bends which are entirely in the horizontal plane (fig. 12.1, 12.2 and 12.3 I, K and Q). • Bends 45° or 30° in the horizontal plane: Horizontal bends are bends which are entirely in the horizontal plane. •...
- Page 14 11.1 Table and air-restrictor plate Starting length (STL), Vertical (TVH) and Horizontal (THL) 30,1 30,1 30,1 40,1 50,1 50,1 60,1 60,1 60,1 65,1 65,1 65,1 65,1 65,1 65,1 65,1 65,1 65,1 65,1 65,1 65,1 65,1 65,1 65,1 65,1 65,1 65,1 65,1 65,1 65,1...
- Page 15 12 Examples flue materials Fig. 12.1 Fig. 12.2 Fig. 12.3 14 < < < <...
- Page 16 13 Examples flue materials Starter length (STL) First part on top of the appliance Value Flue length from 0,1m till 0,45m Flue length from 0,5m till 0,90m Flue length from 1m till 1,4m Flue length from 1,5m till 2m Flue length 2m or more Bend 90°...
- Page 17 found value Search in the table at TVH and THL and enter the value that is found. ……………………………… If the detected value is a number, check whether the completed STL is higher or equal to the value in the table. Is the STL value lower as specified in the table then the installation is not possible.
-
Page 18: Technical Data
14 Technical data Technical data Type indication(s) Farum, Fyn, Fyn 450, Concept I-450 Type appliance C11/C31/C91 Diameter outlet/inlet 100/150 Gas connection 3/8" Indirect heating functionality Category II2H3+ Symbol Unit Reference gas/inlet pressure G20-20 G30-30 G31-37 mbar mg/kWh input Emissions in space heating... - Page 19 15 Terminal position Short roof terminal. Only for existing Chimney connection Extension pipe over roof Location Position outlet Distance mm Under a gutter Under a roof edge Under a carport or balcony Vertical downpipe Inside and outside corners From wall surface to a wall outlet 1000 Two gable outlets against over each other 1000...
- Page 20 Location Position outlet Distance mm Under a gutter Under a roof edge Under a carport or balcony Vertical downpipe Inside and outside corners From wall surface to a wall outlet 1000 Two gable outlets against over each other 1000 Distance between two roof outlets Two roof outlets above each other on a pitched roof 1000 Two gable outlets next to each other...
-
Page 21: Troubleshooting Guide
16 Troubleshooting guide 20 < < < <... - Page 22 21 < < < <...
- Page 23 22 < < < <...
- Page 24 23 < < < <...
- Page 25 24 < < < <...
-
Page 26: Dimensional Drawings
17 Dimensional drawings 17.1 Fyn 450 25 < < < <... - Page 27 17.2 Ventilation grid 26 < < < <...
- Page 28 17.3 Remote access door 27 < < < <...
- Page 29 28 < < < <...
- Page 30 29 < < < <...
- Page 31 Fyn 450...
