  • Page 1 Installation manual Farum 40011999-2006...
  • Page 2 Installation manual Farum 1 < < < <...
  • Page 3 Installation manual Farum 2 < < < <...
  • Page 4 Installation manual Farum 3 < < < <...
  • Page 5 Installation manual Farum 4 < < < <...
  • Page 6 Installation manual Farum 5 < < < <...
  • Page 7 Safety instructions Dear user  Please note! Congratulations on your purchase of a Faber fire! A quality product from which you will experience It is advisable to always install a screen for the warmth and atmosphere for many years. We...
  • Page 8: Installation Requirements

    100/150mm or 130/200mm. See fig. 1.2 for the wiring diagram: C31, outlet via roof A = Adapter (6 V) For a (flat) roof, use a Faber roof outlet with a B = Gas valve diameter of 100/150mm. C = Receiver...
  • Page 9 The controller can be connected to an external Avoid fingerprints on the glass, these are no source, such as a Domotica system, by using a longer removable once the fire is used. Faber Interface Unit (article number A9323000). Placing decoration material Preparing the fireplace ...
  • Page 10 Installation manual Farum Pebbles Check ignition and burner Ignite the fireplace by using the remote control as See the supplied decoration instruction card or described in the user manual and test all burner chapter 18.2. possibilities.  Divide the pebbles over the burner and Checking the flame image the bottom.
  • Page 11 Start length (STL): Remove the front glass (see chapter 5). The first part that is placed on the You can clean the glass with Faber glass polish. fireplace and represents a certain value This is a specially formulated cleaning agent that (fig.
  • Page 12 Installation manual Farum  If a value is indicated, check that the calculated STL Elbows 45° or 30° vertical to horizontal value is not lower than indicated in the restrictor plane: table. In this case STL must be adjusted. These are 30° or 45° elbows vertically offset less than 45°...
  • Page 13 Installation manual Farum 11.1 Restrictor table (100/150) Start length (STL) Vertical (TVH) and Horizontal (THL) 30.00 30.00 30.10 30.00 30.00 0.00 0.00 0.00 0.00 30.10 30.00 30.00 30.00 0.00 0.00 0.00 30.10 40.00 30.00 30.00 30.00 0.00 0.00 40.10 50.00 40.00...
  • Page 14 Installation manual Farum 12 Examples flue materials 13 < < < <...
  • Page 15 Installation manual Farum 13 Calculation sheet Starter length (STL) First part on top of the appliance Value Flue length from 0,1m till 0,45m Flue length from 0,5m till 0,90m Flue length from 1m till 1,4m Flue length from 1,5m till 2m Flue length 2m or more Bend 90°...
  • Page 16 Installation manual Farum found value Search in the table at TVH and THL and enter the value that is found. ……………………………… If the detected value is a number, check whether the completed STL is higher or equal to the value in the table.
  • Page 17: Technical Data

    Installation manual Farum 14 Technical data Technical data Type indication(s) Farum, Fyn, Fyn 450, Concept I-450 Type appliance C11/C31/C91 Diameter outlet/inlet 100/150 Gas connection 3/8" Indirect heating functionality Category II2H3+ Symbol Unit Reference gas/inlet pressure G20-20 G30-30 G31-37 mbar Emissions in space heating...
  • Page 18 Installation manual Farum 15 Outlet position  Please note! These rules apply only for the proper functioning of the unit, for ventilation and environmental protection you need to comply with the applicable rules as defined in the building regulations. Short roof terminal.
  • Page 19: Troubleshooting Guide

    Installation manual Farum 16 Troubleshooting guide 18 < < < <...
  • Page 20 Installation manual Farum 19 < < < <...
  • Page 21 Installation manual Farum 17 Dimensional drawings 17.1 Farum 20 < < < <...
  • Page 22 Installation manual Farum 17.2 Position gas connection 21 < < < <...
  • Page 23 Installation manual Farum 18 Decoration instruction card 18.1 Log set 22 < < < <...
  • Page 24 Installation manual Farum 18.2 Pebbles 23 < < < <...
  • Page 25 Installation manual Farum 24 < < < <...
  • Page 26 Installation manual Farum 25 < < < <...
  • Page 27 Installation manual Farum 26 < < < <...
  • Page 28 www.faberfires.com contact@faberfires.com Saturnus 8 NL 8448 CC Heerenveen Postbus 219 NL 8440 AE Heerenveen...
